9099-24-24
Connection Details: {"Side 1 Connection Type":"Male Komatsu","Side 1 Thread Type":"M24X1.5","Side 1 Standard":"Komatsu Standard","Side 1 Role":"Line Connection","Side 2 Connection Type":"Male Komatsu","Side 2 Thread Type":"M24X1.5","Side 2 Standard":"Komatsu Standard","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Union","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"1.000","Weight":"0.26 lb"}
D2425-S25-25-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"25mm","Side 1 Thread Type":"M36X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Tube Weld","Side 2 Tube OD":"25mm","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Coupling","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Weight":"0.49 lb"}
7200-06-06-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-18 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male BSPT 30°","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"R - 3/8-19","Side 2 Standard":"ISO 7-1","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"0.748","Weight":"0.17 lb"}
D7802-L18-08-NWO-RR-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male BSPP Adjustable ORR","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"45° Elbow","Shape Type":"Male Adjustable Elbow","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Weight":"0.47 lb"}
8900-22-VITON
Specifications: {"Nominal OD":"22mm","Exact OD":"23.7mm","Exact ID":"19.3mm","Exact Width":"2.2mm","Color":"Brown","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Temperature":"-15°F to 400°F","Dash Size":"-M22","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, synthetic lubricants, fuels, diesel, gasoline, hydraulic oils, phosphate ester fluids, silicone oils and greases, diester lubricants, aromatic hydrocarbons, many chlorinated hydrocarbons, mild acids","Not Recommended For":"Ketones, amines, low molecular weight esters and ethers, hot hydrofluoric acids, strong alkalis, steam, hot water, glycol-based brake fluids"} Cross References: {"Parker TFD Part Number":"2-018 FKM"}
5503-06-06-FG-B
Connection Details: {"Side 1 Connection Type":"Male NPTF 30°","Side 1 Pipe Size":"3/8\"","Side 1 Thread Type":"3/8-18 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Line/Pipe Connection","Side 2 Connection Type":"Female NPTF","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"45° Elbow","Shape Type":"Street Elbow","Primary Material":"Brass","Material Grade":"CA377","Surface Treatment":"Natural Finish"} Dimensions: {"Weight":"0.18 lb"}
4404-20-12
Connection Details: {"Side 1 Connection Type":"Beaded Hose Barb","Side 1 Hose ID":"1-1/4\"","Side 1 Standard":"SAE J1231-2","Side 1 Role":"Hose Connection","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.36 lb"}
D8400-L12-22-CF-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"12mm","Side 1 Thread Type":"M18X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male Metric Cut Face","Side 2 Thread Type":"M22X1.5","Side 2 Standard":"DIN 3852-1, ISO 1179-1","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"27mm","Weight":"0.26 lb"}
D2404-L18-08-SS-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"18mm","Side 1 Thread Type":"M26X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ANSI/ASME B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"27mm","Weight":"0.18 lb"}
6405-06-02-O-VITON
Connection Details: {"Side 1 Connection Type":"Male ORB","Side 1 Thread Type":"9/16-18 UNF","Side 1 Standard":"SAE J1926","Side 1 Role":"Port Connection","Side 1 Replacement Seal":"4001-06","Side 2 Connection Type":"Female NPTF","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Adapter","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Weight":"0.07 lb"}
1940-61-12
Connection Details: {"Connection End Port 1 Type":"Female NPTF","Connection End Port 1 Thread":"1/4-18 NPTF","Connection End Port 2 Type":"Female O-Ring Boss","Connection End Port 2 Thread":"7/16-20 UNF-2B","Flange Interface Sealing Type":"Dual Face","Flange Interface Code":"Code 61","Flange Interface Pad Size":"3/4\""} Body & Materials: {"Primary Material":"Steel","Material Grade":"C1020","Weight":"1.2897 lb"} Performance Specifications: {"Working Pressure":"5000 psi","Temperature Range":"-65°F to 500°F","Burst Pressure":"20000 psi","Burst Ratio":"4:1"}
2403-LH-05-05
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Union","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.07 lb"}
D6400-S25-16-O-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"25mm","Side 1 Thread Type":"M36X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"1-5/16-12 UN","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4000-16"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"41mm","Weight":"0.58 lb"}
D7801-S14-08-CF-BANJO-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"14mm","Side 1 Thread Type":"M22X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male BSPP Cut Face","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"DIN 3852-2, ISO 1179-4","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Banjo Elbow","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)","Seal Code":"FKM"} Dimensions: {"Hex/Wrench":"32mm","Weight":"0.73 lb"}
7008-04-02
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIS","Side 2 Thread Type":"G - 1/8-28","Side 2 Standard":"JIS B 0202","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"Straight","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"0.630","Weight":"0.05 lb"}
0500-20-16-SS
Connection Details: {"Side 1 Connection Type":"Bore","Side 1 Tube OD":"1-1/4\"","Side 1 Standard":"Not Defined","Side 1 Role":"Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"1\"","Side 2 Thread Type":"1-5/16-12 UN","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316/316L"} Dimensions: {"Weight":"1.01 lb"}
C2650-32-32-32-32-SS
Connection Details: {"Side 1 Connection Type":"Flareless Bite Type","Side 1 Tube OD":"2\"","Side 1 Thread Type":"2-1/2-12 UN","Side 1 Standard":"SAE J514","Side 1 Role":"Tube Connection","Side 2 Connection Type":"Flareless Bite Type","Side 2 Tube OD":"2\"","Side 2 Thread Type":"2-1/2-12 UN","Side 2 Standard":"SAE J514","Side 2 Role":"Tube Connection","Side 3 Connection Type":"Flareless Bite Type","Side 3 Tube OD":"2\"","Side 3 Thread Type":"2-1/2-12 UN","Side 3 Standard":"SAE J514","Side 3 Role":"Tube Connection","Side 4 Connection Type":"Flareless Bite Type","Side 4 Tube OD":"2\"","Side 4 Thread Type":"2-1/2-12 UN","Side 4 Standard":"SAE J514","Side 4 Role":"Tube Connection"} Body & Materials: {"Shape":"Cross","Shape Type":"Union Cross","Primary Material":"Stainless Steel","Material Grade":"316/316L"} Dimensions: {"Weight":"0.22 lb"}
FS7001-06-16
Series Configuration: Male ORFS x Male Metric ORR Technical Series Configuration: SAE J1453 Male ORFS Tube x ISO 9974 (Type G) Male Metric ORR Port Connector Side 1 Connection Type: Male ORFS
D8801-L22-26-CF-BANJO-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"22mm","Side 1 Thread Type":"M30X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male Metric Cut Face","Side 2 Thread Type":"M26X1.5","Side 2 Standard":"DIN 3852-1, ISO 9974-3","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Banjo Elbow","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)","Seal Code":"FKM"} Dimensions: {"Hex/Wrench":"41mm","Weight":"1.28 lb"}
D6602-L42-L42-L42-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"4mm","Side 1 Thread Type":"M52X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Female Metric Swivel","Side 2 Thread Type":"M52X2.0","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Line Connection","Side 2 DIN Pressure Series":"Light","Side 3 Connection Type":"DIN Tube","Side 3 Tube OD":"42mm","Side 3 Thread Type":"M52X2.0","Side 3 Standard":"DIN 2353, ISO 8434-1","Side 3 Role":"Tube Connection","Side 3 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Tee","Shape Type":"Swivel Run Tee","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Hex/Wrench":"50mm","Weight":"3.34 lb"}
1904-62-32
Connection Details: {"Flange Interface Code":"Code 62","Flange Interface Flange Size":"2\""} Body & Materials: {"Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Weight":"4.93 lb"} Performance Specifications: {"Working Pressure":"6000 psi","Temperature Range":"-65°F to 500°F","Corrosion Resistance":"120 hrs no white rust; 240 hrs no red rust per ASTM B117","Burst Pressure":"24000 psi","Burst Ratio":"4:1"}
D7400-L12-12-ED
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"12mm","Side 1 Thread Type":"M18X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male BSPP ED Seal","Side 2 Thread Type":"G - 3/4-14","Side 2 Standard":"DIN 3852-11, ISO 1179-2","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"ED4000-12"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"32mm","Weight":"0.29 lb"}
4000-05-PC
Specifications: {"Nominal OD":"5/16\"","Exact OD":"0.558\"","Exact ID":"0.414\"","Exact Width":"0.072\"","Color":"Black with blue dot","Seal Code":"HNBR","Seal Material":"Hydrogenated Nitrile","Temperature":"-40°F to 250°F","Dash Number":"-905","Dash Size":"-05","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, fuels, diesel, gasoline, hydraulic fluids, water (moderate temperatures), ozone, weathering, sour gas, amines","Not Recommended For":"Phosphate ester fluids, strong acids, chlorinated hydrocarbons, ketones, esters, high concentrations of aromatic hydrocarbons"} Shape: O-Ring
