Brennan Product Browser
24,928Total
24,928Scraped
0Pending
24,928 matching products
Clear
1502-20-20-FG
Connection Details: {"Side 1 Connection Type":"Female NPTF","Side 1 Pipe Size":"1-1/4\"","Side 1 Thread Type":"1-1/4-11-1/2 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Female NPSM Swivel","Side 2 Pipe Size":"1-1/4\"","Side 2 Thread Type":"1-1/4-11-1/2 NPSM","Side 2 Standard":"SAE J514","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Swivel Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"1.70 lb"}
D6504-L28-L10
Connection Details: {"Side 1 Connection Type":"Female Metric Swivel","Side 1 Tube OD":"28mm","Side 1 Thread Type":"M36X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line Connection","Side 1 DIN Pressure Series":"Light","Side 1 Replacement Seal":"M4000-28","Side 2 Connection Type":"DIN Tube","Side 2 Tube OD":"10mm","Side 2 Thread Type":"M16X1.5","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Tube Connection","Side 2 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Straight","Shape Type":"Swivel Reducer","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"36mm","Weight":"0.90 lb"}
9233-06-06-FG
Connection Details: {"Side 1 Connection Type":"Female BSPP","Side 1 Thread Type":"G - 3/8-19","Side 1 Standard":"ISO 1179","Side 1 Role":"Port Connection","Side 2 Connection Type":"Female BSPP","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"0.875","Weight":"0.69 lb"}
D6504-L42-L28-X
Connection Details: {"Side 1 Connection Type":"Female Metric Swivel","Side 1 Tube OD":"42mm","Side 1 Thread Type":"M52X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line Connection","Side 1 DIN Pressure Series":"Light","Side 1 Replacement Seal":"M4000-42","Side 2 Connection Type":"Male DIN","Side 2 Tube OD":"28mm","Side 2 Thread Type":"M36X2.0","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Line/Tube Connection","Side 2 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Straight","Shape Type":"Swivel Reducer","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"50mm","Weight":"0.94 lb"}
FS2404-08-16
Connection Details: {"Side 1 Connection Type":"Male ORFS","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"13/16-16 UNF","Side 1 Standard":"SAE J1453 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 1 Replacement Seal":"FS4000-08","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"1\"","Side 2 Thread Type":"1-11-1/2 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Connector","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Weight":"0.35 lb"}
9033-10-06
Connection Details: {"Side 1 Connection Type":"Female BSPP","Side 1 Thread Type":"G - 5/8-14","Side 1 Standard":"ISO 1179","Side 1 Role":"Port Connection","Side 2 Connection Type":"Female BSPP","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Union","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"1.181","Weight":"0.14 lb"}
6809-10-10-NWO-FG
Connection Details: {"Side 1 Connection Type":"Male Adjustable ORB","Side 1 Thread Type":"7/8-14 UNF","Side 1 Standard":"SAE J1926","Side 1 Role":"Port Connection","Side 1 Replacement Seal":"4000-10","Side 2 Connection Type":"Female JIC Swivel","Side 2 Tube OD":"5/8\"","Side 2 Thread Type":"7/8-14 UNF","Side 2 Standard":"SAE J514 - Class 2B Thread","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Adjustable Swivel Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Weight":"0.40 lb"}
DP2404-04
Dimensions: {"Weight":"0.18 lb"} Performance Specifications: {"Temperature Range":"°F to °F"} Cross References: {"Parker TFD Part Number":"EMA3/1/4NPT"}
2404-12-12-SS
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-1/16-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Connector","Primary Material":"Stainless Steel","Material Grade":"316/316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"1.125","Weight":"0.29 lb"}
2704-LN-05-05-05-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"5/16\"","Side 1 Thread Type":"1/2-20 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"5/16\"","Side 2 Thread Type":"1/2-20 UNF","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection","Side 3 Connection Type":"Male JIC","Side 3 Tube OD":"5/16\"","Side 3 Thread Type":"1/2-20 UNF","Side 3 Standard":"SAE J514 - Class 2A Thread","Side 3 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Tee","Shape Type":"Bulkhead Run Tee","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Feature":"Bulkhead"} Dimensions: {"Weight":"0.16 lb"}
FS2702-10-10-FG
Connection Details: {"Side 1 Connection Type":"Male ORFS","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"1-14 UNS","Side 1 Standard":"SAE J1453 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 1 Replacement Seal":"FS4000-10","Side 2 Connection Type":"Male ORFS","Side 2 Tube OD":"5/8\"","Side 2 Thread Type":"1-14 UNS","Side 2 Standard":"SAE J1453 - Class 2A Thread","Side 2 Role":"Line/Tube Connection","Side 2 Replacement Seal":"FS4000-10"} Body & Materials: {"Shape":"45° Elbow","Shape Type":"Bulkhead Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Feature":"Bulkhead","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Weight":"0.53 lb"}
4003-42
Specifications: {"Nominal OD":"42mm","Exact OD":"43mm","Exact ID":"37.77mm","Exact Width":"2.62mm","Color":"Black","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)","Temperature":"-40°F to 250°F","Dash Size":"-M42","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, fuels, diesel, gasoline, hydraulic fluids, aliphatic hydrocarbons, water (below 150°F), natural gas, air","Not Recommended For":"Phosphate ester fluids, glycol-based brake fluids, strong acids, ozone, weathering, ketones, esters, chlorinated hydrocarbons"} Cross References: {"Parker TFD Part Number":"2-128"}
D6602-L08-L08-L08-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"8mm","Side 1 Thread Type":"M14X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Female Metric Swivel","Side 2 Thread Type":"M14X1.5","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Line Connection","Side 2 DIN Pressure Series":"Light","Side 3 Connection Type":"DIN Tube","Side 3 Tube OD":"8mm","Side 3 Thread Type":"M14X1.5","Side 3 Standard":"DIN 2353, ISO 8434-1","Side 3 Role":"Tube Connection","Side 3 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Tee","Shape Type":"Swivel Run Tee","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Hex/Wrench":"12mm","Weight":"0.20 lb"}
6316-10-SS
Connection Details: {"Side 1 Connection Type":"Female JIC Swivel","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"7/8-14 UNF","Side 1 Standard":"SAE J514 - Class 2B Thread","Side 1 Role":"Line Connection","Side 2 Connection Type":"Buttweld","Side 2 Tube OD":"5/8\"","Side 2 Thread Type":"7/8-14 UNF","Side 2 Standard":"Not defined","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Swivel Connector","Primary Material":"Stainless Steel","Material Grade":"316/316L"} Dimensions: {"Weight":"0.20 lb"}
D8400-S20-27-CF
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"20mm","Side 1 Thread Type":"M30X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male Metric Cut Face","Side 2 Thread Type":"M27X2.0","Side 2 Standard":"DIN 3852-1, ISO 1179-1","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Hex/Wrench":"32mm","Weight":"0.46 lb"}
9900-06-SS-VITON
Specifications: {"Nominal OD":"3/8\"","Exact OD":"0.937\"","Exact ID":"0.589\"","Exact Width":"0.08\"","Color":"Brown","Gasket Dash Size":"-06","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Temperature":"-15°F to 400°F","Seal Hardness":"75 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, synthetic lubricants, fuels, diesel, gasoline, hydraulic oils, phosphate ester fluids, silicone oils and greases, diester lubricants, aromatic hydrocarbons, many chlorinated hydrocarbons, mild acids","Not Recommended For":"Ketones, amines, low molecular weight esters and ethers, hot hydrofluoric acids, strong alkalis, steam, hot water, glycol-based brake fluids"} Cross References: {"Parker TFD Part Number":"D9DT-6-SS FKM"}
D7400-S08-04-CF
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"8mm","Side 1 Thread Type":"M16X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male BSPP Cut Face","Side 2 Thread Type":"G - 1/4-19","Side 2 Standard":"DIN 3852-2, ISO 1179-4","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Hex/Wrench":"19mm","Weight":"0.15 lb"}
3474-12-12-NWO-SS-VITON
Connection Details: {"Side 1 Connection Type":"Male Adjustable ORB","Side 1 Thread Type":"1-1/16-12 UN","Side 1 Standard":"SAE J1926","Side 1 Role":"Port Connection","Side 1 Replacement Seal":"4001-12","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"1-1/16-12 UN","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4001-12"} Body & Materials: {"Shape":"Straight","Shape Type":"Nipple","Primary Material":"Stainless Steel","Material Grade":"316/316L","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Weight":"0.49 lb"}
8900-10-PC
Specifications: {"Nominal OD":"10mm","Exact OD":"11.3mm","Exact ID":"8.1mm","Exact Width":"1.6mm","Color":"Black with blue dot","Seal Code":"HNBR","Seal Material":"Hydrogenated Nitrile","Temperature":"-40°F to 250°F","Dash Size":"-M10","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, fuels, diesel, gasoline, hydraulic fluids, water (moderate temperatures), ozone, weathering, sour gas, amines","Not Recommended For":"Phosphate ester fluids, strong acids, chlorinated hydrocarbons, ketones, esters, high concentrations of aromatic hydrocarbons"} Shape: Washer
D7400-L35-24-ED-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"35mm","Side 1 Thread Type":"M45X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male BSPP ED Seal","Side 2 Thread Type":"G - 1-1/2-11","Side 2 Standard":"DIN 3852-11, ISO 1179-2","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"ED4000-24"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"55mm","Weight":"1.00 lb"}
6506-08-06-SS
Connection Details: {"Side 1 Connection Type":"Female NPTF","Side 1 Pipe Size":"1/2\"","Side 1 Thread Type":"1/2-14 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Female JIC Swivel","Side 2 Tube OD":"3/8\"","Side 2 Thread Type":"9/16-18 UNF","Side 2 Standard":"SAE J514 - Class 2B Thread","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Swivel Connector","Primary Material":"Stainless Steel","Material Grade":"316/316L"} Dimensions: {"Weight":"0.27 lb"}
2501-10-12-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"7/8-14 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"1.062","Weight":"0.42 lb"}
FS2700-LN-10-08
Connection Details: {"Side 1 Connection Type":"Male ORFS","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"1-14 UNS","Side 1 Standard":"SAE J1453 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 1 Replacement Seal":"FS4000-10","Side 2 Connection Type":"Male ORFS","Side 2 Tube OD":"1/2\"","Side 2 Thread Type":"13/16-16 UNF","Side 2 Standard":"SAE J1453 - Class 2A Thread","Side 2 Role":"Line/Tube Connection","Side 2 Replacement Seal":"FS4000-08"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc","Feature":"Bulkhead","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Weight":"0.44 lb"}
