768LGSS3/8X1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/8 | 760LBSS3/8","Side 1 Replacement Nut":"761LSS3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.82\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.82\"","Weight":"0.221 lb"}
Pipe Weld Elbow N2525-06-04-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-06-SS | N0319-B-06-SS","Side 1 Replacement Nut":"N0318-06-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Pipe Weld","Side 2 Pipe Size":"1/4\"","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Pipe Weld Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"0.91\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"0.91\"","Weight":"0.1375 lb"}
Let-Lok Cap 7108LSS10MMOC
Connection Details: {"Connection Type":"Double Ferrule Compression","Tube OD":"10mm","Thread Type":"5/8-20 UN","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Cap","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean"} Dimensions: {"Hex/Wrench":"18mm","Overall Length/Centerline":"26.6mm","Weight":"0.088 lb"}
766LGSS8MMX1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"8mm","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female BSPP","Side 2 Thread Type":"G - 1/4-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"38.5mm"} Dimensions: {"Hex/Wrench":"19mm","Overall Length/Centerline":"38.5mm","Weight":"0.11 lb"}
768LSS18MMX3/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"18mm","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"50.5mm"} Dimensions: {"Hex/Wrench":"27mm","Overall Length/Centerline":"50.5mm","Weight":"0.322 lb"}
765HLB3/8
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760HLB3/8","Side 1 Replacement Nut":"761LB3/8","Side 1 Tube Fitting System":"Ham-let One-Lok Series","Side 2 Connection Type":"Single Ferrule Compression","Side 2 Tube OD":"3/8\"","Side 2 Thread Type":"9/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760HLB3/8","Side 2 Replacement Nut":"761LB3/8","Side 2 Tube Fitting System":"Ham-let One-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Brass","Length":"0.91\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"0.91\"","Weight":"0.154 lb"}
763LSS1/2X1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/2 | 760LBSS1/2","Side 1 Replacement Nut":"761LSS1/2","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"1/4\"","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFSS1/4 | 760LBSS1/4","Side 2 Replacement Nut":"761LSS1/4","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Reducer","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.85\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.85\"","Weight":"0.163 lb"}
769HLRSS1/2X1/2
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760HLSS1/2","Side 1 Replacement Nut":"761LSS1/2","Side 1 Tube Fitting System":"Ham-let One-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"R - 1/2-14","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.02\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.02\"","Weight":"0.302 lb"}
Male Elbow NS2501-04-02-SS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"NS0319-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan NS Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"0.77\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.77\"","Weight":"0.122 lb"}
771LB3/8X1/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"3/8\"","Side 3 Thread Type":"9/16-20 UN","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Male Run Tee","Primary Material":"Brass","Surface Treatment":"Oxygen Clean","Length":"0.91\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"0.91\"","Weight":"0.2384 lb"}
767LPSS1/4LF
Connection Details: {"Side 1 Connection Type":"Port Connector","Side 1 Tube OD":"1/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Tube Stub","Side 2 Tube OD":"1/4\"","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Port Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"0.98\""} Dimensions: {"Overall Length/Centerline":"0.98\"","Weight":"0.01 lb"}
121HSS3/8
Connection Details: {"Connection Type":"NPT Plug","Pipe Size":"3/8\"","Thread Type":"3/8-18 NPT","Role":"Pipe Connection","Connection Role":"Pipe Connection"} Body & Materials: {"Shape":"Plug","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.99\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.99\"","Weight":"0.108 lb"}
Cap NS2408-16-SS
Connection Details: {"Connection Type":"Single Ferrule Compression","Tube OD":"1\"","Thread Type":"1-5/16-20 UN","Standard":"ASTM A213, A249, A269","Connection Standard":"ASTM A213, A249, A269","Tube Fitting System":"Brennan NS Series","Replacement Ferrule":"NS0319-16-SS","Replacement Nut":"N0318-16-SS"} Body & Materials: {"Shape":"Cap","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"1.51\""} Dimensions: {"Hex/Wrench":"1.375\"","Overall Length/Centerline":"1.51\"","Weight":"0.3047 lb"}
772LFSS12MMX1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"12mm","Side 2 Thread Type":"3/4-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series","Side 3 Connection Type":"Female NPT","Side 3 Pipe Size":"1/4\"","Side 3 Thread Type":"1/4-18 NPT","Side 3 Standard":"ASME/ANSI B1.20.1","Side 3 Role":"Pipe Connection"} Body & Materials: {"Shape":"Tee","Shape Type":"Female Branch Tee","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"25.9mm"} Dimensions: {"Hex/Wrench":"20.6mm","Overall Length/Centerline":"25.9mm","Weight":"0.364 lb"}
Union Connector 762LB10MMOC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"10mm","Side 1 Thread Type":"5/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"10mm","Side 2 Thread Type":"5/8-20 UN","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Brass","Surface Treatment":"Oxygen Clean"} Dimensions: {"Hex/Wrench":"18mm","Overall Length/Centerline":"46.2mm","Weight":"0.154 lb"}
739LMSS1/4X3/8
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.49\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"1.49\"","Weight":"0.01 lb"}
Bulkhead Union 774LSS6MMOC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"6mm","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead Union","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean"} Dimensions: {"Hex/Wrench":"16mm","Overall Length/Centerline":"57.7mm","Weight":"0.11 lb"}
120HB3/8X1/4
Connection Details: {"Side 1 Connection Type":"Female NPT","Side 1 Pipe Size":"3/8\"","Side 1 Thread Type":"3/8-18 NPT","Side 1 Standard":"ASME/ANSI B1.20.1","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Adapter","Primary Material":"Brass","Length":"1.5\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"1.5\"","Weight":"0.159 lb"}
769LSS1/16X1/16
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/16\"","Side 1 Thread Type":"3/16-32 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/16 | 760LBSS1/16","Side 1 Replacement Nut":"761LSS1/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/16\"","Side 2 Thread Type":"1/16-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.6\""} Dimensions: {"Hex/Wrench":"0.4375\"","Overall Length/Centerline":"0.6\"","Weight":"0.051 lb"}
7102LSS1/2OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"1/2\"","Side 2 Thread Type":"3/4-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"1/2\"","Side 3 Thread Type":"3/4-20 UNEF","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series","Side 4 Connection Type":"Double Ferrule Compression","Side 4 Tube OD":"1/2\"","Side 4 Thread Type":"3/4-20 UNEF","Side 4 Role":"Tube Connection","Side 4 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Cross","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"1.02\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.02\"","Weight":"0.529 lb"}
768LOBSS1/2X7/814
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/2 | 760LBSS1/2","Side 1 Replacement Nut":"761LSS1/2","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"7/8-14 UNF","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4001-10"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.77\""} Dimensions: {"Hex/Wrench":"1\"","Overall Length/Centerline":"1.77\"","Weight":"0.169 lb"}
Let-Lok Back Ferrule 760LBB16MM
Connection Details: {"Connection Type":"Double Ferrule Compression Back Ferrule","Tube OD":"16mm","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Sleeve","Primary Material":"Brass"} Dimensions: {"Weight":"0.0102 lb"}
