Let-Lok Front Ferrule 760LFSS38MM
Connection Details: {"Connection Type":"Double Ferrule Compression Front Ferrule","Tube OD":"38mm","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Sleeve","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Weight":"0.0169 lb"}
768LGSS3/4X1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/4 | 760LBSS3/4","Side 1 Replacement Nut":"761LSS3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.93\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.93\"","Weight":"0.277 lb"}
Union Elbow 765LSS8MM
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"8mm","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS8MM | 760LBSS8MM","Side 1 Replacement Nut":"761LSS8MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"8mm","Side 2 Thread Type":"1/2-20 UNF","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFSS8MM | 760LBSS8MM","Side 2 Replacement Nut":"761LSS8MM","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"14.3mm","Overall Length/Centerline":"21.3mm","Weight":"0.132 lb"}
Male Connector N2404-02-04-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/8\"","Side 1 Thread Type":"5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-02-SS | N0319-B-02-SS","Side 1 Replacement Nut":"N0318-02-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"1.4\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"1.4\"","Weight":"0.0984 lb"}
767LTSS3/8X3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/8 | 760LBSS3/8","Side 1 Replacement Nut":"761LSS3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Tube Stub","Side 2 Tube OD":"3/8\"","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Reducer","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.7\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"1.7\"","Weight":"0.063 lb"}
765LM1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFM1/4 | 760LBM1/4","Side 1 Replacement Nut":"761LM1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"1/4\"","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFM1/4 | 760LBM1/4","Side 2 Replacement Nut":"761LM1/4","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Nickel Alloy","Material Grade":"Alloy 400","Length":"0.77\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.77\"","Weight":"0.123 lb"}
Let-Lok Plug 7121LSS2
Connection Details: {"Connection Type":"Double Ferrule Compression Plug","Tube OD":"2\"","Thread Type":"2-5/8-20 UN","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Plug","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"3\"","Weight":"3.521 lb"}
767LTSS3/4X1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/4 | 760LBSS3/4","Side 1 Replacement Nut":"761LSS3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Tube Stub","Side 2 Tube OD":"1/2\"","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Reducer","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"2.15\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"2.15\"","Weight":"0.223 lb"}
769LSS5/16X1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"5/16\"","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS5/16 | 760LBSS5/16","Side 1 Replacement Nut":"761LSS5/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.84\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"0.84\"","Weight":"0.107 lb"}
SAE J518 Code 62 Split Flange Kit 1902-08
Flange Kit Components: {"Flange Part Number":"1952-08","Flange Size":"1/2\"","Bolt Type":"Hex Head","Bolt Grade":"Grade 8","Bolt Material":"Steel","Bolt Quantity":"4","Washer Type":"Lock Washer","Washer Material":"Steel","Washer Quantity":"4","O-Ring Part Number":"4005-08","O-Ring Dash Size":"-08","O-Ring Dash Number":"-210","O-Ring Quantity":"1"} Cross References: {"Aeroquip Part Number":"FF595-08","Parker Hose Part Number":"HFHFHK-8","Parker TFD Part Number":"8FCS2SK"} Series Configuration: Code 62 Split Flange Kit
Code 61 NPTF Flange O-Ring Face 1927-61-06-08
Connection Details: {"Connection End Type":"Female NPTF","Connection End Pipe Size":"3/8\"","Connection End Thread":"3/8-18 NPTF","Connection End Standard":"SAE J476 - ANSI B1.20.3","Connection End Role":"Pipe Connection","Flange Interface Sealing Type":"O-Ring Face","Flange Interface Code":"Code 61","Flange Interface Pad Size":"1/2\""} Body & Materials: {"Primary Material":"Steel","Material Grade":"C1020","Weight":"0.6687 lb"} Performance Specifications: {"Working Pressure":"5000 psi","Temperature Range":"-65°F to 500°F","Burst Pressure":"20000 psi","Burst Ratio":"4:1"}
739LNSS1/4X1/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Pipe Weld","Side 2 Pipe Size":"1/4\"","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.14\""} Dimensions: {"Overall Length/Centerline":"1.14\"","Weight":"0.031 lb"}
122HSS3/4
Connection Details: {"Side 1 Connection Type":"Male NPT","Side 1 Pipe Size":"3/4\"","Side 1 Thread Type":"3/4-14 NPT","Side 1 Standard":"ASME/ANSI B1.20.1","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Hex Nipple","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.84\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.84\"","Weight":"0.276 lb"}
766LSS5/8X3/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"7/8-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS5/8 | 760LBSS5/8","Side 1 Replacement Nut":"761LSS5/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.9\""} Dimensions: {"Hex/Wrench":"1.3125\"","Overall Length/Centerline":"1.9\"","Weight":"0.62 lb"}
765LSS1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"1/4\"","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"0.77\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.77\"","Weight":"0.11 lb"}
768LGSS3/8X1/2TC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/8 | 760LBSS3/8","Side 1 Replacement Nut":"761LSS3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Feature":"Thermo Couple","Length":"1.82\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.82\"","Weight":"0.229 lb"}
769LSS12MMX1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"25.9mm"} Dimensions: {"Hex/Wrench":"20.6mm","Overall Length/Centerline":"25.9mm","Weight":"0.441 lb"}
768LB1/8X1/8TC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/8\"","Side 1 Thread Type":"5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/8 | 760LBB1/8","Side 1 Replacement Nut":"761LB1/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Feature":"Thermo Couple","Length":"1.2\""} Dimensions: {"Hex/Wrench":"0.4375\"","Overall Length/Centerline":"1.2\"","Weight":"0.046 lb"}
764LRB5/8X5/8X3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"7/8-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB5/8 | 760LBB5/8","Side 1 Replacement Nut":"761LB5/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"5/8\"","Side 2 Thread Type":"7/8-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"3/8\"","Side 3 Thread Type":"9/16-20 UN","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Union Reducer Tee","Primary Material":"Brass","Length":"1.13\""} Dimensions: {"Hex/Wrench":"0.9375\"","Overall Length/Centerline":"1.13\"","Weight":"0.5952 lb"}
Male Connector NS6400-12-12-O-SS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"NS0319-12-SS","Side 1 Replacement Nut":"N0318-12-SS","Side 1 Tube Fitting System":"Brennan NS Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"1-1/16-12 UN","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4000-12"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.93\""} Dimensions: {"Hex/Wrench":"1.25\"","Overall Length/Centerline":"1.93\"","Weight":"0.3187 lb"}
768LSS10MMX1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"10mm","Side 1 Thread Type":"5/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS10MM | 760LBSS10MM","Side 1 Replacement Nut":"761LSS10MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"36.3mm"} Dimensions: {"Hex/Wrench":"18mm","Overall Length/Centerline":"36.3mm","Weight":"0.108 lb"}
739LTFLSS3/8X3/8BD
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"3/8\"","Side 2 Thread Type":"9/16-18 UNF","Side 2 Standard":"SAE J514","Side 2 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"15.9mm","Weight":"0.064 lb"}
