D7601-L10-L10-08-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"10mm","Side 1 Thread Type":"M16X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"DIN Tube","Side 2 Tube OD":"10mm","Side 2 Thread Type":"M16X1.5","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Tube Connection","Side 2 DIN Pressure Series":"Light","Side 3 Connection Type":"Male BSPT","Side 3 Thread Type":"1/2-14","Side 3 Standard":"ISO 7-1","Side 3 Role":"Pipe Connection"} Body & Materials: {"Shape":"Tee","Shape Type":"Male Branch Tee","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"19mm","Weight":"0.41 lb"}
D2403-CV-L06-L06-1.0CP
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Check Valve","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Weight":"0.29 lb"}
7001-10-22-SS
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"7/8-14 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male Metric ORR","Side 2 Thread Type":"M22X1.5","Side 2 Standard":"ISO 9974","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4003-22","Side 2 Replacement Washer":"8200-22-SS"} Body & Materials: {"Shape":"Straight","Shape Type":"Adapter","Primary Material":"Stainless Steel","Material Grade":"316/316L","Surface Treatment":"Passivated","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"1.063","Weight":"0.21 lb"}
1404-06-06-R.095
Connection Details: {"Side 1 Connection Type":"Male NPTF 30°","Side 1 Standard":"SAE J476","Side 1 Role":"Line/Pipe Connection","Side 2 Connection Type":"Female NPSM Swivel","Side 2 Standard":"SAE J514","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Swivel Connector","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.15 lb"}
D8801-S08-14-CF-BANJO-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"8mm","Side 1 Thread Type":"M16X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male Metric Cut Face","Side 2 Thread Type":"M14X1.5","Side 2 Standard":"DIN 3852-1, ISO 9974-3","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Banjo Elbow","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)","Seal Code":"FKM"} Dimensions: {"Hex/Wrench":"22mm","Weight":"0.26 lb"}
5501-20-20-FG
Connection Details: {"Side 1 Connection Type":"Male NPTF 30°","Side 1 Pipe Size":"1-1/4\"","Side 1 Thread Type":"1-1/4-11-1/2 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Line/Pipe Connection","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"1-1/4\"","Side 2 Thread Type":"1-1/4-11-1/2 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"45° Elbow","Shape Type":"Male Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.83 lb"}
D7400-S08-08-CF
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"8mm","Side 1 Thread Type":"M16X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male BSPP Cut Face","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"DIN 3852-2, ISO 1179-4","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Hex/Wrench":"27mm","Weight":"0.29 lb"}
7032-02-06-BS
Connection Details: {"Side 1 Connection Type":"Male NPTF 30°","Side 1 Pipe Size":"1/8\"","Side 1 Thread Type":"1/8-27 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Line/Pipe Connection","Side 2 Connection Type":"Male BSPP 60° Line/Port","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 8434-6, ISO 1179","Side 2 Role":"Line/Port Connection","Side 2 Replacement Gasket":"9900-06"} Body & Materials: {"Shape":"Straight","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc","Feature":"Bonded Seal","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"0.866","Weight":"0.01 lb"}
D8601-S10-S10-16-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"10mm","Side 1 Thread Type":"M18X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"DIN Tube","Side 2 Tube OD":"10mm","Side 2 Thread Type":"M18X1.5","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Tube Connection","Side 2 DIN Pressure Series":"Heavy","Side 3 Connection Type":"Male Metric Taper","Side 3 Thread Type":"M16X1.5","Side 3 Standard":"DIN 3852-1, DIN 3852-2","Side 3 Role":"Pipe Connection"} Body & Materials: {"Shape":"Tee","Shape Type":"Male Branch Tee","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"17mm","Weight":"0.36 lb"}
7002-16-08-SS-BS
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"1\"","Side 1 Thread Type":"1-5/16-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male BSPP 60° Line/Port","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"ISO 8434-6, ISO 1179","Side 2 Role":"Line/Port Connection","Side 2 Replacement Gasket":"9900-08"} Body & Materials: {"Shape":"Straight","Shape Type":"Adapter","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc","Feature":"Bonded Seal","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"1.375","Weight":"0.33 lb"}
0306-05-SS
Connection Details: {"Connection Type":"JIC Locknut","Tube OD":"5/16\"","Thread Type":"1/2-20 UNF","Standard":"SAE J514","Connection Standard":"SAE J514","Role":"Line Connection","Connection Role":"Line Connection"} Body & Materials: {"Shape":"Nut","Shape Type":"Lock Nut","Primary Material":"Stainless Steel","Material Grade":"316/316L"} Dimensions: {"Weight":"0.03 lb"}
6504-14-14
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"7/8\"","Side 1 Thread Type":"1-3/16-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Female JIC Swivel","Side 2 Tube OD":"7/8\"","Side 2 Thread Type":"1-3/16-12 UN","Side 2 Standard":"SAE J514 - Class 2B Thread","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Swivel Adapter","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.44 lb"}
D2603-L12-L10-L10
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"12mm","Side 1 Thread Type":"M18X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"DIN Tube","Side 2 Tube OD":"10mm","Side 2 Thread Type":"M16X1.5","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Tube Connection","Side 2 DIN Pressure Series":"Light","Side 3 Connection Type":"DIN Tube","Side 3 Tube OD":"10mm","Side 3 Thread Type":"M16X1.5","Side 3 Standard":"DIN 2353, ISO 8434-1","Side 3 Role":"Tube Connection","Side 3 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Tee","Shape Type":"Reducer Union Tee","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Hex/Wrench":"17mm","Weight":"0.30 lb"}
D8404-L12-18-SS
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"12mm","Side 1 Thread Type":"M18X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male Metric Taper","Side 2 Pipe Size":"18mm","Side 2 Thread Type":"M18X1.5","Side 2 Standard":"DIN3852-1, DIN3852-2","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"19mm","Weight":"0.16 lb"}
5406-06-04-SS
Connection Details: {"Side 1 Connection Type":"Male NPTF","Side 1 Pipe Size":"3/8\"","Side 1 Thread Type":"3/8-18 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Female NPTF","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Reducer Bushing","Primary Material":"Stainless Steel","Material Grade":"316/316L"} Dimensions: {"Weight":"0.05 lb"}
4001-04
Specifications: {"Nominal OD":"1/4\"","Exact OD":"0.495\"","Exact ID":"0.351\"","Exact Width":"0.072\"","Color":"Brown","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Temperature":"-15°F to 400°F","Dash Number":"-904","Dash Size":"-04","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, synthetic lubricants, fuels, diesel, gasoline, hydraulic oils, phosphate ester fluids, silicone oils and greases, diester lubricants, aromatic hydrocarbons, many chlorinated hydrocarbons, mild acids","Not Recommended For":"Ketones, amines, low molecular weight esters and ethers, hot hydrofluoric acids, strong alkalis, steam, hot water, glycol-based brake fluids"} Cross References: {"Aeroquip Part Number":"22068-4","Parker TFD Part Number":"3-904 FKM"}
D6504-L42-L06-SS
Connection Details: {"Side 1 Connection Type":"Female Metric Swivel","Side 1 Tube OD":"42mm","Side 1 Thread Type":"M52X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line Connection","Side 1 DIN Pressure Series":"Light","Side 1 Replacement Seal":"M4000-42-VITON","Side 2 Connection Type":"DIN Tube","Side 2 Tube OD":"6mm","Side 2 Thread Type":"M12X1.5","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Tube Connection","Side 2 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Straight","Shape Type":"Swivel Reducer","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Hex/Wrench":"50mm","Weight":"1.97 lb"}
9224-L-20-20
Connection Details: {"Side 1 Connection Type":"Male BSPP 60° Line Only","Side 1 Thread Type":"G - 1-1/4-11","Side 1 Standard":"ISO 8434-6, ISO 1179","Side 1 Role":"Line Connection","Side 2 Connection Type":"Female BSPP Swivel","Side 2 Thread Type":"G - 1-1/4-11","Side 2 Standard":"ISO 8434-6","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"90° Swept Elbow","Shape Type":"Swivel Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"1.969","Weight":"1.53 lb"}
4008-14
Specifications: {"Nominal OD":"7/8\"","Exact OD":"1.28\"","Exact ID":"1.047\"","Exact Width":"0.116\"","Color":"Black","Seal Code":"EPDM","Seal Material":"Ethylene Propylene","Temperature":"°F to °F","Dash Number":"-914","Dash Size":"-14","Seal Hardness":"80 durometer"} Application & Performance: {"Chemical Resistance":"Water, hot water, steam, glycol-based brake fluids, phosphate ester hydraulic fluids, alcohols, ketones, dilute acids, dilute alkalis, ozone, weathering","Not Recommended For":"Petroleum oils, mineral oils, fuels, diesel, gasoline, diester lubricants, aromatic hydrocarbons, chlorinated hydrocarbons"}
M4000-14-VITON
Specifications: {"Exact OD":"16mm","Exact ID":"12mm","Exact Width":"2mm","Color":"Green","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Temperature":"°F to °F","Dash Size":"-M14","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, synthetic lubricants, fuels, diesel, gasoline, hydraulic oils, phosphate ester fluids, silicone oils and greases, diester lubricants, aromatic hydrocarbons, many chlorinated hydrocarbons, mild acids","Not Recommended For":"Ketones, amines, low molecular weight esters and ethers, hot hydrofluoric acids, strong alkalis, steam, hot water, glycol-based brake fluids"}
FS7640-08-26-O
Connection Details: {"Side 1 Connection Type":"Male ORFS","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"13/16-16 UNF","Side 1 Standard":"SAE J1453 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 1 Replacement Seal":"FS4000-08","Side 2 Connection Type":"Male Metric ORB","Side 2 Thread Type":"M26X1.5","Side 2 Standard":"ISO 6149","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"8900-26"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"1.250","Weight":"0.32 lb"}
D2603-L22-L22-L12
Connection Details: {"Side 1 Connection Type":"DIN Tube","Side 1 Tube OD":"22mm","Side 1 Thread Type":"M30X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"DIN Tube","Side 2 Tube OD":"22mm","Side 2 Thread Type":"M30X2.0","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Tube Connection","Side 2 DIN Pressure Series":"Light","Side 3 Connection Type":"DIN Tube","Side 3 Tube OD":"12mm","Side 3 Thread Type":"M18X1.5","Side 3 Standard":"DIN 2353, ISO 8434-1","Side 3 Role":"Tube Connection","Side 3 DIN Pressure Series":"Light"} Body & Materials: {"Shape":"Tee","Shape Type":"Reducer Union Tee","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Hex/Wrench":"27mm","Weight":"0.97 lb"}
5500-12-06-FG
Connection Details: {"Side 1 Connection Type":"Male NPTF 30°","Side 1 Pipe Size":"3/4\"","Side 1 Thread Type":"3/4-14 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Line/Pipe Connection","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.41 lb"}
