Let-Lok Cap 7108LSS14MM
Connection Details: {"Connection Type":"Double Ferrule Compression","Tube OD":"14mm","Thread Type":"7/8-20 UNEF","Tube Fitting System":"Ham-let Let-Lok Series","Replacement Ferrule":"760LFSS14MM | 760LBSS14MM","Replacement Nut":"761LSS14MM"} Body & Materials: {"Shape":"Cap","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"24mm","Overall Length/Centerline":"29.9mm","Weight":"0.176 lb"}
768LRB4MMX1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"4mm","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB4MM | 760LBB4MM","Side 1 Replacement Nut":"761LB4MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Length":"31.2mm"} Dimensions: {"Hex/Wrench":"12mm","Overall Length/Centerline":"31.2mm","Weight":"0.051 lb"}
Male Elbow N7202-08-06-NWO-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-08-SS | N0319-B-08-SS","Side 1 Replacement Nut":"N0318-08-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male Adjustable BSPP ORR","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"9901-06","Side 2 Replacement Washer":"9200-06-SS"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.02\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.02\"","Weight":"0.4179 lb"}
768LB15MMX1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"15mm","Side 1 Thread Type":"7/8-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB15MM | 760LBB15MM","Side 1 Replacement Nut":"761LB15MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Length":"49mm"} Dimensions: {"Hex/Wrench":"24mm","Overall Length/Centerline":"49mm","Weight":"0.243 lb"}
770LB3/4X3/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/4 | 760LBB3/4","Side 1 Replacement Nut":"761LB3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Brass","Length":"1.36\""} Dimensions: {"Hex/Wrench":"1.375\"","Overall Length/Centerline":"1.36\"","Weight":"0.838 lb"}
SAE J518 Code 61 Split Flange Kit 1901-32-SS
Flange Kit Components: {"Flange Part Number":"1951-32-SS","Flange Size":"2\"","Bolt Type":"Hex Head","Bolt Screw Size":"1/2-13","Bolt Grade":"Grade 8","Bolt Material":"Stainless Steel","Bolt Quantity":"4","Washer Type":"Lock Washer","Washer Material":"Stainless Steel","Washer Quantity":"4","O-Ring Part Number":"4005-32","O-Ring Dash Size":"-32","O-Ring Dash Number":"-228","O-Ring Quantity":"1"} Cross References: {"Parker Hose Part Number":"5151HK-32-SS","Parker TFD Part Number":"32FCS1SSK"} Series Configuration: Code 61 Split Flange Kit
Long Hex Nipple 113HB1X3
Connection Details: {"Side 1 Connection Type":"Male NPT","Side 1 Pipe Size":"1\"","Side 1 Thread Type":"1-11-1/2 NPT","Side 1 Standard":"ASME/ANSI B1.20.1","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1\"","Side 2 Thread Type":"1-11-1/2 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Long Hex Nipple","Primary Material":"Brass"} Dimensions: {"Hex/Wrench":"1.375\"","Overall Length/Centerline":"3\"","Weight":"1.676 lb"}
768LGB8MMX1/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"8mm","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 1/4-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Surface Treatment":"Oxygen Clean","Length":"38.5mm"} Dimensions: {"Hex/Wrench":"19mm","Overall Length/Centerline":"38.5mm","Weight":"0.11 lb"}
768LRSS1/4X1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/4 | 760LBSS1/4","Side 1 Replacement Nut":"761LSS1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.29\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"1.29\"","Weight":"0.053 lb"}
Union Reducer 763LSS10MMX6MM
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"10mm","Side 1 Thread Type":"5/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS10MM | 760LBSS10MM","Side 1 Replacement Nut":"761LSS10MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"6mm","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFSS6MM | 760LBSS6MM","Side 2 Replacement Nut":"761LSS6MM","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Reducer","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"18mm","Overall Length/Centerline":"44.5mm","Weight":"0.126 lb"}
7108LSS1/8
Connection Details: {"Connection Type":"Double Ferrule Compression","Tube OD":"1/8\"","Thread Type":"5/16-20 UN","Tube Fitting System":"Ham-let Let-Lok Series","Replacement Ferrule":"760LFSS1/8 | 760LBSS1/8","Replacement Nut":"761LSS1/8"} Body & Materials: {"Shape":"Cap","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.79\""} Dimensions: {"Hex/Wrench":"0.4375\"","Overall Length/Centerline":"0.79\"","Weight":"0.025 lb"}
771LFSS12MMX3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS12MM | 760LBSS12MM","Side 1 Replacement Nut":"761LSS12MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"12mm","Side 3 Thread Type":"3/4-20 UNEF","Side 3 Role":"Tube Connection","Side 3 Replacement Ferrule":"760LFSS12MM | 760LBSS12MM","Side 3 Replacement Nut":"761LSS12MM","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Female Run Tee","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"25.9mm"} Dimensions: {"Hex/Wrench":"23.8mm","Overall Length/Centerline":"25.9mm","Weight":"0.4809 lb"}
769HLSS1/4X1/4
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760HLSS1/4","Side 1 Replacement Nut":"761LSS1/4","Side 1 Tube Fitting System":"Ham-let One-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.77\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.77\"","Weight":"0.088 lb"}
770LB1/4X1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/4 | 760LBB1/4","Side 1 Replacement Nut":"761LB1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Brass","Length":"0.88\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.88\"","Weight":"0.163 lb"}
Union Connector NS2403-16-16-SS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1\"","Side 1 Thread Type":"1-5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"NS0319-16-SS","Side 1 Replacement Nut":"N0318-16-SS","Side 1 Tube Fitting System":"Brennan NS Series","Side 2 Connection Type":"Single Ferrule Compression","Side 2 Tube OD":"1\"","Side 2 Thread Type":"1-5/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"NS0319-16-SS","Side 2 Replacement Nut":"N0318-16-SS","Side 2 Tube Fitting System":"Brennan NS Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"2.55\""} Dimensions: {"Hex/Wrench":"1.375\"","Overall Length/Centerline":"2.55\"","Weight":"0.2271 lb"}
130HFSS3/16X1/4
Connection Details: {"Side 1 Connection Type":"Hose Connector","Side 1 Hose ID":"3/16\"","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.44\""} Dimensions: {"Hex/Wrench":"0.75\"","Overall Length/Centerline":"1.44\"","Weight":"0.22 lb"}
762LSS3/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/4 | 760LBSS3/4","Side 1 Replacement Nut":"761LSS3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"3/4\"","Side 2 Thread Type":"1-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFSS3/4 | 760LBSS3/4","Side 2 Replacement Nut":"761LSS3/4","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"2.11\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"2.11\"","Weight":"0.405 lb"}
768LSS1/2X1TC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/2 | 760LBSS1/2","Side 1 Replacement Nut":"761LSS1/2","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1\"","Side 2 Thread Type":"1-11-1/2 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Feature":"Thermo Couple","Length":"2.25\""} Dimensions: {"Hex/Wrench":"1.375\"","Overall Length/Centerline":"2.25\"","Weight":"0.571 lb"}
130HMSS3/4X3/4
Connection Details: {"Side 1 Connection Type":"Hose Connector","Side 1 Hose ID":"3/4\"","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"2.14\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"2.14\"","Weight":"0.265 lb"}
775LB3/8X1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/8 | 760LBB3/8","Side 1 Replacement Nut":"761LB3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"1/4\"","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead Union Reducer","Primary Material":"Brass","Length":"2.39\""} Dimensions: {"Hex/Wrench":"0.75\"","Overall Length/Centerline":"2.39\"","Weight":"1.72 lb"}
768LSS8MMX3/8OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"8mm","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"39.3mm"} Dimensions: {"Hex/Wrench":"18mm","Overall Length/Centerline":"39.3mm","Weight":"0.11 lb"}
