768LRB3/8X1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/8 | 760LBB3/8","Side 1 Replacement Nut":"761LB3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Length":"1.39\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"1.39\"","Weight":"0.09 lb"}
Bulkhead Male Connector N2706-LN-04-04-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-04-SS | N0319-B-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"2.13\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"2.13\"","Weight":"0.1893 lb"}
770LSS3/8X1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/8 | 760LBSS3/8","Side 1 Replacement Nut":"761LSS3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.13\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.13\"","Weight":"0.376 lb"}
768LRSS6MMX3/8LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"R - 3/8-19","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"38.4mm"} Dimensions: {"Hex/Wrench":"18mm","Overall Length/Centerline":"38.4mm","Weight":"0.11 lb"}
Union Connector 762LSS4MMOC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"4mm","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"4mm","Side 2 Thread Type":"3/8-20 UN","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean"} Dimensions: {"Hex/Wrench":"12mm","Overall Length/Centerline":"37.3mm","Weight":"0.0596 lb"}
771LB1/2X1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/2 | 760LBB1/2","Side 1 Replacement Nut":"761LB1/2","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"1/2\"","Side 3 Thread Type":"3/4-20 UNEF","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Male Run Tee","Primary Material":"Brass","Length":"1.02\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.02\"","Weight":"0.28 lb"}
Let-Lok Back Ferrule 760LBSS2MM
Connection Details: {"Connection Type":"Double Ferrule Compression Back Ferrule","Tube OD":"2mm","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Sleeve","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Weight":"0.01 lb"}
1929-62-32-32
Connection Details: {"Connection End Type":"Female ORB","Connection End Thread":"2-1/2-12 UN","Connection End Standard":"SAE J1926 - Class 2B","Connection End Role":"Port Connection","Flange Interface Sealing Type":"O-Ring Face","Flange Interface Code":"Code 62","Flange Interface Pad Size":"2\""} Body & Materials: {"Primary Material":"Steel","Material Grade":"C1020","Weight":"7.2648 lb"} Performance Specifications: {"Working Pressure":"2000 psi","Temperature Range":"-65°F to 500°F","Burst Pressure":"8000 psi","Burst Ratio":"4:1"}
768HLM1/2X3/8
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760HLM1/2","Side 1 Replacement Nut":"761LM1/2","Side 1 Tube Fitting System":"Ham-let One-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Nickel Alloy","Material Grade":"Alloy 400","Length":"1.71\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.71\"","Weight":"0.176 lb"}
Male Connector NS2404-08-02-SS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"NS0319-08-SS","Side 1 Replacement Nut":"N0318-08-SS","Side 1 Tube Fitting System":"Brennan NS Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"1.53\""} Dimensions: {"Hex/Wrench":"0.8125\"","Overall Length/Centerline":"1.53\"","Weight":"0.17 lb"}
768LNSS1/4X1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/4 | 760LBSS1/4","Side 1 Replacement Nut":"761LSS1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Pipe Weld","Side 2 Pipe Size":"1/8\"","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Weld Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.29\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"1.29\"","Weight":"0.044 lb"}
768LSS3/4X3/4TC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/4 | 760LBSS3/4","Side 1 Replacement Nut":"761LSS3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Feature":"Thermo Couple","Length":"1.99\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.99\"","Weight":"0.406 lb"}
760LFB1/8OC
Connection Details: {"Connection Type":"Double Ferrule Compression Front Ferrule","Tube OD":"1/8\"","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Sleeve","Primary Material":"Brass","Surface Treatment":"Oxygen Clean"} Dimensions: {"Weight":"0.01 lb"}
Female Connector N2405-01-02-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/16\"","Side 1 Thread Type":"10-32 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-01-SS | N0319-B-01-SS","Side 1 Replacement Nut":"N0318-01-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"0.96\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"0.96\"","Weight":"0.0312 lb"}
739LMOBSS3/8X9/1618
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"9/16-18 UNF","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.52\""} Dimensions: {"Hex/Wrench":"17.5mm","Overall Length/Centerline":"1.52\"","Weight":"0.249 lb"}
Nut N0318-06-B
Connection Details: {"Connection Type":"Double Ferrule Compression Tube Nut","Tube OD":"3/8\"","Thread Type":"9/16-20 UN","Standard":"ASME B31.3","Connection Standard":"ASME B31.3","Tube Fitting System":"Brennan N & NS Series"} Body & Materials: {"Shape":"Nut","Primary Material":"Brass","Material Grade":"ASTM B16 C36000","Length":"0.56\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.56\"","Weight":"0.0417 lb"}
110HOBSS15/16X11/16
Connection Details: {"Side 1 Connection Type":"Male ORB","Side 1 Thread Type":"1-5/16-12 UN","Side 1 Standard":"SAE J1926","Side 1 Role":"Port Connection","Side 2 Connection Type":"Female ORB","Side 2 Thread Type":"1-1/16-12 UN","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Reducer Bushing","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Weight":"0.441 lb"}
Union Reducer Tee N2603-16-06-06-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1\"","Side 1 Thread Type":"1-5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-16-SS | N0319-B-16-SS","Side 1 Replacement Nut":"N0318-16-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"3/8\"","Side 2 Thread Type":"9/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"N0319-F-06-SS | N0319-B-06-SS","Side 2 Replacement Nut":"N0318-06-SS","Side 2 Tube Fitting System":"Brennan N Series","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"3/8\"","Side 3 Thread Type":"9/16-20 UN","Side 3 Role":"Tube Connection","Side 3 Replacement Ferrule":"N0319-F-06-SS | N0319-B-06-SS","Side 3 Replacement Nut":"N0318-06-SS","Side 3 Tube Fitting System":"Brennan N Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Union Reducer Tee","Primary Material":"Stainless Steel","Material Grade":"316L"} Dimensions: {"Hex/Wrench":"1.417\"","Weight":"0.6994 lb"}
Bulkhead Union 774LSS4MM
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"4mm","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS4MM | 760LBSS4MM","Side 1 Replacement Nut":"761LSS4MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"4mm","Side 2 Thread Type":"3/8-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFSS4MM | 760LBSS4MM","Side 2 Replacement Nut":"761LSS4MM","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead Union","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"14mm","Overall Length/Centerline":"53.6mm","Weight":"0.099 lb"}
