766LRSS6MMX1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS6MM | 760LBSS6MM","Side 1 Replacement Nut":"761LSS6MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"31.3mm"} Dimensions: {"Hex/Wrench":"14mm","Overall Length/Centerline":"31.3mm","Weight":"0.066 lb"}
766LGSS12MMX3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS12MM | 760LBSS12MM","Side 1 Replacement Nut":"761LSS12MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female BSPP","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"44.4mm"} Dimensions: {"Hex/Wrench":"24mm","Overall Length/Centerline":"44.4mm","Weight":"0.22 lb"}
764LSS3/16
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/16\"","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/16 | 760LBSS3/16","Side 1 Replacement Nut":"761LSS3/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"3/16\"","Side 2 Thread Type":"3/8-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"760LFSS3/16 | 760LBSS3/16","Side 2 Replacement Nut":"761LSS3/16","Side 2 Tube Fitting System":"Ham-let Let-Lok Series","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"3/16\"","Side 3 Thread Type":"3/8-20 UN","Side 3 Role":"Tube Connection","Side 3 Replacement Ferrule":"760LFSS3/16 | 760LBSS3/16","Side 3 Replacement Nut":"761LSS3/16","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Union Tee","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.7\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.7\"","Weight":"0.22 lb"}
Union Elbow NS2500-04-02-SS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"NS0319-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan NS Series","Side 2 Connection Type":"Single Ferrule Compression","Side 2 Tube OD":"1/8\"","Side 2 Thread Type":"5/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"NS0319-02-SS","Side 2 Replacement Nut":"N0318-02-SS","Side 2 Tube Fitting System":"Brennan NS Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"0.77\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.77\"","Weight":"0.2728 lb"}
766LGB1/2X3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/2 | 760LBB1/2","Side 1 Replacement Nut":"761LB1/2","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female BSPP","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Brass","Length":"1.75\""} Dimensions: {"Hex/Wrench":"0.9375\"","Overall Length/Centerline":"1.75\"","Weight":"0.243 lb"}
769HLGSS8MMX1/4POS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"8mm","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760HLSS8MM","Side 1 Replacement Nut":"761LSS8MM","Side 1 Tube Fitting System":"Ham-let One-Lok Series","Side 2 Connection Type":"Male Adjustable BSPP ORR","Side 2 Thread Type":"G - 1/4-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"22.4mm"} Dimensions: {"Hex/Wrench":"15.9mm","Overall Length/Centerline":"22.4mm","Weight":"0.185 lb"}
Union Reducer Tee 764LRSS12MMX12MMX6MMLF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"12mm","Side 2 Thread Type":"3/4-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"6mm","Side 3 Thread Type":"7/16-20 UNF","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Union Reducer Tee","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free"} Dimensions: {"Hex/Wrench":"20.6mm","Overall Length/Centerline":"25.9mm","Weight":"0.375 lb"}
Let-Lok Cap 7108LB12MM
Connection Details: {"Connection Type":"Double Ferrule Compression","Tube OD":"12mm","Thread Type":"3/4-20 UNEF","Tube Fitting System":"Ham-let Let-Lok Series","Replacement Ferrule":"760LFB12MM | 760LBB12MM","Replacement Nut":"761LB12MM"} Body & Materials: {"Shape":"Cap","Primary Material":"Brass"} Dimensions: {"Hex/Wrench":"22mm","Overall Length/Centerline":"29.1mm","Weight":"0.143 lb"}
7121LM1/2
Connection Details: {"Connection Type":"Double Ferrule Compression Plug","Tube OD":"1/2\"","Thread Type":"3/4-20 UNEF","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Plug","Primary Material":"Nickel Alloy","Material Grade":"Alloy 400"} Dimensions: {"Hex/Wrench":"0.875\"","Weight":"0.088 lb"}
760LISS1/2X3/8OC
Connection Details: {"Connection Type":"Double Ferrule Tube Insert","Tube OD":"1/2\"","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Insert","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean"} Dimensions: {"Weight":"0.11 lb"}
768LB12MMX1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB12MM | 760LBB12MM","Side 1 Replacement Nut":"761LB12MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Length":"38.8mm"} Dimensions: {"Hex/Wrench":"22mm","Overall Length/Centerline":"38.8mm","Weight":"0.154 lb"}
768LSS3/16X1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/16\"","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/16 | 760LBSS3/16","Side 1 Replacement Nut":"761LSS3/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.43\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"1.43\"","Weight":"0.19 lb"}
Bulkhead Male Flared Connector N2707-LN-04-04-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-04-SS | N0319-B-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"1/4\"","Side 2 Thread Type":"7/16-20 UNF","Side 2 Standard":"SAE J514","Side 2 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead Male Flared Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"2.12\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"2.12\"","Weight":"0.1332 lb"}
SAE J518 Code 62 Split Flange Pair 1952-08
Connection Details: {"Flange Interface Code":"Code 62","Flange Interface Flange Size":"1/2\""} Body & Materials: {"Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Weight":"0.3704 lb"} Performance Specifications: {"Working Pressure":"6000 psi","Temperature Range":"-65°F to 500°F","Corrosion Resistance":"120 hrs no white rust; 240 hrs no red rust per ASTM B117","Burst Pressure":"24000 psi","Burst Ratio":"4:1"}
768LB3/8X1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/8 | 760LBB3/8","Side 1 Replacement Nut":"761LB3/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Brass","Length":"1.39\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"1.39\"","Weight":"0.098 lb"}
768LSS1/16X1/16
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/16\"","Side 1 Thread Type":"3/16-32 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/16 | 760LBSS1/16","Side 1 Replacement Nut":"761LSS1/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/16\"","Side 2 Thread Type":"1/16-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.94\""} Dimensions: {"Hex/Wrench":"0.3125\"","Overall Length/Centerline":"0.94\"","Weight":"0.022 lb"}
768LRSS4MMX1/8TC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"4mm","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS4MM | 760LBSS4MM","Side 1 Replacement Nut":"761LSS4MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Feature":"Thermo Couple","Length":"31.2mm"} Dimensions: {"Hex/Wrench":"12mm","Overall Length/Centerline":"31.2mm","Weight":"0.044 lb"}
766LSS6MMX1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"35.8mm"} Dimensions: {"Hex/Wrench":"19mm","Overall Length/Centerline":"35.8mm","Weight":"0.11 lb"}
Female Elbow N2502-08-08-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-08-SS | N0319-B-08-SS","Side 1 Replacement Nut":"N0318-08-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"1.13\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.13\"","Weight":"0.5959 lb"}
Let-Lok Back Ferrule 760LBSS22MM
Connection Details: {"Connection Type":"Double Ferrule Compression Back Ferrule","Tube OD":"22mm","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Sleeve","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Weight":"0.0119 lb"}
768LGSS1/2X3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/2 | 760LBSS1/2","Side 1 Replacement Nut":"761LSS1/2","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.7\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"1.7\"","Weight":"0.175 lb"}
