767LTSS1/4X6MMOC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Tube Stub","Side 2 Tube OD":"6mm","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Reducer","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean"} Dimensions: {"Weight":"0.044 lb"}
762LB3/16
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/16\"","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/16 | 760LBB3/16","Side 1 Replacement Nut":"761LB3/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"3/16\"","Side 2 Thread Type":"3/8-20 UN","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Brass","Length":"1.47\""} Dimensions: {"Hex/Wrench":"0.4375\"","Overall Length/Centerline":"1.47\"","Weight":"0.063 lb"}
Union Elbow N2500-12-12-B
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-12-B | N0319-B-12-B","Side 1 Replacement Nut":"N0318-12-B","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"3/4\"","Side 2 Thread Type":"1-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"N0319-F-12-B | N0319-B-12-B","Side 2 Replacement Nut":"N0318-12-B","Side 2 Tube Fitting System":"Brennan N Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Brass","Material Grade":"ASTM B16 CA37700","Length":"1.17\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.17\"","Weight":"0.5413 lb"}
Male Connector N6400-06-10-O-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-06-SS | N0319-B-06-SS","Side 1 Replacement Nut":"N0318-06-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"7/8-14 UNF","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4000-10"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.66\""} Dimensions: {"Hex/Wrench":"1\"","Overall Length/Centerline":"1.66\"","Weight":"0.2 lb"}
Union Connector NS2403-24-24-SS
Connection Details: {"Side 1 Connection Type":"Single Ferrule Compression","Side 1 Tube OD":"1-1/2\"","Side 1 Thread Type":"1-15/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"NS0319-24-SS","Side 1 Replacement Nut":"N0318-24-SS","Side 1 Tube Fitting System":"Brennan NS Series","Side 2 Connection Type":"Single Ferrule Compression","Side 2 Tube OD":"1-1/2\"","Side 2 Thread Type":"1-15/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"NS0319-24-SS","Side 2 Replacement Nut":"N0318-24-SS","Side 2 Tube Fitting System":"Brennan NS Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"4.25\""} Dimensions: {"Hex/Wrench":"2.125\"","Overall Length/Centerline":"4.25\"","Weight":"0.2174 lb"}
Male Connector N7013-16-12-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1\"","Side 1 Thread Type":"1-5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-16-SS | N0319-B-16-SS","Side 1 Replacement Nut":"N0318-16-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 3/4-14","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L"} Dimensions: {"Hex/Wrench":"1.417\"","Weight":"0.2138 lb"}
761LB3/4
Connection Details: {"Connection Type":"Double Ferrule Tube Nut","Tube OD":"3/4\"","Thread Type":"1-20 UNEF","Tube Fitting System":"Ham-let Let-Lok & One-Lok Series"} Body & Materials: {"Shape":"Nut","Primary Material":"Brass","Length":"0.69\""} Dimensions: {"Hex/Wrench":"1.125\"","Overall Length/Centerline":"0.69\"","Weight":"0.082 lb"}
116HSS1/2X1/2
Connection Details: {"Side 1 Connection Type":"Female NPT","Side 1 Pipe Size":"1/2\"","Side 1 Thread Type":"1/2-14 NPT","Side 1 Standard":"ASME/ANSI B1.20.1","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Street Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.56\""} Dimensions: {"Hex/Wrench":"1.125\"","Overall Length/Centerline":"1.56\"","Weight":"0.54 lb"}
Union Connector 762LSS12MMOC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"12mm","Side 1 Thread Type":"3/4-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"12mm","Side 2 Thread Type":"3/4-20 UNEF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Union Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean"} Dimensions: {"Hex/Wrench":"22mm","Overall Length/Centerline":"51.2mm","Weight":"0.22 lb"}
771LB3/4X3/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/4 | 760LBB3/4","Side 1 Replacement Nut":"761LB3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"3/4\"","Side 3 Thread Type":"1-20 UNEF","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Male Run Tee","Primary Material":"Brass","Length":"1.17\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.17\"","Weight":"0.703 lb"}
739LMSS12MMX1/4OC
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"12mm","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"46.5mm"} Dimensions: {"Hex/Wrench":"16mm","Overall Length/Centerline":"46.5mm","Weight":"0.088 lb"}
768LSS3/4X3/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS3/4 | 760LBSS3/4","Side 1 Replacement Nut":"761LSS3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.99\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.99\"","Weight":"0.3 lb"}
Male Connector N7013-04-08-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-04-SS | N0319-B-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 1/2-14","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L"} Dimensions: {"Hex/Wrench":"0.866\"","Weight":"0.2008 lb"}
1990-40-08X2.75
Flange Kit Components: {"Flange Code":"Code 61 & Code 62","Bolt Grade":"Grade 8","Bolt Material":"Steel","Bolt Quantity":"4","Washer Material":"Steel","Washer Quantity":"4","O-Ring Part Number":"4005-40","O-Ring Dash Size":"-40","O-Ring Dash Number":"-232","O-Ring Quantity":"1"} Series Configuration: Code 61/62 Flange Hardware Kit w/Socket Head Bolts Technical Series Configuration: SAE J518 Code 61/62 Flange Hardware Kit with Socket Head Bolts
Let-Lok Front Ferrule 760LFSS8MM
Connection Details: {"Connection Type":"Double Ferrule Compression Front Ferrule","Tube OD":"8mm","Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Sleeve","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Weight":"0.01 lb"}
739LFSS1/2X1/4OC
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/2\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"1.71\""} Dimensions: {"Hex/Wrench":"0.75\"","Overall Length/Centerline":"1.71\"","Weight":"0.088 lb"}
Union Tee 764LB6MM
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB6MM | 760LBB6MM","Side 1 Replacement Nut":"761LB6MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"6mm","Side 2 Thread Type":"7/16-20 UNF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series","Side 3 Connection Type":"Double Ferrule Compression","Side 3 Tube OD":"6mm","Side 3 Thread Type":"7/16-20 UNF","Side 3 Role":"Tube Connection","Side 3 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"Tee","Shape Type":"Union Tee","Primary Material":"Brass"} Dimensions: {"Hex/Wrench":"12.7mm","Overall Length/Centerline":"19.6mm","Weight":"0.154 lb"}
768LGSS1/4X3/8OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 3/8-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"1.5\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"1.5\"","Weight":"0.11 lb"}
Bulkhead Union N2700-LN-16-16-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1\"","Side 1 Thread Type":"1-5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-16-SS | N0319-B-16-SS","Side 1 Replacement Nut":"N0318-16-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"1\"","Side 2 Thread Type":"1-5/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Replacement Ferrule":"N0319-F-16-SS | N0319-B-16-SS","Side 2 Replacement Nut":"N0318-16-SS","Side 2 Tube Fitting System":"Brennan N Series"} Body & Materials: {"Shape":"Straight","Shape Type":"Bulkhead Union","Primary Material":"Stainless Steel","Material Grade":"316L"} Dimensions: {"Hex/Wrench":"1.625\"","Weight":"0.9812 lb"}
768LGSS10MMX1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"10mm","Side 1 Thread Type":"5/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPP (Type D)","Side 2 Thread Type":"G - 1/4-19","Side 2 Standard":"ISO 1179","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"39.4mm"} Dimensions: {"Hex/Wrench":"19mm","Overall Length/Centerline":"39.4mm","Weight":"0.11 lb"}
120HRNB1/2
Connection Details: {"Side 1 Connection Type":"Female BSPT","Side 1 Pipe Size":"1/2\"","Side 1 Thread Type":"R - 1/2-14","Side 1 Standard":"ISO 7-1","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Adapter","Primary Material":"Brass","Length":"1.96\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.96\"","Weight":"0.309 lb"}
