561 matching products
Clear
769LB15MMX1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"15mm","Side 1 Thread Type":"7/8-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB15MM | 760LBB15MM","Side 1 Replacement Nut":"761LB15MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"27.9mm"} Dimensions: {"Hex/Wrench":"23.8mm","Overall Length/Centerline":"27.9mm","Weight":"0.392 lb"}
769LSS1/8X1/4LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/8\"","Side 1 Thread Type":"5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"0.71\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.71\"","Weight":"0.176 lb"}
769LTSS15MMX15MM
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"15mm","Side 1 Thread Type":"7/8-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS15MM | 760LBSS15MM","Side 1 Replacement Nut":"761LSS15MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Tube Stub","Side 2 Tube OD":"15mm","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Reducer Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated"} Dimensions: {"Hex/Wrench":"28.6mm","Overall Length/Centerline":"27.9mm","Weight":"0.831 lb"}
769LSS3/8X1/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"0.91\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"0.91\"","Weight":"0.198 lb"}
N2502-04-04-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-04-SS | N0319-B-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"0.88\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.88\"","Weight":"0.2466 lb"}
765LSS3/8LF
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"3/8\"","Side 2 Thread Type":"9/16-20 UN","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Lubricant Free","Length":"0.91\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"0.91\"","Weight":"0.163 lb"}
769LRB6MMX3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB6MM | 760LBB6MM","Side 1 Replacement Nut":"761LB6MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"R - 3/8-19","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"22.4mm"} Dimensions: {"Hex/Wrench":"17.5mm","Overall Length/Centerline":"22.4mm","Weight":"0.231 lb"}
770LSS1/4X1/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"0.88\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.88\"","Weight":"0.198 lb"}
769LSS3/4X3/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"1.17\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.17\"","Weight":"0.461 lb"}
765LB5/16
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"5/16\"","Side 1 Thread Type":"1/2-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB5/16 | 760LBB5/16","Side 1 Replacement Nut":"761LB5/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"5/16\"","Side 2 Thread Type":"1/2-20 UNF","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Brass","Length":"0.84\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"0.84\"","Weight":"0.154 lb"}
769LB1/8X1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/8\"","Side 1 Thread Type":"5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/8 | 760LBB1/8","Side 1 Replacement Nut":"761LB1/8","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"0.71\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.71\"","Weight":"0.097 lb"}
769LB6MMX1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB6MM | 760LBB6MM","Side 1 Replacement Nut":"761LB6MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"19.6mm"} Dimensions: {"Hex/Wrench":"12.7mm","Overall Length/Centerline":"19.6mm","Weight":"0.132 lb"}
769LRB3MMX1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3mm","Side 1 Thread Type":"5/16-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3MM | 760LBB3MM","Side 1 Replacement Nut":"761LB3MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"17mm"} Dimensions: {"Hex/Wrench":"11.1mm","Overall Length/Centerline":"17mm","Weight":"0.044 lb"}
769LTSS1/4X1/2
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/4 | 760LBSS1/4","Side 1 Replacement Nut":"761LSS1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Tube Stub","Side 2 Tube OD":"1/2\"","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Reducer Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.91\""} Dimensions: {"Hex/Wrench":"0.625\"","Overall Length/Centerline":"0.91\"","Weight":"0.11 lb"}
770LB3/4X3/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-20 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB3/4 | 760LBB3/4","Side 1 Replacement Nut":"761LB3/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Brass","Length":"1.36\""} Dimensions: {"Hex/Wrench":"1.375\"","Overall Length/Centerline":"1.36\"","Weight":"0.838 lb"}
770LB1/4X1/4
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/4 | 760LBB1/4","Side 1 Replacement Nut":"761LB1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Brass","Length":"0.88\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.88\"","Weight":"0.163 lb"}
770LSS1/4X3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFSS1/4 | 760LBSS1/4","Side 1 Replacement Nut":"761LSS1/4","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Female Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.96\""} Dimensions: {"Hex/Wrench":"0.9375\"","Overall Length/Centerline":"0.96\"","Weight":"0.254 lb"}
769LB6MMX3/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB6MM | 760LBB6MM","Side 1 Replacement Nut":"761LB6MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"22.4mm"} Dimensions: {"Hex/Wrench":"17.5mm","Overall Length/Centerline":"22.4mm","Weight":"0.174 lb"}
765LB4MM
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"4mm","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB4MM | 760LBB4MM","Side 1 Replacement Nut":"761LB4MM","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Double Ferrule Compression","Side 2 Tube OD":"4mm","Side 2 Thread Type":"3/8-20 UN","Side 2 Role":"Tube Connection","Side 2 Tube Fitting System":"Ham-let Let-Lok Series"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Brass"} Dimensions: {"Hex/Wrench":"12.7mm","Overall Length/Centerline":"18.8mm","Weight":"0.106 lb"}
N2525-04-04-SS
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/4\"","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"N0319-F-04-SS | N0319-B-04-SS","Side 1 Replacement Nut":"N0318-04-SS","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Pipe Weld","Side 2 Pipe Size":"1/4\"","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Pipe Weld Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"0.77\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.77\"","Weight":"0.1253 lb"}
N2501-03-02-B
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"3/16\"","Side 1 Thread Type":"3/8-20 UN","Side 1 Role":"Tube Connection","Side 1 Replacement Nut":"N0318-03-B","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Material Grade":"ASTM B124 CA37700","Length":"0.74\""} Dimensions: {"Hex/Wrench":"0.5\"","Overall Length/Centerline":"0.74\"","Weight":"0.1275 lb"}
769LB1/16X1/8
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"1/16\"","Side 1 Thread Type":"3/16-32 UNEF","Side 1 Role":"Tube Connection","Side 1 Replacement Ferrule":"760LFB1/16 | 760LBB1/16","Side 1 Replacement Nut":"761LB1/16","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Brass","Length":"0.6\""} Dimensions: {"Hex/Wrench":"0.4375\"","Overall Length/Centerline":"0.6\"","Weight":"0.055 lb"}
769LRSS6MMX1/4OC
Connection Details: {"Side 1 Connection Type":"Double Ferrule Compression","Side 1 Tube OD":"6mm","Side 1 Thread Type":"7/16-20 UNF","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"R - 1/4-19","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"19.6mm"} Dimensions: {"Hex/Wrench":"12.7mm","Overall Length/Centerline":"19.6mm","Weight":"0.132 lb"}
