301 matching products
Clear
N2429-08-08-SS
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/2\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"3/4-16 UNF","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4000-08"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.82\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"1.82\"","Weight":"0.1673 lb"}
739LFSS8MMX1/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"8mm","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"37.6mm"} Dimensions: {"Hex/Wrench":"19mm","Overall Length/Centerline":"37.6mm","Weight":"0.088 lb"}
739LNSS3/8X1/2
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Pipe Weld","Side 2 Pipe Size":"1/2\"","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.46\""} Dimensions: {"Overall Length/Centerline":"1.46\"","Weight":"0.088 lb"}
739LMB1/2X1/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/2\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Brass","Length":"1.75\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"1.75\"","Weight":"0.088 lb"}
739LFSS3/4X1
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1\"","Side 2 Thread Type":"1-11-1/2 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"2.3\""} Dimensions: {"Hex/Wrench":"1.625\"","Overall Length/Centerline":"2.3\"","Weight":"0.529 lb"}
739LMSS5/8X1/2
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"5/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"2.06\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"2.06\"","Weight":"0.159 lb"}
739LMRSS1/4X1/8
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male BSPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"R - 1/8-28","Side 2 Standard":"ISO 7-1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"31.8mm"} Dimensions: {"Hex/Wrench":"0.4375mm","Overall Length/Centerline":"31.8mm","Weight":"0.022 lb"}
739LFSS20MMX3/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"20mm","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"56mm"} Dimensions: {"Hex/Wrench":"35mm","Overall Length/Centerline":"56mm","Weight":"0.408 lb"}
739LMSS3MMX1/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3mm","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"35.3mm"} Dimensions: {"Hex/Wrench":"14mm","Overall Length/Centerline":"35.3mm","Weight":"0.0467 lb"}
N2430-05-04-SS
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"5/16\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"1.48\""} Dimensions: {"Hex/Wrench":"0.75\"","Overall Length/Centerline":"1.48\"","Weight":"0.1224 lb"}
739LMOBSS11/4X15/812
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1-1/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"1-5/8-12 UN","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"2.81\""} Dimensions: {"Hex/Wrench":"47.6mm","Overall Length/Centerline":"2.81\"","Weight":"1.257 lb"}
739LMOBSS3/8X9/1618
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male ORB","Side 2 Thread Type":"9/16-18 UNF","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Length":"1.52\""} Dimensions: {"Hex/Wrench":"17.5mm","Overall Length/Centerline":"1.52\"","Weight":"0.249 lb"}
N2428-06-06-SS
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"1.56\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"1.56\"","Weight":"0.0958 lb"}
739LMB3/8X1/8
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/8\"","Side 2 Thread Type":"1/8-27 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Brass","Length":"1.32\""} Dimensions: {"Hex/Wrench":"0.4375\"","Overall Length/Centerline":"1.32\"","Weight":"0.033 lb"}
N2428-08-08-SS
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/2\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Length":"2\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"2\"","Weight":"0.1969 lb"}
N2428-06-06-B
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Brennan N Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Brass","Material Grade":"ASTM B16 C36000","Length":"1.56\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"1.56\"","Weight":"0.1153 lb"}
739LMSS7/8X3/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"7/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"2.09\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"2.09\"","Weight":"0.245 lb"}
739LFSS8MMX1/2OC
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"8mm","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Oxygen Clean","Length":"46mm"} Dimensions: {"Hex/Wrench":"27mm","Overall Length/Centerline":"46mm","Weight":"0.216 lb"}
739LFSS1/2X3/8
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/2\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"3/8\"","Side 2 Thread Type":"3/8-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.79\""} Dimensions: {"Hex/Wrench":"0.875\"","Overall Length/Centerline":"1.79\"","Weight":"0.129 lb"}
739LMSS6MMX1/2
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"6mm","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"43.4mm"} Dimensions: {"Hex/Wrench":"22mm","Overall Length/Centerline":"43.4mm","Weight":"0.132 lb"}
739LMB1/4X1/4
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"1/4\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/4\"","Side 2 Thread Type":"1/4-18 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Brass","Length":"1.46\""} Dimensions: {"Hex/Wrench":"0.5625\"","Overall Length/Centerline":"1.46\"","Weight":"0.06 lb"}
761LFLSS3/8X3/8
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female JIC Swivel","Side 2 Tube OD":"3/8\"","Side 2 Thread Type":"9/16-18 UNF","Side 2 Standard":"SAE J514","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"0.98\""} Dimensions: {"Hex/Wrench":"0.6875\"","Overall Length/Centerline":"0.98\"","Weight":"0.088 lb"}
739LFSS3/8X1/2
Connection Details: {"Side 1 Connection Type":"Tube Stub","Side 1 Tube OD":"3/8\"","Side 1 Role":"Tube Connection","Side 1 Tube Fitting System":"Ham-let Let-Lok Series","Side 2 Connection Type":"Female NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ASME/ANSI B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Tube Adapter","Primary Material":"Stainless Steel","Material Grade":"316L","Surface Treatment":"Passivated","Length":"1.84\""} Dimensions: {"Hex/Wrench":"1.0625\"","Overall Length/Centerline":"1.84\"","Weight":"0.217 lb"}
