Brennan Product Browser
24,928Total
24,928Scraped
0Pending
24,928 matching products
Clear
Male Elbow D2501-L18-08-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"18mm","Side 1 Thread Type":"M26X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male NPT","Side 2 Pipe Size":"1/2\"","Side 2 Thread Type":"1/2-14 NPT","Side 2 Standard":"ANSI/ASME B1.20.1","Side 2 Role":"Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Elbow","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Hex/Wrench":"24mm","Weight":"0.28 lb"}
Male Branch Tee 2601-10-10-08-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"5/8\"","Side 1 Thread Type":"7/8-14 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"5/8\"","Side 2 Thread Type":"7/8-14 UNF","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection","Side 3 Connection Type":"Male NPTF 30°","Side 3 Pipe Size":"1/2\"","Side 3 Thread Type":"1/2-14 NPTF","Side 3 Standard":"SAE J476","Side 3 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"Tee","Shape Type":"Male Branch Tee","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"0.875","Weight":"0.39 lb"}
Reducer Union Tee D2603-S38-S38-S25-SS-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"38mm","Side 1 Thread Type":"M52X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Heavy","Side 2 Connection Type":"Male DIN","Side 2 Tube OD":"38mm","Side 2 Thread Type":"M52X2.0","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Line/Tube Connection","Side 2 DIN Pressure Series":"Heavy","Side 3 Connection Type":"Male DIN","Side 3 Tube OD":"25mm","Side 3 Thread Type":"M36X2.0","Side 3 Standard":"DIN 2353, ISO 8434-1","Side 3 Role":"Line/Tube Connection","Side 3 DIN Pressure Series":"Heavy"} Body & Materials: {"Shape":"Tee","Shape Type":"Reducer Union Tee","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"50mm","Weight":"2.55 lb"}
Ferrule C0319-32-SS
Connection Details: {"Connection Type":"Flareless Bite Type Sleeve","Tube OD":"2\"","Standard":"SAE J514","Connection Standard":"SAE J514","Role":"Tube Connection","Connection Role":"Tube Connection"} Body & Materials: {"Shape":"Sleeve","Shape Type":"Ferrule","Primary Material":"Stainless Steel","Material Grade":"17-4 PH","Surface Treatment":"Heat Treated and Passivated"} Dimensions: {"Weight":"0.05 lb"}
ORFS O-Ring FS4000-10-PC
Specifications: {"Nominal OD":"3/4\"","Exact OD":"0.754\"","Exact ID":"0.614\"","Exact Width":"0.07\"","Color":"Black with blue dot","Seal Code":"HNBR","Seal Material":"Hydrogenated Nitrile","Temperature":"°F to °F","Dash Number":"-016","Dash Size":"-10","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, fuels, diesel, gasoline, hydraulic fluids, water (moderate temperatures), ozone, weathering, sour gas, amines","Not Recommended For":"Phosphate ester fluids, strong acids, chlorinated hydrocarbons, ketones, esters, high concentrations of aromatic hydrocarbons"}
Male Adapter 1700-24-16
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"1-1/2\"","Side 1 Thread Type":"1-7/8-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Split Flange Head","Side 2 Flange Size":"1\"","Side 2 Standard":"SAE J518","Side 2 Role":"Flange Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Adapter","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"1.36 lb"}
Male Cross 2651-16-16-16-16-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"1\"","Side 1 Thread Type":"1-5/16-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male NPTF 30°","Side 2 Pipe Size":"1\"","Side 2 Thread Type":"1-11-1/2 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection","Side 3 Connection Type":"Male JIC","Side 3 Tube OD":"1\"","Side 3 Thread Type":"1-5/16-12 UN","Side 3 Standard":"SAE J514 - Class 2A Thread","Side 3 Role":"Line/Tube Connection","Side 4 Connection Type":"Male JIC","Side 4 Tube OD":"1\"","Side 4 Thread Type":"1-5/16-12 UN","Side 4 Standard":"SAE J514 - Class 2A Thread","Side 4 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Cross","Shape Type":"Male Cross","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"1.11 lb"}
Code 61 Flange Hardware Kit 1900-61-20-K-SS
Flange Kit Components: {"Bolt Type":"Hex Head","Bolt Material":"Stainless Steel","Bolt Quantity":"4","Washer Type":"Lock Washer","Washer Material":"Stainless Steel","Washer Quantity":"4","O-Ring Part Number":"4005-20","O-Ring Quantity":"1"} Series Configuration: Code 61 Flange Hardware Kit w/Hex Bolts Technical Series Configuration: SAE J518 Code 61 Flange Hardware Kit with Hex Bolts
Union Cross 2650-06-08-06-08-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"3/8\"","Side 1 Thread Type":"9/16-18 UNF","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"1/2\"","Side 2 Thread Type":"3/4-16 UNF","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection","Side 3 Connection Type":"Male JIC","Side 3 Tube OD":"3/8\"","Side 3 Thread Type":"9/16-18 UNF","Side 3 Standard":"SAE J514 - Class 2A Thread","Side 3 Role":"Line/Tube Connection","Side 4 Connection Type":"Male JIC","Side 4 Tube OD":"1/2\"","Side 4 Thread Type":"3/4-16 UNF","Side 4 Standard":"SAE J514 - Class 2A Thread","Side 4 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Cross","Shape Type":"Union Cross","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.19 lb"}
Coupling D2425-L08-08-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"8mm","Side 1 Thread Type":"M14X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Tube Weld","Side 2 Tube OD":"8mm","Side 2 Role":"Weld Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Coupling","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel"} Dimensions: {"Weight":"0.03 lb"}
SAE J518 Code 61 Split Flange Kit 1901-32-VITON
Flange Kit Components: {"Flange Part Number":"1951-32","Flange Size":"2\"","Bolt Type":"Hex Head","Bolt Screw Size":"1/2-13","Bolt Grade":"Grade 8","Bolt Material":"Steel","Bolt Quantity":"4","Washer Type":"Lock Washer","Washer Material":"Steel","Washer Quantity":"4","O-Ring Part Number":"4005-32-VITON","O-Ring Dash Size":"-32","O-Ring Dash Number":"-228","O-Ring Quantity":"1"} Cross References: {"Aeroquip Part Number":"FF687-32"} Series Configuration: Code 61 Split Flange Kit
BSPP Bonded Seal Swivel Connector 7022-12-12-SS-BS
Connection Details: {"Side 1 Connection Type":"Female JIC Swivel","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-1/16-12 UN","Side 1 Standard":"SAE J514 - Class 2B Thread","Side 1 Role":"Line Connection","Side 2 Connection Type":"Male BSPP 60° Line/Port","Side 2 Thread Type":"G - 3/4-14","Side 2 Standard":"ISO 8434-6, ISO 1179","Side 2 Role":"Line/Port Connection","Side 2 Replacement Gasket":"9900-12"} Body & Materials: {"Shape":"Straight","Primary Material":"Stainless Steel","Material Grade":"316/316L","Surface Treatment":"Passivated","Feature":"Bonded Seal","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"1.260","Weight":"0.34 lb"}
Union 2403-LH-16-10
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Union","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.45 lb"}
Union Elbow 2500-12-08-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-1/16-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male JIC","Side 2 Tube OD":"1/2\"","Side 2 Thread Type":"3/4-16 UNF","Side 2 Standard":"SAE J514 - Class 2A Thread","Side 2 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Union Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Weight":"0.46 lb"}
Swivel Elbow 9204-16-16
Connection Details: {"Side 1 Connection Type":"Male BSPT","Side 1 Pipe Size":"1\"","Side 1 Thread Type":"R - 1-11","Side 1 Standard":"ISO 7-1","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Female BSPP Swivel","Side 2 Thread Type":"G - 1-11","Side 2 Standard":"ISO 8434-6","Side 2 Role":"Line Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Swivel Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"1.614","Weight":"1.01 lb"}
Male Connector FS0403-16-12-SS
Connection Details: {"Side 1 Connection Type":"Bore","Side 1 Tube OD":"1\"","Side 1 Standard":"Not Defined","Side 1 Role":"Tube Connection","Side 2 Connection Type":"Male ORFS","Side 2 Tube OD":"3/4\"","Side 2 Thread Type":"1-3/16-12 UN","Side 2 Standard":"SAE J1453 - Class 2A Thread","Side 2 Role":"Line/Tube Connection","Side 2 Replacement Seal":"FS4000-12"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Stainless Steel","Material Grade":"316/316L","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Weight":"0.40 lb"}
Male Connector D7400-L06-04-ED-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"6mm","Side 1 Thread Type":"M12X1.5","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male BSPP ED Seal","Side 2 Thread Type":"G - 1/4-19","Side 2 Standard":"DIN 3852-11, ISO 1179-2","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"ED4000-04"} Body & Materials: {"Shape":"Straight","Shape Type":"Male Connector","Primary Material":"Steel","Material Grade":"11SMnPb30","Plating":"Zinc Nickel","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"19mm","Weight":"0.07 lb"}
Flange O-Ring 4005-12
Specifications: {"Nominal OD":"3/4\"","Exact OD":"1.264\"","Exact ID":"0.984\"","Exact Width":"0.139\"","Color":"Black","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)","Temperature":"-40°F to 250°F","Dash Number":"-214","Dash Size":"-12","Seal Hardness":"90 Durometer"} Application & Performance: {"Chemical Resistance":"Petroleum oils, mineral oils, fuels, diesel, gasoline, hydraulic fluids, aliphatic hydrocarbons, water (below 150°F), natural gas, air","Not Recommended For":"Phosphate ester fluids, glycol-based brake fluids, strong acids, ozone, weathering, ketones, esters, chlorinated hydrocarbons"} Cross References: {"Aeroquip Part Number":"FF9446-214","Parker Hose Part Number":"711510-5","Parker TFD Part Number":"2-214 N0552"}
Adapter 7002-24-20
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"1-1/2\"","Side 1 Thread Type":"1-7/8-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male BSPP 60° Line/Port","Side 2 Thread Type":"G - 1-1/4-11","Side 2 Standard":"ISO 8434-6, ISO 1179","Side 2 Role":"Line/Port Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Adapter","Primary Material":"Steel","Material Grade":"12L14/C1045","Plating":"Trivalent Zinc"} Dimensions: {"Hex/Wrench":"1.969","Weight":"0.98 lb"}
Union Cross D2650-L28-L28-L28-L28-SS-X
Connection Details: {"Side 1 Connection Type":"Male DIN","Side 1 Tube OD":"28mm","Side 1 Thread Type":"M36X2.0","Side 1 Standard":"DIN 2353, ISO 8434-1","Side 1 Role":"Line/Tube Connection","Side 1 DIN Pressure Series":"Light","Side 2 Connection Type":"Male DIN","Side 2 Tube OD":"28mm","Side 2 Thread Type":"DIN 2353, ISO 8434-1","Side 2 Standard":"DIN 2353, ISO 8434-1","Side 2 Role":"Line/Tube Connection","Side 2 DIN Pressure Series":"Light","Side 3 Connection Type":"Male DIN","Side 3 Tube OD":"28mm","Side 3 Thread Type":"M36X2.0","Side 3 Standard":"DIN 2353, ISO 8434-1","Side 3 Role":"Line/Tube Connection","Side 3 DIN Pressure Series":"Light","Side 4 Connection Type":"Male DIN","Side 4 Tube OD":"28mm","Side 4 Thread Type":"M36X2.0","Side 4 Standard":"DIN 2353, ISO 8434-1","Side 4 Role":"Line/Tube Connection"} Body & Materials: {"Shape":"Cross","Shape Type":"Union Cross","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} Dimensions: {"Hex/Wrench":"36mm","Weight":"0.88 lb"}
Female Bulkhead Connector C2705-08-08-SS
Connection Details: {"Side 1 Connection Type":"Female NPTF","Side 1 Pipe Size":"1/2\"","Side 1 Thread Type":"1/2-14 NPTF","Side 1 Standard":"SAE J476","Side 1 Role":"Pipe Connection","Side 2 Connection Type":"Flareless Bite Type","Side 2 Tube OD":"1/2\"","Side 2 Thread Type":"3/4-16 UNF","Side 2 Standard":"SAE J514","Side 2 Role":"Tube Connection"} Body & Materials: {"Shape":"Straight","Shape Type":"Female Bulkhead Connector","Primary Material":"Stainless Steel","Material Grade":"316/316L","Feature":"Bulkhead"} Dimensions: {"Weight":"0.18 lb"}
Male Swivel Elbow 5701-12-12-FG
Connection Details: {"Side 1 Connection Type":"Male JIC","Side 1 Tube OD":"3/4\"","Side 1 Thread Type":"1-1/16-12 UN","Side 1 Standard":"SAE J514 - Class 2A Thread","Side 1 Role":"Line/Tube Connection","Side 2 Connection Type":"Male NPTF Swivel","Side 2 Pipe Size":"3/4\"","Side 2 Thread Type":"3/4-14 NPTF","Side 2 Standard":"SAE J476","Side 2 Role":"Line/Pipe Connection"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Male Swivel Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Seal Code":"NBR","Seal Material":"Buna-N (Nitrile)"} Dimensions: {"Hex/Wrench":"1.063","Weight":"0.66 lb"}
Adjustable Elbow F6801-08-12-NWO-FG-VITON
Connection Details: {"Side 1 Connection Type":"Male Flare-O","Side 1 Tube OD":"1/2\"","Side 1 Thread Type":"3/4-16 UNF","Side 1 Standard":"SAE J514","Side 1 Role":"Line/Tube Connection","Side 1 Replacement Seal":"F4004-08","Side 2 Connection Type":"Male Adjustable ORB","Side 2 Thread Type":"1-1/16-12 UN","Side 2 Standard":"SAE J1926","Side 2 Role":"Port Connection","Side 2 Replacement Seal":"4001-12"} Body & Materials: {"Shape":"90° Elbow","Shape Type":"Adjustable Elbow","Primary Material":"Steel","Material Grade":"C1045","Plating":"Trivalent Zinc","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)"} Dimensions: {"Weight":"0.57 lb"}
