Attributes
| Part Number | D2525-S10-10-X |
|---|---|
| Is Series Page | 0 |
Description
Steel, DIN 2353 90° Weld Elbow, Heavy 10mm Tube OD x 10mm Butt Weld, Body Only
Specifications
| Body & Materials | {"Shape":"90° Elbow","Shape Type":"Coupling Elbow","Primary Material":"Steel","Material Grade":"11SMnPb30"} |
|---|---|
| Dimensions | {"Weight":"0.41 lb"} |
| Performance Specifications | {"Temperature Range":"-65°F to 500°F","Corrosion Resistance":"1,000 hrs no red rust per DIN ISO 9227"} |
| Cross References | {"Parker TFD Part Number":"WAS10SX"} |
| Regulatory & Compliance | {"RoHS Compliance":"Compliant by Exemption 6a-I (Lead in steel alloy)","REACH Compliance":"May contain Lead ≥0.1%"} |
| Series Configuration | Male DIN x Buttweld, Body Only |
| Technical Series Configuration | DIN 2353/ISO 8434-1 Flareless Tube x Buttweld Coupling 90° Elbow, Body Only |
| Shape | 90° Elbow |
| Product Type | Fittings |
