Attributes
| Part Number | D5002-CV-20-20-1.0CP-SS |
|---|---|
| Is Series Page | 0 |
Description
Stainless Steel, DIN 2353 Female Check Valve, 1 1/4" BSPP, 1.0 Bar Check Pressure
Specifications
| Body & Materials | {"Shape":"Straight","Primary Material":"Stainless Steel","Material Grade":"316Ti (1.4571)"} |
|---|---|
| Dimensions | {"Weight":"3.17 lb"} |
| Performance Specifications | {"Temperature Range":"°F to °F"} |
| Cross References | {"Parker TFD Part Number":"RHDI1.1/471"} |
| Regulatory & Compliance | {"RoHS Compliance":"Compliant","REACH Compliance":"No Substance(s) Present Above Threshold"} |
| Series Configuration | Female BSPP x Female BSPP |
| Technical Series Configuration | ISO 1179-1/DIN 3852 T2 Female BSPP x Female BSPP Check Valve Coupling |
| Shape | Straight |
| Product Type | Fittings |
