Attributes
| Part Number | 0600-10-10-10 |
|---|---|
| Is Series Page | 0 |
Description
Steel, SAE J514 Tube Bore Male Flared Branch Tee, 5/8" Bore x 5/8" Male JIC
Specifications
| Connection Details | {"Side 1 Connection Type":"Bore","Side 1 Tube OD":"5/8\"","Side 1 Standard":"Not Defined","Side 1 Role":"Tube Connection","Side 2 Connection Type":"Bore","Side 2 Tube OD":"5/8\"","Side 2 Standard":"Not Defined","Side 2 Role":"Tube Connection","Side 3 Connection Type":"Male JIC","Side 3 Tube OD":"5/8\"","Side 3 Thread Type":"7/8-14 UNF","Side 3 Standard":"SAE J514 - Class 2A Thread","Side 3 Role":"Line/Tube Connection"} |
|---|---|
| Body & Materials | {"Shape":"Tee","Shape Type":"Branch Tee","Primary Material":"Steel","Material Grade":"1018/1020","Plating":"Unplated"} |
| Dimensions | {"Weight":"0.24 lb"} |
| Performance Specifications | {"Working Pressure":"5000 psi","Temperature Range":"-65°F to 500°F","Burst Pressure":"20000 psi","Burst Ratio":"4:1"} |
| Regulatory & Compliance | {"RoHS Compliance":"Compliant","REACH Compliance":"No Substance(s) Present Above Threshold"} |
| Series Configuration | Tube Bore x Tube Bore x Male JIC |
| Technical Series Configuration | SAE J514 Tube Bore x Tube Bore x Male JIC Tube Branch Tee |
| Side 1 Connection Type | Bore |
| Side 2 Connection Type | Bore |
| Shape | Tee |
| Product Type | Fittings |
PDF Documents
No PDF documents.
