Attributes
| Part Number | 760LIB6MMX4MM |
|---|---|
| Is Series Page | 0 |
Description
Brass Tube Insert, Tube OD 6mm x Tube ID 4mm
Specifications
| Connection Details | {"Connection Type":"Double Ferrule Tube Insert","Tube OD":"6mm","Tube Fitting System":"Ham-let Let-Lok Series"} |
|---|---|
| Body & Materials | {"Shape":"Insert","Primary Material":"Brass"} |
| Dimensions | {"Weight":"0.022 lb"} |
| Performance Specifications | {"Temperature Range":"-325°F to 400°F","Pressure Rating Notes":"See Tube Pressure Rating Chart"} |
| Cross References | {"Gal #":"3100140","Swagelok Part Number":"B-6M5-4M"} |
| Series Configuration | Double Ferrule Tube Insert |
| Side 1 Connection Type | Double Ferrule Tube Insert |
| Product Type | Fittings |
