Attributes
| Part Number | 8800-06-SS-VITON |
|---|---|
| Is Series Page | 0 |
Description
Stainless Steel/Fluorocarbon, Metric Bonded Seal Gasket for 6mm Metric (Type D) Port
Specifications
| Specifications | {"Exact OD":"10mm","Exact ID":"4.7mm","Exact Width":"1mm","Color":"Brown","Gasket Dash Size":"-M06","Seal Code":"FKM","Seal Material":"Viton (Fluorocarbon)","Temperature":"-15°F to 400°F","Seal Hardness":"75 Durometer"} |
|---|---|
| Application & Performance | {"Chemical Resistance":"Petroleum oils, mineral oils, synthetic lubricants, fuels, diesel, gasoline, hydraulic oils, phosphate ester fluids, silicone oils and greases, diester lubricants, aromatic hydrocarbons, many chlorinated hydrocarbons, mild acids","Not Recommended For":"Ketones, amines, low molecular weight esters and ethers, hot hydrofluoric acids, strong alkalis, steam, hot water, glycol-based brake fluids"} |
| Shape | Straight |
