Description
MBT-MM CF 90 ELBOW.
D8801-CF
DIN Metric Tube Fittings
Available Variations
| SKU | Attribute | Price | Stock | Detailed Specs |
|---|---|---|---|---|
| D8801-L22-26-CF-SS | D8801-L22-26-CF-SS (L22MBT-26MM ...) | $287.45 | In Stock |
CONNECTION 1 TYPE: DIN METRIC TUBE COMPRESSION CONNECTION 1 TUBE SIZE: LIGHT 22MM TUBE OD CONNECTION 1 THREAD SIZE: M30X2.0 CONNECTION 1 SPECIFICATION: DIN 2353, ISO 8434-1 CONNECTION 2 TYPE: MALE METRIC FORM B CONNECTION 2 THREAD SIZE: M26X1.5 CONNECTION 2 THREAD (ID): 18.0 CONNECTION 2 SPECIFICATION: ISO 9974 FORM B BODY HEX (MM): 27.0 HEX C 1 (MM): 36.0 CENTERLINE LENGTH M1 (MM): 45.5 CENTERLINE LENGTH M2 (MM): 35.0 CENTERLINE LENGHT M3 (MM): 27.5 CENTERLINE LENGTH L1 (MM): 42.0 CENTERLINE LENGTH L2 (MM): 16.0 SHAPE: 90 DEGREE ANGLE BODY MATERIAL: STAINLESS STEEL RAW MATERIAL TYPE: STAINLESS STEEL FORGING WEIGHT (LBS): 0.635 MAXIMUM DYNAMIC PRESSURE (BAR): 250 CALIFORNIA RESIDENTS: PROP-65 WARNING CUBIC INCH SPACE (L X W X H): 7.777 |
| D8801-L28-33-CF-SS | D8801-L28-33-CF-SS (L28MBT-33MM ...) | $603.22 | In Stock |
CONNECTION 1 TYPE: DIN METRIC TUBE COMPRESSION CONNECTION 1 TUBE SIZE: LIGHT 28MM TUBE OD CONNECTION 1 THREAD SIZE: M36X2.0 CONNECTION 1 SPECIFICATION: DIN 2353, ISO 8434-1 CONNECTION 2 TYPE: MALE METRIC FORM B CONNECTION 2 THREAD SIZE: M33X2.0 CONNECTION 2 THREAD (ID): 23.0 CONNECTION 2 SPECIFICATION: ISO 9974 FORM B BODY HEX (MM): 36.0 HEX C 1 (MM): 41.0 CENTERLINE LENGTH M1 (MM): 49.0 CENTERLINE LENGTH M2 (MM): 38.0 CENTERLINE LENGHT M3 (MM): 30.5 CENTERLINE LENGTH L1 (MM): 48.0 CENTERLINE LENGTH L2 (MM): 18.0 SHAPE: 90 DEGREE ANGLE BODY MATERIAL: STAINLESS STEEL RAW MATERIAL TYPE: STAINLESS STEEL FORGING WEIGHT (LBS): 0.935 MAXIMUM DYNAMIC PRESSURE (BAR): 160 CALIFORNIA RESIDENTS: PROP-65 WARNING CUBIC INCH SPACE (L X W X H): 11.483 |
| D8801-L35-42-CF-SS | D8801-L35-42-CF-SS (L35MBT-42MM ...) | $1,017.44 | In Stock |
CONNECTION 1 TYPE: DIN METRIC TUBE COMPRESSION CONNECTION 1 TUBE SIZE: LIGHT 35MM TUBE OD CONNECTION 1 THREAD SIZE: M45X2.0 CONNECTION 1 SPECIFICATION: DIN 2353, ISO 8434-1 CONNECTION 2 TYPE: MALE METRIC FORM B CONNECTION 2 THREAD SIZE: M42X2.0 CONNECTION 2 THREAD (ID): 30.0 CONNECTION 2 SPECIFICATION: ISO 9974 FORM B BODY HEX (MM): 41.0 HEX C 1 (MM): 50.0 CENTERLINE LENGTH M1 (MM): 57.0 CENTERLINE LENGTH M2 (MM): 45.0 CENTERLINE LENGHT M3 (MM): 34.5 CENTERLINE LENGTH L1 (MM): 54.0 CENTERLINE LENGTH L2 (MM): 20.0 SHAPE: 90 DEGREE ANGLE BODY MATERIAL: STAINLESS STEEL RAW MATERIAL TYPE: STAINLESS STEEL FORGING WEIGHT (LBS): 1.435 MAXIMUM DYNAMIC PRESSURE (BAR): 160 CALIFORNIA RESIDENTS: PROP-65 WARNING CUBIC INCH SPACE (L X W X H): 18.681 |
| D8801-S25-33-CF-SS | D8801-S25-33-CF-SS (S25MBT-33MM ...) | $631.21 | In Stock |
CONNECTION 1 TYPE: DIN METRIC TUBE COMPRESSION CONNECTION 1 TUBE SIZE: HEAVY 25MM TUBE OD CONNECTION 1 THREAD SIZE: M36X2.0 CONNECTION 1 SPECIFICATION: DIN 2353, ISO 8434-1 CONNECTION 2 TYPE: MALE METRIC FORM B CONNECTION 2 THREAD SIZE: M33X2.0 CONNECTION 2 THREAD (ID): 20.0 CONNECTION 2 SPECIFICATION: ISO 9974 FORM B BODY HEX (MM): 36.0 HEX C 1 (MM): 46.0 CENTERLINE LENGTH M1 (MM): 55.0 CENTERLINE LENGTH M2 (MM): 42.0 CENTERLINE LENGHT M3 (MM): 30.0 CENTERLINE LENGTH L1 (MM): 48.0 CENTERLINE LENGTH L2 (MM): 18.0 SHAPE: 90 DEGREE ANGLE BODY MATERIAL: STAINLESS STEEL RAW MATERIAL TYPE: STAINLESS STEEL FORGING WEIGHT (LBS): 1.403 MAXIMUM DYNAMIC PRESSURE (BAR): 250 CALIFORNIA RESIDENTS: PROP-65 WARNING CUBIC INCH SPACE (L X W X H): 14.549 |
| D8801-S30-42-CF-SS | D8801-S30-42-CF-SS (S30MBT-42MM ...) | $886.64 | In Stock |
CONNECTION 1 TYPE: DIN METRIC TUBE COMPRESSION CONNECTION 1 TUBE SIZE: HEAVY 30MM TUBE OD CONNECTION 1 THREAD SIZE: M42X2.0 CONNECTION 1 SPECIFICATION: DIN 2353, ISO 8434-1 CONNECTION 2 TYPE: MALE METRIC FORM B CONNECTION 2 THREAD SIZE: M42X2.0 CONNECTION 2 THREAD (ID): 25.0 CONNECTION 2 SPECIFICATION: ISO 9974 FORM B BODY HEX (MM): 41.0 HEX C 1 (MM): 50.0 CENTERLINE LENGTH M1 (MM): 63.2 CENTERLINE LENGTH M2 (MM): 49.0 CENTERLINE LENGHT M3 (MM): 35.5 CENTERLINE LENGTH L1 (MM): 54.0 CENTERLINE LENGTH L2 (MM): 20.0 SHAPE: 90 DEGREE ANGLE BODY MATERIAL: STAINLESS STEEL RAW MATERIAL TYPE: STAINLESS STEEL FORGING WEIGHT (LBS): 2.011 MAXIMUM DYNAMIC PRESSURE (BAR): 160 CALIFORNIA RESIDENTS: PROP-65 WARNING CUBIC INCH SPACE (L X W X H): 20.187 |
| D8801-S38-48-CF-SS | D8801-S38-48-CF-SS (S38MBT-48MM ...) | $1,226.15 | In Stock |
CONNECTION 1 TYPE: DIN METRIC TUBE COMPRESSION CONNECTION 1 TUBE SIZE: HEAVY 38MM TUBE OD CONNECTION 1 THREAD SIZE: M52X2.0 CONNECTION 1 SPECIFICATION: DIN 2353, ISO 8434-1 CONNECTION 2 TYPE: MALE METRIC FORM B CONNECTION 2 THREAD SIZE: M48X2.0 CONNECTION 2 THREAD (ID): 32.0 CONNECTION 2 SPECIFICATION: ISO 9974 FORM B BODY HEX (MM): 50.0 HEX C 1 (MM): 60.0 CENTERLINE LENGTH M1 (MM): 72.5 CENTERLINE LENGTH M2 (MM): 57.0 CENTERLINE LENGHT M3 (MM): 41.0 CENTERLINE LENGTH L1 (MM): 61.0 CENTERLINE LENGTH L2 (MM): 22.0 SHAPE: 90 DEGREE ANGLE BODY MATERIAL: STAINLESS STEEL RAW MATERIAL TYPE: STAINLESS STEEL FORGING WEIGHT (LBS): 2.900 MAXIMUM DYNAMIC PRESSURE (BAR): 160 CALIFORNIA RESIDENTS: PROP-65 WARNING CUBIC INCH SPACE (L X W X H): 32.486 |
