D8501

D8501-E04-06

$33.83

Attribute: D8501-E04-06 (E04MBT-06MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 04MM TUBE OD
CONNECTION 1 THREAD SIZE	M08X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M06X1.0
CONNECTION 2 THREAD (ID)	2.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	10.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	11.0
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.033
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.342

D8501-E04-06-SS

$88.46

Attribute: D8501-E04-06-SS (E04MBT-06MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 04MM TUBE OD
CONNECTION 1 THREAD SIZE	M08X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M06X1.0
CONNECTION 2 THREAD (ID)	2.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	10.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	11.0
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.033
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.342

D8501-E04-08

$36.15

Attribute: D8501-E04-08 (E04MBT-08MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 04MM TUBE OD
CONNECTION 1 THREAD SIZE	M08X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M08X1.0
CONNECTION 2 THREAD (ID)	3.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	10.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	11.0
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.036
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.342

D8501-E04-08-SS

$87.48

Attribute: D8501-E04-08-SS (E04MBT-08MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 04MM TUBE OD
CONNECTION 1 THREAD SIZE	M08X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M08X1.0
CONNECTION 2 THREAD (ID)	3.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	10.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	11.0
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.036
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.342

D8501-E06-06

$22.28

Attribute: D8501-E06-06 (E06MBT-06MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M10X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M06X1.0
CONNECTION 2 THREAD (ID)	2.5
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	12.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	9.5
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.036
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.429

D8501-E06-06-SS

$107.32

Attribute: D8501-E06-06-SS (E06MBT-06MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M10X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M06X1.0
CONNECTION 2 THREAD (ID)	2.5
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	12.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	9.5
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.036
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.429

D8501-E06-08

$20.36

Attribute: D8501-E06-08 (E06MBT-08MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M10X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M08X1.0
CONNECTION 2 THREAD (ID)	3.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	12.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	9.5
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.040
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.429

D8501-E06-08-SS

$105.61

Attribute: D8501-E06-08-SS (E06MBT-08MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M10X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M08X1.0
CONNECTION 2 THREAD (ID)	3.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	12.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	9.5
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.040
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.429

D8501-E06-10-SS

$87.44

Attribute: D8501-E06-10-SS (E06MBT-10MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M10X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M10X1.0
CONNECTION 2 THREAD (ID)	4.5
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	9.0
HEX C 1 (MM)	12.0
CENTERLINE LENGTH M1 (MM)	21.0
CENTERLINE LENGTH M2 (MM)	15.0
CENTERLINE LENGHT M3 (MM)	9.5
CENTERLINE LENGTH L1 (MM)	17.0
CENTERLINE LENGTH L2 (MM)	8.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.042
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.429

D8501-E08-10

$54.21

Attribute: D8501-E08-10 (E08MBT-10MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 08MM TUBE OD
CONNECTION 1 THREAD SIZE	M12X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M10X1.0
CONNECTION 2 THREAD (ID)	6.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	14.0
CENTERLINE LENGTH M1 (MM)	23.0
CENTERLINE LENGTH M2 (MM)	17.0
CENTERLINE LENGHT M3 (MM)	11.5
CENTERLINE LENGTH L1 (MM)	20.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.057
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.669

D8501-E08-10-SS

$93.46

Attribute: D8501-E08-10-SS (E08MBT-10MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	EXTRA LIGHT 08MM TUBE OD
CONNECTION 1 THREAD SIZE	M12X1.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M10X1.0
CONNECTION 2 THREAD (ID)	6.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	14.0
CENTERLINE LENGTH M1 (MM)	23.0
CENTERLINE LENGTH M2 (MM)	17.0
CENTERLINE LENGHT M3 (MM)	11.5
CENTERLINE LENGTH L1 (MM)	20.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.057
MAXIMUM DYNAMIC PRESSURE (BAR)	100
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.669

D8501-L06-08-SS

$87.18

Attribute: D8501-L06-08-SS (L06MBT-08MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M12X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M08X1.0
CONNECTION 2 THREAD (ID)	3.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	14.0
CENTERLINE LENGTH M1 (MM)	27.0
CENTERLINE LENGTH M2 (MM)	19.0
CENTERLINE LENGHT M3 (MM)	12.0
CENTERLINE LENGTH L1 (MM)	20.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.075
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.761

D8501-L06-10

$23.48

Attribute: D8501-L06-10 (L06MBT-10MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M12X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M10X1.0
CONNECTION 2 THREAD (ID)	4.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	14.0
CENTERLINE LENGTH M1 (MM)	27.0
CENTERLINE LENGTH M2 (MM)	19.0
CENTERLINE LENGHT M3 (MM)	12.0
CENTERLINE LENGTH L1 (MM)	20.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.079
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.761

D8501-L06-10-SS

$79.71

Attribute: D8501-L06-10-SS (L06MBT-10MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M12X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M10X1.0
CONNECTION 2 THREAD (ID)	4.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	14.0
CENTERLINE LENGTH M1 (MM)	27.0
CENTERLINE LENGTH M2 (MM)	19.0
CENTERLINE LENGHT M3 (MM)	12.0
CENTERLINE LENGTH L1 (MM)	20.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.079
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.761

D8501-L08-10-SS

$95.76

Attribute: D8501-L08-10-SS (L08MBT-10MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 08MM TUBE OD
CONNECTION 1 THREAD SIZE	M14X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M10X1.0
CONNECTION 2 THREAD (ID)	4.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	17.0
CENTERLINE LENGTH M1 (MM)	29.0
CENTERLINE LENGTH M2 (MM)	21.0
CENTERLINE LENGHT M3 (MM)	14.0
CENTERLINE LENGTH L1 (MM)	24.0
CENTERLINE LENGTH L2 (MM)	10.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.103
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.180

D8501-L08-12

$17.03

Attribute: D8501-L08-12 (L08MBT-12MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 08MM TUBE OD
CONNECTION 1 THREAD SIZE	M14X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M12X1.5
CONNECTION 2 THREAD (ID)	6.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	17.0
CENTERLINE LENGTH M1 (MM)	29.0
CENTERLINE LENGTH M2 (MM)	21.0
CENTERLINE LENGHT M3 (MM)	14.0
CENTERLINE LENGTH L1 (MM)	26.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.106
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.253

D8501-L08-12-SS

$88.46

Attribute: D8501-L08-12-SS (L08MBT-12MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 08MM TUBE OD
CONNECTION 1 THREAD SIZE	M14X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M12X1.5
CONNECTION 2 THREAD (ID)	6.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	17.0
CENTERLINE LENGTH M1 (MM)	29.0
CENTERLINE LENGTH M2 (MM)	21.0
CENTERLINE LENGHT M3 (MM)	14.0
CENTERLINE LENGTH L1 (MM)	26.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.106
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.253

D8501-L10-14

$23.43

Attribute: D8501-L10-14 (L10MBT-14MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 10MM TUBE OD
CONNECTION 1 THREAD SIZE	M16X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M14X1.5
CONNECTION 2 THREAD (ID)	7.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	14.0
HEX C 1 (MM)	19.0
CENTERLINE LENGTH M1 (MM)	30.0
CENTERLINE LENGTH M2 (MM)	22.0
CENTERLINE LENGHT M3 (MM)	15.0
CENTERLINE LENGTH L1 (MM)	27.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.144
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.566

D8501-L10-14-SS

$99.00

Attribute: D8501-L10-14-SS (L10MBT-14MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 10MM TUBE OD
CONNECTION 1 THREAD SIZE	M16X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M14X1.5
CONNECTION 2 THREAD (ID)	7.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	14.0
HEX C 1 (MM)	19.0
CENTERLINE LENGTH M1 (MM)	30.0
CENTERLINE LENGTH M2 (MM)	22.0
CENTERLINE LENGHT M3 (MM)	15.0
CENTERLINE LENGTH L1 (MM)	27.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.144
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.566

D8501-L10-16-SS

$115.30

Attribute: D8501-L10-16-SS (L10MBT-16MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 10MM TUBE OD
CONNECTION 1 THREAD SIZE	M16X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M16X1.5
CONNECTION 2 THREAD (ID)	8.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	14.0
HEX C 1 (MM)	19.0
CENTERLINE LENGTH M1 (MM)	30.0
CENTERLINE LENGTH M2 (MM)	22.0
CENTERLINE LENGHT M3 (MM)	15.0
CENTERLINE LENGTH L1 (MM)	28.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.152
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.609

D8501-L12-16

$22.36

Attribute: D8501-L12-16 (L12MBT-16MMT 90)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 12MM TUBE OD
CONNECTION 1 THREAD SIZE	M18X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M16X1.5
CONNECTION 2 THREAD (ID)	9.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	17.0
HEX C 1 (MM)	22.0
CENTERLINE LENGTH M1 (MM)	32.0
CENTERLINE LENGTH M2 (MM)	24.0
CENTERLINE LENGHT M3 (MM)	17.0
CENTERLINE LENGTH L1 (MM)	28.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.188
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	2.121

D8501-L12-16-SS

$105.06

Attribute: D8501-L12-16-SS (L12MBT-16MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 12MM TUBE OD
CONNECTION 1 THREAD SIZE	M18X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M16X1.5
CONNECTION 2 THREAD (ID)	9.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	17.0
HEX C 1 (MM)	22.0
CENTERLINE LENGTH M1 (MM)	32.0
CENTERLINE LENGTH M2 (MM)	24.0
CENTERLINE LENGHT M3 (MM)	17.0
CENTERLINE LENGTH L1 (MM)	28.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.188
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	2.121

D8501-L15-18-SS

$157.76

Attribute: D8501-L15-18-SS (L15MBT-18MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 15MM TUBE OD
CONNECTION 1 THREAD SIZE	M22X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M18X1.5
CONNECTION 2 THREAD (ID)	11.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	19.0
HEX C 1 (MM)	27.0
CENTERLINE LENGTH M1 (MM)	36.0
CENTERLINE LENGTH M2 (MM)	28.0
CENTERLINE LENGHT M3 (MM)	21.0
CENTERLINE LENGTH L1 (MM)	32.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.300
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	3.411

D8501-L18-22-SS

$198.64

Attribute: D8501-L18-22-SS (L18MBT-22MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 18MM TUBE OD
CONNECTION 1 THREAD SIZE	M26X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M22X1.5
CONNECTION 2 THREAD (ID)	14.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	24.0
HEX C 1 (MM)	32.0
CENTERLINE LENGTH M1 (MM)	40.5
CENTERLINE LENGTH M2 (MM)	31.0
CENTERLINE LENGHT M3 (MM)	23.5
CENTERLINE LENGTH L1 (MM)	36.0
CENTERLINE LENGTH L2 (MM)	14.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.445
MAXIMUM DYNAMIC PRESSURE (BAR)	315
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	5.331

D8501-S06-12-SS

$98.91

Attribute: D8501-S06-12-SS (S06MBT-12MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 06MM TUBE OD
CONNECTION 1 THREAD SIZE	M14X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M12X1.5
CONNECTION 2 THREAD (ID)	4.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	12.0
HEX C 1 (MM)	17.0
CENTERLINE LENGTH M1 (MM)	31.0
CENTERLINE LENGTH M2 (MM)	23.0
CENTERLINE LENGHT M3 (MM)	16.0
CENTERLINE LENGTH L1 (MM)	26.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.130
MAXIMUM DYNAMIC PRESSURE (BAR)	400
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.324

D8501-S08-14-SS

$111.80

Attribute: D8501-S08-14-SS (S08MBT-14MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 08MM TUBE OD
CONNECTION 1 THREAD SIZE	M16X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M14X1.5
CONNECTION 2 THREAD (ID)	5.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	14.0
HEX C 1 (MM)	19.0
CENTERLINE LENGTH M1 (MM)	32.0
CENTERLINE LENGTH M2 (MM)	24.0
CENTERLINE LENGHT M3 (MM)	17.0
CENTERLINE LENGTH L1 (MM)	27.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.175
MAXIMUM DYNAMIC PRESSURE (BAR)	400
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	1.651

D8501-S10-16-SS

$130.02

Attribute: D8501-S10-16-SS (S10MBT-16MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 10MM TUBE OD
CONNECTION 1 THREAD SIZE	M18X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M16X1.5
CONNECTION 2 THREAD (ID)	7.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	17.0
HEX C 1 (MM)	22.0
CENTERLINE LENGTH M1 (MM)	34.0
CENTERLINE LENGTH M2 (MM)	25.0
CENTERLINE LENGHT M3 (MM)	17.5
CENTERLINE LENGTH L1 (MM)	28.0
CENTERLINE LENGTH L2 (MM)	15.5
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.232
MAXIMUM DYNAMIC PRESSURE (BAR)	400
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	2.225

D8501-S12-18-SS

$166.89

Attribute: D8501-S12-18-SS (S12MBT-18MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 12MM TUBE OD
CONNECTION 1 THREAD SIZE	M20X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M18X1.5
CONNECTION 2 THREAD (ID)	8.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	17.0
HEX C 1 (MM)	24.0
CENTERLINE LENGTH M1 (MM)	38.0
CENTERLINE LENGTH M2 (MM)	29.0
CENTERLINE LENGHT M3 (MM)	21.5
CENTERLINE LENGTH L1 (MM)	28.0
CENTERLINE LENGTH L2 (MM)	12.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.283
MAXIMUM DYNAMIC PRESSURE (BAR)	400
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	2.724

D8501-S14-20-SS

$200.39

Attribute: D8501-S14-20-SS (S14MBT-20MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 14MM TUBE OD
CONNECTION 1 THREAD SIZE	M22X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M20X1.5
CONNECTION 2 THREAD (ID)	10.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	19.0
HEX C 1 (MM)	27.0
CENTERLINE LENGTH M1 (MM)	39.5
CENTERLINE LENGTH M2 (MM)	30.0
CENTERLINE LENGHT M3 (MM)	22.0
CENTERLINE LENGTH L1 (MM)	32.0
CENTERLINE LENGTH L2 (MM)	18.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.381
MAXIMUM DYNAMIC PRESSURE (BAR)	400
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	3.673

D8501-S16-22-SS

$236.66

Attribute: D8501-S16-22-SS (S16MBT-22MMT 90...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 16MM TUBE OD
CONNECTION 1 THREAD SIZE	M24X1.5
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE METRIC TAPERED
CONNECTION 2 THREAD SIZE	M22X1.5
CONNECTION 2 THREAD (ID)	12.0
CONNECTION 2 SPECIFICATION	DIN 158
BODY HEX (MM)	24.0
HEX C 1 (MM)	30.0
CENTERLINE LENGTH M1 (MM)	43.0
CENTERLINE LENGTH M2 (MM)	33.0
CENTERLINE LENGHT M3 (MM)	24.5
CENTERLINE LENGTH L1 (MM)	32.0
CENTERLINE LENGTH L2 (MM)	16.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.489
MAXIMUM DYNAMIC PRESSURE (BAR)	400
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	4.732

ID	10168722
Category	DIN Metric Tube Fittings

Description

Description

Variations (30)

D8501-E04-06

D8501-E04-06-SS

D8501-E04-08

D8501-E04-08-SS

D8501-E06-06

D8501-E06-06-SS

D8501-E06-08

D8501-E06-08-SS

D8501-E06-10-SS

D8501-E08-10

D8501-E08-10-SS

D8501-L06-08-SS

D8501-L06-10

D8501-L06-10-SS

D8501-L08-10-SS

D8501-L08-12

D8501-L08-12-SS

D8501-L10-14

D8501-L10-14-SS

D8501-L10-16-SS

D8501-L12-16

D8501-L12-16-SS

D8501-L15-18-SS

D8501-L18-22-SS

D8501-S06-12-SS

D8501-S08-14-SS

D8501-S10-16-SS

D8501-S12-18-SS

D8501-S14-20-SS

D8501-S16-22-SS

General Attributes

PDF Documents
