D7801-CF

D7801-L22-12-CF-SS

$257.78

Attribute: D7801-L22-12-CF-SS (L22MBT-12MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 22MM TUBE OD
CONNECTION 1 THREAD SIZE	M30X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	3/4-14
CONNECTION 2 THREAD ID (MM)	18.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	27.0
HEX C 1 (MM)	36.0
CENTERLINE LENGTH M1 (MM)	45.5
CENTERLINE LENGTH M2 (MM)	35.0
CENTERLINE LENGHT M3 (MM)	27.5
CENTERLINE LENGTH L1 (MM)	42.0
CENTERLINE LENGTH L2 (MM)	16.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.624
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	7.777

D7801-L28-16-CF

$130.58

Attribute: D7801-L28-16-CF (L28MBT-16MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 28MM TUBE OD
CONNECTION 1 THREAD SIZE	M36X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-11
CONNECTION 2 THREAD ID (MM)	23.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	36.0
HEX C 1 (MM)	41.0
CENTERLINE LENGTH M1 (MM)	49.0
CENTERLINE LENGTH M2 (MM)	38.0
CENTERLINE LENGHT M3 (MM)	30.5
CENTERLINE LENGTH L1 (MM)	48.0
CENTERLINE LENGTH L2 (MM)	18.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.946
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	11.483

D7801-L28-16-CF-SS

$520.52

Attribute: D7801-L28-16-CF-SS (L28MBT-16MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 28MM TUBE OD
CONNECTION 1 THREAD SIZE	M36X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-11
CONNECTION 2 THREAD ID (MM)	23.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	36.0
HEX C 1 (MM)	41.0
CENTERLINE LENGTH M1 (MM)	49.0
CENTERLINE LENGTH M2 (MM)	38.0
CENTERLINE LENGHT M3 (MM)	30.5
CENTERLINE LENGTH L1 (MM)	48.0
CENTERLINE LENGTH L2 (MM)	18.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.946
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	11.483

D7801-L35-20-CF

$219.42

Attribute: D7801-L35-20-CF (L35MBT-20MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 35MM TUBE OD
CONNECTION 1 THREAD SIZE	M45X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/4-11
CONNECTION 2 THREAD ID (MM)	30.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	41.0
HEX C 1 (MM)	50.0
CENTERLINE LENGTH M1 (MM)	57.0
CENTERLINE LENGTH M2 (MM)	45.0
CENTERLINE LENGHT M3 (MM)	34.5
CENTERLINE LENGTH L1 (MM)	54.0
CENTERLINE LENGTH L2 (MM)	20.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	1.426
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	18.681

D7801-L35-20-CF-SS

$863.95

Attribute: D7801-L35-20-CF-SS (L35MBT-20MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 35MM TUBE OD
CONNECTION 1 THREAD SIZE	M45X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/4-11
CONNECTION 2 THREAD ID (MM)	30.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	41.0
HEX C 1 (MM)	50.0
CENTERLINE LENGTH M1 (MM)	57.0
CENTERLINE LENGTH M2 (MM)	45.0
CENTERLINE LENGHT M3 (MM)	34.5
CENTERLINE LENGTH L1 (MM)	54.0
CENTERLINE LENGTH L2 (MM)	20.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	1.426
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	18.681

D7801-L42-24-CF

$255.74

Attribute: D7801-L42-24-CF (L42MBT-24MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 42MM TUBE OD
CONNECTION 1 THREAD SIZE	M52X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/2-11
CONNECTION 2 THREAD ID (MM)	36.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	50.0
HEX C 1 (MM)	60.0
CENTERLINE LENGTH M1 (MM)	63.0
CENTERLINE LENGTH M2 (MM)	51.0
CENTERLINE LENGHT M3 (MM)	40.0
CENTERLINE LENGTH L1 (MM)	61.0
CENTERLINE LENGTH L2 (MM)	22.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	2.119
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	29.321

D7801-L42-24-CF-SS

$1,151.09

Attribute: D7801-L42-24-CF-SS (L42MBT-24MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	LIGHT 42MM TUBE OD
CONNECTION 1 THREAD SIZE	M52X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/2-11
CONNECTION 2 THREAD ID (MM)	36.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	50.0
HEX C 1 (MM)	60.0
CENTERLINE LENGTH M1 (MM)	63.0
CENTERLINE LENGTH M2 (MM)	51.0
CENTERLINE LENGHT M3 (MM)	40.0
CENTERLINE LENGTH L1 (MM)	61.0
CENTERLINE LENGTH L2 (MM)	22.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	2.119
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	29.321

D7801-S20-08-CF-SS

$316.76

Attribute: D7801-S20-08-CF-SS (S20MBT-08MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 20MM TUBE OD
CONNECTION 1 THREAD SIZE	M30X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1/2-14
CONNECTION 2 THREAD ID (MM)	12.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	27.0
HEX C 1 (MM)	36.0
CENTERLINE LENGTH M1 (MM)	49.0
CENTERLINE LENGTH M2 (MM)	37.0
CENTERLINE LENGHT M3 (MM)	26.5
CENTERLINE LENGTH L1 (MM)	42.0
CENTERLINE LENGTH L2 (MM)	14.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.772
MAXIMUM DYNAMIC PRESSURE (BAR)	250
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	8.238

D7801-S20-12-CF

$118.50

Attribute: D7801-S20-12-CF (S20MBT-12MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 20MM TUBE OD
CONNECTION 1 THREAD SIZE	M30X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	3/4-14
CONNECTION 2 THREAD ID (MM)	16.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	27.0
HEX C 1 (MM)	36.0
CENTERLINE LENGTH M1 (MM)	49.0
CENTERLINE LENGTH M2 (MM)	37.0
CENTERLINE LENGHT M3 (MM)	26.5
CENTERLINE LENGTH L1 (MM)	42.0
CENTERLINE LENGTH L2 (MM)	16.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	0.772
MAXIMUM DYNAMIC PRESSURE (BAR)	250
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	8.238

D7801-S20-12-CF-SS

$308.73

Attribute: D7801-S20-12-CF-SS (S20MBT-12MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 20MM TUBE OD
CONNECTION 1 THREAD SIZE	M30X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	3/4-14
CONNECTION 2 THREAD ID (MM)	16.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	27.0
HEX C 1 (MM)	36.0
CENTERLINE LENGTH M1 (MM)	49.0
CENTERLINE LENGTH M2 (MM)	37.0
CENTERLINE LENGHT M3 (MM)	26.5
CENTERLINE LENGTH L1 (MM)	42.0
CENTERLINE LENGTH L2 (MM)	16.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	0.772
MAXIMUM DYNAMIC PRESSURE (BAR)	250
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	8.238

D7801-S25-16-CF

$155.93

Attribute: D7801-S25-16-CF (S25MBT-16MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 25MM TUBE OD
CONNECTION 1 THREAD SIZE	M36X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-11
CONNECTION 2 THREAD ID (MM)	20.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	36.0
HEX C 1 (MM)	46.0
CENTERLINE LENGTH M1 (MM)	55.0
CENTERLINE LENGTH M2 (MM)	42.0
CENTERLINE LENGHT M3 (MM)	30.0
CENTERLINE LENGTH L1 (MM)	48.0
CENTERLINE LENGTH L2 (MM)	18.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	1.413
MAXIMUM DYNAMIC PRESSURE (BAR)	250
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	14.549

D7801-S25-16-CF-SS

$580.18

Attribute: D7801-S25-16-CF-SS (S25MBT-16MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 25MM TUBE OD
CONNECTION 1 THREAD SIZE	M36X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-11
CONNECTION 2 THREAD ID (MM)	20.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	36.0
HEX C 1 (MM)	46.0
CENTERLINE LENGTH M1 (MM)	55.0
CENTERLINE LENGTH M2 (MM)	42.0
CENTERLINE LENGHT M3 (MM)	30.0
CENTERLINE LENGTH L1 (MM)	48.0
CENTERLINE LENGTH L2 (MM)	18.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	1.413
MAXIMUM DYNAMIC PRESSURE (BAR)	250
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	14.549

D7801-S30-20-CF

$227.11

Attribute: D7801-S30-20-CF (S30MBT-20MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 30MM TUBE OD
CONNECTION 1 THREAD SIZE	M42X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/4-11
CONNECTION 2 THREAD ID (MM)	25.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	41.0
HEX C 1 (MM)	50.0
CENTERLINE LENGTH M1 (MM)	63.2
CENTERLINE LENGTH M2 (MM)	49.0
CENTERLINE LENGHT M3 (MM)	35.5
CENTERLINE LENGTH L1 (MM)	54.0
CENTERLINE LENGTH L2 (MM)	20.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	2.004
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	20.187

D7801-S30-20-CF-SS

$862.80

Attribute: D7801-S30-20-CF-SS (S30MBT-20MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 30MM TUBE OD
CONNECTION 1 THREAD SIZE	M42X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/4-11
CONNECTION 2 THREAD ID (MM)	25.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	41.0
HEX C 1 (MM)	50.0
CENTERLINE LENGTH M1 (MM)	63.2
CENTERLINE LENGTH M2 (MM)	49.0
CENTERLINE LENGHT M3 (MM)	35.5
CENTERLINE LENGTH L1 (MM)	54.0
CENTERLINE LENGTH L2 (MM)	20.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	2.004
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	20.187

D7801-S38-24-CF

$198.26

Attribute: D7801-S38-24-CF (S38MBT-24MBSPP ...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 38MM TUBE OD
CONNECTION 1 THREAD SIZE	M52X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/2-11
CONNECTION 2 THREAD ID (MM)	32.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	50.0
HEX C 1 (MM)	60.0
CENTERLINE LENGTH M1 (MM)	72.5
CENTERLINE LENGTH M2 (MM)	57.0
CENTERLINE LENGHT M3 (MM)	41.0
CENTERLINE LENGTH L1 (MM)	61.0
CENTERLINE LENGTH L2 (MM)	22.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	ZINC NICKEL
WEIGHT (LBS)	2.886
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	32.486

D7801-S38-24-CF-SS

$1,196.40

Attribute: D7801-S38-24-CF-SS (S38MBT-24MBS...)

Stock Status: True

CONNECTION 1 TYPE	DIN METRIC TUBE COMPRESSION
CONNECTION 1 TUBE SIZE	HEAVY 38MM TUBE OD
CONNECTION 1 THREAD SIZE	M52X2.0
CONNECTION 1 SPECIFICATION	DIN 2353, ISO 8434-1
CONNECTION 2 TYPE	MALE BSPP FORM B
CONNECTION 2 THREAD SIZE	1-1/2-11
CONNECTION 2 THREAD ID (MM)	32.0
CONNECTION 2 SPECIFICATION	DIN 3852-2 FORM B
BODY HEX (MM)	50.0
HEX C 1 (MM)	60.0
CENTERLINE LENGTH M1 (MM)	72.5
CENTERLINE LENGTH M2 (MM)	57.0
CENTERLINE LENGHT M3 (MM)	41.0
CENTERLINE LENGTH L1 (MM)	61.0
CENTERLINE LENGTH L2 (MM)	22.0
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STAINLESS STEEL FORGING
WEIGHT (LBS)	2.886
MAXIMUM DYNAMIC PRESSURE (BAR)	160
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	32.486

ID	10168087
Category	DIN Metric Tube Fittings

Description

Description

Variations (16)

D7801-L22-12-CF-SS

D7801-L28-16-CF

D7801-L28-16-CF-SS

D7801-L35-20-CF

D7801-L35-20-CF-SS

D7801-L42-24-CF

D7801-L42-24-CF-SS

D7801-S20-08-CF-SS

D7801-S20-12-CF

D7801-S20-12-CF-SS

D7801-S25-16-CF

D7801-S25-16-CF-SS

D7801-S30-20-CF

D7801-S30-20-CF-SS

D7801-S38-24-CF

D7801-S38-24-CF-SS

General Attributes

PDF Documents
