FS2764

Attribute: FS2764-04-04-O (04MFS Bulkhead-0...)

Stock Status: True

TUBE O.D.	1/4
A THREAD	9/16-18
B MORB	7/16-20
A DRILL	0.172
B DRILL	0.172
L LGTH	2.14
H HEX	.812
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-04-06-O (04MFS Bulkhead-0...)

Stock Status: True

TUBE O.D.	3/8
A THREAD	9/16-18
B MORB	9/16-18
A DRILL	0.172
B DRILL	0.295
L LGTH	2.18
H HEX	.812
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-06-06-O (06MFS Bulkhead-0...)

Stock Status: True

TUBE O.D.	3/8
A THREAD	11/16-16
B MORB	9/16-18
A DRILL	0.264
B DRILL	0.264
L LGTH	2.31
H HEX	1.00
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-08-08-O (08MFS Bulkhead-0...)

Stock Status: True

TUBE O.D.	1/2
A THREAD	13/16-16
B MORB	3/4-16
A DRILL	0.378
B DRILL	0.378
L LGTH	2.600
H HEX	1.125
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-10-10-O (10MFS Bulkhead-1...)

Stock Status: True

TUBE O.D.	5/8
A THREAD	1.14
B MORB	7/8-14
A DRILL	0.484
B DRILL	0.484
L LGTH	2.91
H HEX	1.312
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-12-12-O (12MFS Bulkhead-1...)

Stock Status: True

TUBE O.D.	3/4
A THREAD	1-3/16-12
B MORB	1-1/16-12
A DRILL	0.609
B DRILL	0.609
L LGTH	3.110
H HEX	1.500
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-16-16-O (16MFS Bulkhead-1...)

Stock Status: True

TUBE O.D.	1
A THREAD	1-7/16-12
B MORB	1-5/16-12
A DRILL	0.811
B DRILL	0.811
L LGTH	3.220
H HEX	1.750
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-20-20-O (20MFS Bulkhead-2...)

Stock Status: True

TUBE O.D.	1-1/4
A THREAD	1-11/16-12
B MORB	1-5/8-12
A DRILL	1.024
B DRILL	1.024
L LGTH	3.300
H HEX	2.000
MATERIAL	STEEL FACE SEAL

Attribute: FS2764-24-24-O (24MFS Bulkhead-2...)

Stock Status: True

TUBE O.D.	1-1/2
A THREAD	2-12
B MORB	1-7/8-12
A DRILL	1.260
B DRILL	1.260
L LGTH	3.30
H HEX	2.375
MATERIAL	STEEL FACE SEAL
