FS2704-FG

Attribute: FS2704-04-04-04-FG (04MFS-04MFS ...)

Stock Status: True

TUBE O.D.	1/4
A1 THREAD	9/16-18
A2 THREAD	9/16-18
A3 THREAD	9/16-18
A1 DRILL	0.172
A2 DRILL	0.172
A3 DRILL	0.172
R1 LGTH	0.890
S LGTH	1.850
R2 LGTH	0.890
JJ FLATS	0.562
MATERIAL	STEEL FORGED

Attribute: FS2704-06-06-06-FG (06MFS-06MFS ...)

Stock Status: True

TUBE O.D.	3/8
A1 THREAD	11/16-16
A2 THREAD	11/16-16
A3 THREAD	11/16-16
A1 DRILL	0.264
A2 DRILL	0.264
A3 DRILL	0.264
R1 LGTH	1.02
S LGTH	2.05
R2 LGTH	1.02
JJ FLATS	0.750
MATERIAL	STEEL FORGED

Attribute: FS2704-08-08-08-FG (08MFS-08MFS ...)

Stock Status: True

TUBE O.D.	1/2
A1 THREAD	13/16-16
A2 THREAD	13/16-16
A3 THREAD	13/16-16
A1 DRILL	0.378
A2 DRILL	0.378
A3 DRILL	0.378
R1 LGTH	1.14
S LGTH	2.18
R2 LGTH	1.14
JJ FLATS	0.750
MATERIAL	STEEL FORGED

Attribute: FS2704-08-08-08-SS (08MFS-08MFS ...)

Stock Status: True

TUBE O.D.	1/2
A1 THREAD	13/16-16
A2 THREAD	13/16-16
A3 THREAD	13/16-16
A1 DRILL	0.378
A2 DRILL	0.378
A3 DRILL	0.378
R1 LGTH	1.14
S LGTH	2.18
R2 LGTH	1.14
JJ FLATS	0.750
MATERIAL	STAINLESS STEEL

Attribute: FS2704-10-10-10-FG (10MFS-10MFS ...)

Stock Status: True

TUBE O.D.	5/8
A1 THREAD	1-14
A2 THREAD	1-14
A3 THREAD	1-14
A1 DRILL	0.484
A2 DRILL	0.484
A3 DRILL	0.484
R1 LGTH	1.36
S LGTH	2.48
R2 LGTH	1.36
JJ FLATS	1.062
MATERIAL	STEEL FORGED

Attribute: FS2704-12-12-12-FG (12MFS-12MFS ...)

Stock Status: True

TUBE O.D.	3/4
A1 THREAD	1-3/16-12
A2 THREAD	1-3/16-12
A3 THREAD	1-3/16-12
A1 DRILL	0.609
A2 DRILL	0.609
A3 DRILL	0.609
R1 LGTH	1.52
S LGTH	2.65
R2 LGTH	1.52
JJ FLATS	1.188
MATERIAL	STEEL FORGED

Attribute: FS2704-16-16-16-FG (16MFS-16MFS ...)

Stock Status: True

TUBE O.D.	1
A1 THREAD	1-7/16-12
A2 THREAD	1-7/16-12
A3 THREAD	1-7/16-12
A1 DRILL	0.811
A2 DRILL	0.811
A3 DRILL	0.811
R1 LGTH	1.67
S LGTH	2.80
R2 LGTH	1.67
JJ FLATS	1.438
MATERIAL	STEEL FORGED

Attribute: FS2704-20-20-20-FG (20MFS-20MFS ...)

Stock Status: True

TUBE O.D.	1-1/4
A1 THREAD	1-11/16-12
A2 THREAD	1-11/16-12
A3 THREAD	1-11/16-12
A1 DRILL	1.024
A2 DRILL	1.024
A3 DRILL	1.024
R1 LGTH	1.79
S LGTH	2.97
R2 LGTH	1.79
JJ FLATS	1.625
MATERIAL	STEEL FORGED

Attribute: FS2704-24-24-24-FG (24MFS-24MFS ...)

Stock Status: True

TUBE O.D.	1 1/2
A1 THREAD	2-12
A2 THREAD	2-12
A3 THREAD	2-12
A1 DRILL	3.130
A2 DRILL	79.50
A3 DRILL	1.950
R1 LGTH	49.53
S LGTH	1 7/8
R2 LGTH	1.875
JJ FLATS	47.62
MATERIAL	STEEL FORGED
