C2707

Attribute: C2707-04-04 (04MJ-04BT Blkhd Str...)

Stock Status: True

TUBE O.D.	1/4
B1 THREAD	7/16-20
B2 THREAD	7/16-20
B1 DRILL	0.203
B2 DRILL	0.172
K DEPTH	0.234
L LGTH	1.94
C1 HEX	0.688
C2 HEX	0.688
MATERIAL	STEEL COMPRESSION

Attribute: C2707-04-04-SS (04MJ-04BT Blkhd ...)

Stock Status: True

TUBE O.D.	1/4
B1 THREAD	7/16-20
B2 THREAD	7/16-20
B1 DRILL	0.203
B2 DRILL	0.172
K DEPTH	0.234
L LGTH	1.94
C1 HEX	0.688
C2 HEX	0.688
MATERIAL	STAINLESS STEEL

Attribute: C2707-06-06 (06MJ-06BT Blkhd Str...)

Stock Status: True

TUBE O.D.	3/8
B1 THREAD	9/16-18
B2 THREAD	9/16-18
B1 DRILL	0.281
B2 DRILL	0.297
K DEPTH	0.250
L LGTH	2.08
C1 HEX	0.812
C2 HEX	0.812
MATERIAL	STEEL COMPRESSION

Attribute: C2707-06-06-SS (06MJ-06BT Blkhd ...)

Stock Status: True

TUBE O.D.	3/8
B1 THREAD	9/16-18
B2 THREAD	9/16-18
B1 DRILL	0.281
B2 DRILL	0.297
K DEPTH	0.250
L LGTH	2.08
C1 HEX	0.812
C2 HEX	0.812
MATERIAL	STAINLESS STEEL

Attribute: C2707-08-08 (08MJ-08BT Blkhd Str...)

Stock Status: True

TUBE O.D.	1/2
B1 THREAD	3/4-16
B2 THREAD	3/4-16
B1 DRILL	0.422
B2 DRILL	0.391
K DEPTH	0.305
L LGTH	2.310
C1 HEX	1.000
C2 HEX	1.000
MATERIAL	STEEL COMPRESSION

Attribute: C2707-08-08-SS (08MJ-08BT Blkhd ...)

Stock Status: True

TUBE O.D.	1/2
B1 THREAD	3/4-16
B2 THREAD	3/4-16
B1 DRILL	0.422
B2 DRILL	0.391
K DEPTH	0.305
L LGTH	2.31
C1 HEX	1.000
C2 HEX	1.000
MATERIAL	STAINLESS STEEL

Attribute: C2707-12-12 (12MJ-12BT Blkhd Str...)

Stock Status: True

TUBE O.D.	3/4
B1 THREAD	1-1/16-12
B2 THREAD	1-1/16-12
B1 DRILL	0.656
B2 DRILL	0.609
K DEPTH	0.350
L LGTH	2.940
C1 HEX	1.375
C2 HEX	1.375
MATERIAL	STEEL

Attribute: C2707-12-12-SS (12MJ-12BT Blkhd ...)

Stock Status: True

TUBE O.D.	3/4
B1 THREAD	1-1/16-12
B2 THREAD	1-1/16-12
B1 DRILL	0.656
B2 DRILL	0.609
K DEPTH	0.350
L LGTH	2.94
C1 HEX	1.375
C2 HEX	1.375
MATERIAL	STAINLESS STEEL
