FS1700

Attribute: FS1700-08-08 (08MFS-08Flange Str...)

Stock Status: True

TUBE O.D.	1/2
1 THREAD	13/16-16 UN
2 FLANGE	1/2
L (IN.)	2.450
A/F (IN.)	1.125
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-12-12 (12MFS-12Flange Str...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1-3/16-12
2 FLANGE	3/4
L (IN.)	2.750
A/F (IN.)	1.375
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-12-16 (12MFS-16Flange Str...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1-3/16-12
2 FLANGE	1
L (IN.)	2.800
A/F (IN.)	1.250
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-16-12 (16MFS-12Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1-7/16-12
2 FLANGE	3/4
L (IN.)	2.750
A/F (IN.)	1.625
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-16-16 (16MFS-16Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1-7/16-12
2 FLANGE	1
L (IN.)	2.800
A/F (IN.)	1.500
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-16-20 (16MFS-20Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1-7/16-12
2 FLANGE	1 1/4
L (IN.)	2.800
A/F (IN.)	1.688
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-20-20 (20MFS-20Flange Str...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1-11/16-12
2 FLANGE	1 1/4
L (IN.)	2.800
A/F (IN.)	1.875
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-20-24 (20MFS-24Flange Str...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1-11/16-12
2 FLANGE	1 1/2
L (IN.)	3.500
A/F (IN.)	2.000
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-24-20 (24MFS-20Flange Str...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	2-12
2 FLANGE	1 1/4
L (IN.)	3.200
A/F (IN.)	2.125
MATERIAL	STEEL FACE SEAL

Attribute: FS1700-24-24 (24MFS-24Flange Str...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	2-12
2 FLANGE	1 1/2
L (IN.)	3.500
A/F (IN.)	2.125
MATERIAL	STEEL FACE SEAL
