1934

Attribute: 1934-48-48 (48FSWP-48FF Flange, ...)

Stock Status: True

PIPE SIZE	3
FLANGE SIZE	3
A	5.12
B	5.31
C	2.438
D	4.188
E	1.38
F	1.120
G	3.547
H	3.00
J MIN	3.615
J MAX	3.625
K2 THREAD	5/8-11
MATERIAL	STEEL

Attribute: 1934-56-56 (56FSWP-56FF Flange, ...)

Stock Status: True

PIPE SIZE	3-1/2
FLANGE SIZE	3-1/2
A	5.50
B	6.00
C	2.750
D	4.750
E	1.44
F	1.190
G	4.047
H	3.50
J MIN	4.095
J MAX	4.115
K2 THREAD	5/8-11
MATERIAL	STEEL

Attribute: 1934-64-64 (64FSWP-64FF Flange, ...)

Stock Status: True

PIPE SIZE	4
FLANGE SIZE	4
A	6.00
B	6.38
C	3.062
D	5.125
E	1.50
F	1.250
G	4.578
H	4.00
J MIN	4.595
J MAX	4.615
K2 THREAD	5/8-11
MATERIAL	STEEL
