1700

1700-08-08

$28.84

Attribute: 1700-08-08 (08MJ-08Flange Straig...)

Stock Status: True

TUBE O.D.	1/2
1 THREAD	3/4-16
2 FLANGE	1/2
L (IN.)	2.600
A/F (IN.)	1.000
MATERIAL	STEEL

1700-08-08-SS

$152.17

Attribute: 1700-08-08-SS (08MJ-08Flange Str...)

Stock Status: True

TUBE O.D.	1/2
1 THREAD	3/4-16
2 FLANGE	1/2
L (IN.)	2.60
A/F (IN.)	7/8
MATERIAL	STAINLESS STEEL

1700-08-12

$39.46

Attribute: 1700-08-12 (08MJ-12Flange Straig...)

Stock Status: True

TUBE O.D.	1/2
1 THREAD	3/4-16
2 FLANGE	3/4
L (IN.)	2.750
A/F (IN.)	1.125
MATERIAL	STEEL

1700-08-12-SS

$174.01

Attribute: 1700-08-12-SS (08MJ-12Flange Str...)

Stock Status: True

TUBE O.D.	1/2
1 THREAD	3/4-16
2 FLANGE	3/4
L (IN.)	2.75
A/F (IN.)	1 1/8
MATERIAL	STAINLESS STEEL

1700-10-10

$52.03

Attribute: 1700-10-10 (10MJ-10Flange Straig...)

Stock Status: True

TUBE O.D.	5/8
1 THREAD	7/8-14
2 FLANGE	5/8
L (IN.)	3.69
A/F (IN.)	.9375
MATERIAL	STEEL

1700-10-10-SS

$204.05

Attribute: 1700-10-10-SS (10MJ-10Flange Str...)

Stock Status: True

TUBE O.D.	5/8
1 THREAD	7/8-14
2 FLANGE	5/8
L (IN.)	3.69
A/F (IN.)	.9375
MATERIAL	STAINLESS STEEL

1700-12-10

$50.59

Attribute: 1700-12-10 (12MJ-10Flange Straig...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12
2 FLANGE	5/8
L (IN.)	2.55
A/F (IN.)	1.125
MATERIAL	STEEL

1700-12-12

$29.62

Attribute: 1700-12-12 (12MJ-12Flange Straig...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1-1/16-12
2 FLANGE	3/4
L (IN.)	2.750
A/F (IN.)	1.375
MATERIAL	STEEL

1700-12-12-SS

$176.44

Attribute: 1700-12-12-SS (12MJ-12Flange Str...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12 UN
2 FLANGE	3/4
L (IN.)	2.75
A/F (IN.)	1 1/8
MATERIAL	STAINLESS STEEL

1700-12-16

$41.55

Attribute: 1700-12-16 (12MJ-16Flange Straig...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12
2 FLANGE	1
L (IN.)	2.800
A/F (IN.)	1.250
MATERIAL	STEEL

1700-12-16-SS

$204.18

Attribute: 1700-12-16-SS (12MJ-16Flange Str...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12 UN
2 FLANGE	1
L (IN.)	2.80
A/F (IN.)	1.125
MATERIAL	STAINLESS STEEL

1700-12-20

$53.32

Attribute: 1700-12-20 (12MJ-20Flange Straig...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12
2 FLANGE	1-1/4
L (IN.)	2.800
A/F (IN.)	1.688
MATERIAL	STEEL

1700-12-20-SS

$455.44

Attribute: 1700-12-20-SS (12MJ-20Flange Str...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12 UN
2 FLANGE	1 1/4
L (IN.)	2.80
A/F (IN.)	1 3/8
MATERIAL	STAINLESS STEEL

1700-12-24

$93.57

Attribute: 1700-12-24 (12MJ-24Flange Straig...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1 1/16-12
2 FLANGE	1-1/2
L (IN.)	2.80
A/F (IN.)	1.50
MATERIAL	STEEL

1700-12-24-SS

$504.94

Attribute: 1700-12-24-SS (12MJ-24Flange Str...)

Stock Status: True

TUBE O.D.	3/4
1 THREAD	1-1/16-12
2 FLANGE	1-1/2
L (IN.)	2.800
A/F (IN.)	1.500
MATERIAL	STAINLESS STEEL

1700-16-12

$34.30

Attribute: 1700-16-12 (16MJ-12Flange Straig...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1-5/16-12
2 FLANGE	3/4
L (IN.)	2.750
A/F (IN.)	1.375
MATERIAL	STEEL

1700-16-12-SS

$403.90

Attribute: 1700-16-12-SS (16MJ-12Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1 5/16-12 UN
2 FLANGE	3/4
L (IN.)	2.75
A/F (IN.)	1 3/8
MATERIAL	STAINLESS STEEL

1700-16-16

$43.90

Attribute: 1700-16-16 (16MJ-16Flange Straig...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1 5/16-12
2 FLANGE	1
L (IN.)	2.800
A/F (IN.)	1.625
MATERIAL	STEEL

1700-16-16-SS

$366.82

Attribute: 1700-16-16-SS (16MJ-16Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1 5/16-12 UN
2 FLANGE	1
L (IN.)	2.80
A/F (IN.)	1 3/8
MATERIAL	STAINLESS STEEL

1700-16-16X3.60

$132.67

Attribute: 1700-16-16X3.60 (16MJ-16Flange S...)

Stock Status: True

MATERIAL	STEEL

1700-16-20

$58.70

Attribute: 1700-16-20 (16MJ-20Flange Straig...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1-5/16-12
2 FLANGE	1 1/4
L (IN.)	2.800
A/F (IN.)	1.375
MATERIAL	STEEL

1700-16-20-SS

$451.45

Attribute: 1700-16-20-SS (16MJ-20Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1 5/16-12 UN
2 FLANGE	1 1/4
L (IN.)	2.80
A/F (IN.)	1 3/8
MATERIAL	STAINLESS STEEL

1700-16-24

$107.53

Attribute: 1700-16-24 (16MJ-24Flange Straig...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1 5/16-12
2 FLANGE	1 1/2
L (IN.)	2.800
A/F (IN.)	1.687
MATERIAL	STEEL

1700-16-24-SS

$726.10

Attribute: 1700-16-24-SS (16MJ-24Flange Str...)

Stock Status: True

TUBE O.D.	1
1 THREAD	1 5/16-12 UN
2 FLANGE	1 1/2
L (IN.)	2.80
A/F (IN.)	1.6875
MATERIAL	STAINLESS STEEL

1700-20-16

$55.62

Attribute: 1700-20-16 (20MJ-16Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12
2 FLANGE	1
L (IN.)	2.800
A/F (IN.)	1.625
MATERIAL	STEEL

1700-20-16-SS

$396.00

Attribute: 1700-20-16-SS (20MJ-16Flange Str...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12 UN
2 FLANGE	1
L (IN.)	2.80
A/F (IN.)	1 11/16
MATERIAL	STAINLESS STEEL

1700-20-20

$55.79

Attribute: 1700-20-20 (20MJ-20Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12
2 FLANGE	1 1/4
L (IN.)	2.80
A/F (IN.)	1 11/16
MATERIAL	STEEL

1700-20-20-SS

$355.23

Attribute: 1700-20-20-SS (20MJ-20Flange Str...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12 UN
2 FLANGE	1 1/4
L (IN.)	2.80
A/F (IN.)	1 11/16
MATERIAL	STAINLESS STEEL

1700-20-24

$98.53

Attribute: 1700-20-24 (20MJ-24Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12
2 FLANGE	1 1/2
L (IN.)	3.375
A/F (IN.)	2.125
MATERIAL	STEEL

1700-20-24-SS

$613.83

Attribute: 1700-20-24-SS (20MJ-24Flange Str...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12 UN
2 FLANGE	1 1/2
L (IN.)	2.80
A/F (IN.)	1 11/16
MATERIAL	STEEL

1700-20-32

$142.79

Attribute: 1700-20-32 (20MJ-32Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12
2 FLANGE	2
L (IN.)	3.50
A/F (IN.)	1 11/16
MATERIAL	STEEL

1700-20-32-SS

$698.69

Attribute: 1700-20-32-SS (20MJ-32Flange Str...)

Stock Status: True

TUBE O.D.	1 1/4
1 THREAD	1 5/8-12 UN
2 FLANGE	2
L (IN.)	3.50
A/F (IN.)	1 11/16
MATERIAL	STAINLESS STEEL

1700-24-16

$92.60

Attribute: 1700-24-16 (24MJ-16Flange Straig...)

Stock Status: True

TUBE O.D.	1-1/2
1 THREAD	1 7/8-12
2 FLANGE	1
L (IN.)	3.130
A/F (IN.)	1.875
MATERIAL	STEEL

1700-24-16-SS

$717.66

Attribute: 1700-24-16-SS (24MJ-16Flange Str...)

Stock Status: True

TUBE O.D.	1-1/2
1 THREAD	1-7/8-12
2 FLANGE	1
L (IN.)	3.500
A/F (IN.)	2.000
MATERIAL	STAINLESS STEEL

1700-24-20

$114.03

Attribute: 1700-24-20 (24MJ-20Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	1 7/8-12
2 FLANGE	1 1/4
L (IN.)	3.40
A/F (IN.)	2
MATERIAL	STEEL

1700-24-20-SS

$764.10

Attribute: 1700-24-20-SS (24MJ-20Flange Str...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	1 7/18-12 UN
2 FLANGE	1 1/4
L (IN.)	3.40
A/F (IN.)	2
MATERIAL	STAINLESS STEEL

1700-24-24

$74.83

Attribute: 1700-24-24 (24MJ-24Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	1 7/8-12
2 FLANGE	1 1/2
L (IN.)	3.50
A/F (IN.)	2
MATERIAL	STEEL

1700-24-24-SS

$606.05

Attribute: 1700-24-24-SS (24MJ-24Flange Str...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	1 7/8-12 UN
2 FLANGE	1 1/2
L (IN.)	3.50
A/F (IN.)	2
MATERIAL	STAINLESS STEEL

1700-24-32

$127.32

Attribute: 1700-24-32 (24MJ-32Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	1 7/8-12
2 FLANGE	2
L (IN.)	3.730
A/F (IN.)	2.000
MATERIAL	STEEL

1700-24-32-SS

$816.76

Attribute: 1700-24-32-SS (24MJ-32Flange Str...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	1 7/8-12 UN
2 FLANGE	2
L (IN.)	3.73
A/F (IN.)	2
MATERIAL	STAINLESS STEEL

1700-24-40

$153.24

Attribute: 1700-24-40 (24MJ-40Flange Straig...)

Stock Status: True

TUBE O.D.	1 1/2
1 THREAD	2 7/8-12
2 FLANGE	2 1/2
L (IN.)	3.97
MATERIAL	STEEL

1700-32-24

$142.71

Attribute: 1700-32-24 (32MJ-24Flange Straig...)

Stock Status: True

TUBE O.D.	2
1 THREAD	2 1/2-12
2 FLANGE	1 1/2
L (IN.)	4.20
A/F (IN.)	2.622
MATERIAL	STEEL

1700-32-24-SS

$723.21

Attribute: 1700-32-24-SS (32MJ-24Flange Str...)

Stock Status: True

TUBE O.D.	2
1 THREAD	2 1/2-12 UN
2 FLANGE	1 1/2
L (IN.)	4.20
A/F (IN.)	2.625
MATERIAL	STAINLESS STEEL

1700-32-32

$144.48

Attribute: 1700-32-32 (32MJ-32Flange Straig...)

Stock Status: True

TUBE O.D.	2
1 THREAD	2-1/2-12
2 FLANGE	2
L (IN.)	3.980
A/F (IN.)	2.625
MATERIAL	STEEL

1700-32-32-SS

$903.68

Attribute: 1700-32-32-SS (32MJ-32Flange Str...)

Stock Status: True

TUBE O.D.	2
1 THREAD	2 1/2-12 UN
2 FLANGE	2
L (IN.)	3.98
A/F (IN.)	2 5/8
MATERIAL	STAINLESS STEEL

1700-32-40

$154.47

Attribute: 1700-32-40 (32MJ-40Flange Straig...)

Stock Status: True

TUBE O.D.	2
1 THREAD	2 1/2-12
2 FLANGE	2 1/2
L (IN.)	3.638
A/F (IN.)	2.750
MATERIAL	STEEL

1700-32-40-SS

$1,180.83

Attribute: 1700-32-40-SS (32MJ-40Flange Str...)

Stock Status: True

TUBE O.D.	2
1 THREAD	2-1/2-12
2 FLANGE	2-1/2
L (IN.)	3.638
A/F (IN.)	2.750
MATERIAL	STAINLESS STEEL

1700-40-40

$259.38

Attribute: 1700-40-40 (40MJ-40Flange Straig...)

Stock Status: True

TUBE O.D.	2 1/2
1 THREAD	3-12
2 FLANGE	2 1/2
L (IN.)	4.209
A/F (IN.)	3.250
MATERIAL	STEEL

1700-40-40-SS

$1,236.09

Attribute: 1700-40-40-SS (40MJ-40Flange Str...)

Stock Status: True

TUBE O.D.	2-1/2
1 THREAD	3-12 UN-2A
2 FLANGE	2-1/2
L (IN.)	4.209
A/F (IN.)	3.250
MATERIAL	STAINLESS STEEL

Connections	JIC, Flange
Shape	Straight

ID	10151572
Category	Flange Fittings

Description

Description
