FS7650-NWO-FG-ISO 6149

FS7650-04-14-NWO-FG

$22.94

Attribute: FS7650-04-14-NWO-FG (04MFS-14MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	9/16-18
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M14X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-04-14-NWO-FG-VITON

$30.08

Attribute: FS7650-04-14-NWO-FG-VITON (04MFS...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	9/16-18
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M14X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	VITON
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-06-12-NWO-FG

$19.64

Attribute: FS7650-06-12-NWO-FG (06MFS-12MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	11/16-16
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M12X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-06-14-NWO-FG

$30.28

Attribute: FS7650-06-14-NWO-FG (06MFS-14MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	11/16-16
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M14X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-06-16-NWO-FG

$27.61

Attribute: FS7650-06-16-NWO-FG (06MFS-16MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	11/16-16
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M16X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-06-18-NWO-FG

$36.03

Attribute: FS7650-06-18-NWO-FG (06MFS-18MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	11/16-16
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M18X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-08-18-NWO-FG

$9.26

Attribute: FS7650-08-18-NWO-FG (08MFS-18MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	13/16-16
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M18X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-08-22-NWO-FG

$31.45

Attribute: FS7650-08-22-NWO-FG (08MFS-22MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	13/16-16
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M22X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-10-27-NWO-FG

$40.76

Attribute: FS7650-10-27-NWO-FG (10MFS-27MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-14
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M27X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-12-22-NWO-FG

$41.30

Attribute: FS7650-12-22-NWO-FG (12MFS-22MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-3/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M22X1.5
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-12-27-NWO-FG

$48.49

Attribute: FS7650-12-27-NWO-FG (12MFS-27MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-3/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M27X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-12-27-NWO-FG-VITON

$55.63

Attribute: FS7650-12-27-NWO-FG-VITON (12MFS...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-3/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M27X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	VITON
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-12-33-NWO-FG

$45.08

Attribute: FS7650-12-33-NWO-FG (12MFS-33MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-3/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M33X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-16-27-NWO-FG

$104.41

Attribute: FS7650-16-27-NWO-FG (16MFS-27MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-7/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M27X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-16-33-NWO-FG

$149.74

Attribute: FS7650-16-33-NWO-FG (16MFS-33MMA...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-7/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M33X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-16-33-NWO-FG-VITON

$156.88

Attribute: FS7650-16-33-NWO-FG-VITON (16MFS...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	1-7/16-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M33X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	VITON
CALIFORNIA RESIDENTS	PROP-65 WARNING

FS7650-24-48-NWO-FG-VITON

$87.05

Attribute: FS7650-24-48-NWO-FG-VITON (24MFS...)

Stock Status: True

THREAD TYPE B1	MALE FACE SEAL O-RING
THREAD SIZE B1	2-12
THREAD SPECIFICATION B1	SAE J1453
THREAD TYPE B2	MALE METRIC ADJUSTABLE ISO6149
THREAD SIZE B2	M48X2.0
THREAD SPECIFICATION B2	ISO 6149 O-RING PORT
SHAPE	90 DEGREE ANGLE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	VITON
CALIFORNIA RESIDENTS	PROP-65 WARNING

ID	10151530
Category	Conversion Adapters

Description

Description

Variations (17)

FS7650-04-14-NWO-FG

FS7650-04-14-NWO-FG-VITON

FS7650-06-12-NWO-FG

FS7650-06-14-NWO-FG

FS7650-06-16-NWO-FG

FS7650-06-18-NWO-FG

FS7650-08-18-NWO-FG

FS7650-08-22-NWO-FG

FS7650-10-27-NWO-FG

FS7650-12-22-NWO-FG

FS7650-12-27-NWO-FG

FS7650-12-27-NWO-FG-VITON

FS7650-12-33-NWO-FG

FS7650-16-27-NWO-FG

FS7650-16-33-NWO-FG

FS7650-16-33-NWO-FG-VITON

FS7650-24-48-NWO-FG-VITON
