9025-BS

Attribute: 9025-04-14-BS (04MBSPP-M14X1.5 S...)

Stock Status: True

THREAD TYPE B1	MALE BSPP WITH 60 DEGREE SEAT
THREAD SIZE B1	1/4-19
THREAD DRILL B1 (MM)	4.7
THREAD SPECIFICATION B1	FOR ISO 1179 PORT
ASSEMBLED BSPP BONDED SEAL	9900-04
THREAD TYPE B2	MALE METRIC WITH 60 DEG SEAT
THREAD SIZE B2	M14X1.5
THREAD DRILL B2 (MM)	4.7
THREAD SPECIFICATION B2	FOR ISO 9974 PORT
ASSEMBLED METRIC BONDED SEAL	8800-14
BODY HEX (MM)	19.0
OVERALL LENGTH L (MM)	32.0
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
O-RING / SEAL MATERIAL	NBR
WEIGHT (LBS)	0.179
MAXIMUM DYNAMIC PRESSURE (PSI)	5,000
CALIFORNIA RESIDENTS	PROP-65 WARNING
CUBIC INCH SPACE (L X W X H)	0.705
