Description
KOMATSU CAP
Description
Variations (6)
7699-C-14
$17.47Attribute: 7699-C-14 (14FK Komatsu Cap (M14...)
Stock Status: True
| THREAD TYPE B1 | FEMALE KOMATSU |
|---|---|
| THREAD SIZE B1 | M14X1.5 |
| THREAD SPECIFICATION B1 | ISO 261 |
| BODY HEX (MM) | 19.0 |
| OVERALL LENGTH L (MM) | 22.5 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.094 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
7699-C-18
$26.98Attribute: 7699-C-18 (18FK Komatsu Cap (M18...)
Stock Status: True
| THREAD TYPE B1 | FEMALE KOMATSU |
|---|---|
| THREAD SIZE B1 | M18X1.5 |
| THREAD SPECIFICATION B1 | ISO 261 |
| BODY HEX (MM) | 24.0 |
| OVERALL LENGTH L (MM) | 24.0 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.143 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
7699-C-22
$27.27Attribute: 7699-C-22 (22FK Komatsu Cap (M22...)
Stock Status: True
| THREAD TYPE B1 | FEMALE KOMATSU |
|---|---|
| THREAD SIZE B1 | M22X1.5 |
| THREAD SPECIFICATION B1 | ISO 261 |
| BODY HEX (MM) | 27.0 |
| OVERALL LENGTH L (MM) | 29.0 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.200 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
7699-C-24
$62.51Attribute: 7699-C-24 (24FK Komatsu Cap (M24...)
Stock Status: True
| THREAD TYPE B1 | FEMALE KOMATSU |
|---|---|
| THREAD SIZE B1 | M24X1.5 |
| THREAD SPECIFICATION B1 | ISO 261 |
| BODY HEX (MM) | 32.0 |
| OVERALL LENGTH L (MM) | 29.5 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.212 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
7699-C-30
$49.18Attribute: 7699-C-30 (30FK Komatsu Cap (M30...)
Stock Status: True
| THREAD TYPE B1 | FEMALE KOMATSU |
|---|---|
| THREAD SIZE B1 | M30X1.5 |
| THREAD SPECIFICATION B1 | ISO 261 |
| BODY HEX (MM) | 41.0 |
| OVERALL LENGTH L (MM) | 33.5 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.244 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
7699-C-33
$56.36Attribute: 7699-C-33 (33FK Komatsu Cap (M33...)
Stock Status: True
| THREAD TYPE B1 | FEMALE KOMATSU |
|---|---|
| THREAD SIZE B1 | M33X1.5 |
| THREAD SPECIFICATION B1 | ISO 261 |
| BODY HEX (MM) | 41.0 |
| OVERALL LENGTH L (MM) | 35.0 |
| SHAPE | STRAIGHT |
| BODY MATERIAL | STEEL |
| RAW MATERIAL TYPE | STRAIGHT STEEL |
| PLATING | CR3 |
| WEIGHT (LBS) | 0.263 |
| CALIFORNIA RESIDENTS | PROP-65 WARNING |
General Attributes
| Connections | Other |
|---|---|
| Shape | Cap |
