Conversion Adapters

7088-F

Scraped 2026-02-15 08:27:38

Description

Description

MJ-FJISS STRAIGHT. FEMALE JIS SWIVEL

Variations (2)

7088-F-06-06

$38.20

Attribute: 7088-F-06-06 (06MJ-06FJISS Strai...)

Stock Status: True

THREAD TYPE B1MALE JIC SAE 37 DEGREE FLARE
THREAD SIZE B19/16-18
THREAD SPECIFICATION B1SAE J514
THREAD TYPE B2FEMALE JIS SWIVEL 30 DEG FLARE
THREAD SIZE B23/8-19
THREAD SPECIFICATION B2JIS B 0202
SHAPESTRAIGHT
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
CALIFORNIA RESIDENTSPROP-65 WARNING

7088-F-08-08

$43.45

Attribute: 7088-F-08-08 (08MJ-08FJISS Strai...)

Stock Status: True

THREAD TYPE B1MALE JIC SAE 37 DEGREE FLARE
THREAD SIZE B13/4-16
THREAD SPECIFICATION B1SAE J514
THREAD TYPE B2FEMALE JIS SWIVEL 30 DEG FLARE
THREAD SIZE B21/2-14
THREAD SPECIFICATION B2JIS B 0202
SHAPESTRAIGHT
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
CALIFORNIA RESIDENTSPROP-65 WARNING

General Attributes

Connections JIC, Other
Shape Straight
