6606-FG

6606-04-04-04-FG

$46.76

Attribute: 6606-04-04-04-FG (04FJS-04FJS-04...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	7/16-20
THREAD B1 DRILL IN	0.172
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	7/16-20
THREAD B2 DRILL IN	0.172
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	7/16-20
THREAD 3 DRILL IN	0.172
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.438
C HEX 1 IN	0.563
C HEX 2 IN	0.563
C HEX 3 IN	0.563
OVERALL LENGTH L IN	1.000
OVERALL LENGTH L2 IN	0.650
CENTERLINE LENGTH M IN	1.000
CENTERLINE LENGTH M2 IN	1.000
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
WEIGHT LBS	0.1125
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-04-04-04-SS

$343.68

Attribute: 6606-04-04-04-SS (04FJS-04FJS-04...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	7/16-20
THREAD B1 DRILL IN	0.172
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	7/16-20
THREAD B2 DRILL IN	0.172
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	7/16-20
THREAD 3 DRILL IN	0.172
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.438
C HEX 1 IN	0.563
C HEX 2 IN	0.563
C HEX 3 IN	0.563
OVERALL LENGTH L IN	1.000
OVERALL LENGTH L2 IN	0.650
CENTERLINE LENGTH M IN	1.000
CENTERLINE LENGTH M2 IN	1.000
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.15
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-05-05-05-FG

$92.23

Attribute: 6606-05-05-05-FG (05FJS-05FJS-05...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1/2-20
THREAD B1 DRILL IN	0.234
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1/2-20
THREAD B2 DRILL IN	0.234
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1/2-20
THREAD 3 DRILL IN	0.234
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-06-06-06-FG

$50.85

Attribute: 6606-06-06-06-FG (06FJS-06FJS-06...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	9/16-18
THREAD B1 DRILL IN	0.297
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	9/16-18
THREAD B2 DRILL IN	0.297
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	9/16-18
THREAD 3 DRILL IN	0.297
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.562
C HEX 1 IN	0.688
C HEX 2 IN	0.688
C HEX 3 IN	0.688
OVERALL LENGTH L IN	1.250
OVERALL LENGTH L2 IN	0.870
CENTERLINE LENGTH M IN	1.250
CENTERLINE LENGTH M2 IN	1.250
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
WEIGHT LBS	0.175
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-06-06-06-SS

$443.51

Attribute: 6606-06-06-06-SS (06FJS-06FJS-06...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	9/16-18
THREAD B1 DRILL IN	0.297
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	9/16-18
THREAD B2 DRILL IN	0.297
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	9/16-18
THREAD 3 DRILL IN	0.297
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.562
C HEX 1 IN	0.688
C HEX 2 IN	0.688
C HEX 3 IN	0.688
OVERALL LENGTH L IN	1.250
OVERALL LENGTH L2 IN	0.870
CENTERLINE LENGTH M IN	1.250
CENTERLINE LENGTH M2 IN	1.250
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.2812
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-08-08-08-FG

$72.32

Attribute: 6606-08-08-08-FG (08FJS-08FJS-08...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	3/4-16
THREAD B1 DRILL IN	0.391
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	3/4-16
THREAD B2 DRILL IN	0.391
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	3/4-16
THREAD 3 DRILL IN	0.391
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.750
C HEX 1 IN	0.875
C HEX 2 IN	0.875
C HEX 3 IN	0.875
OVERALL LENGTH L IN	1.380
OVERALL LENGTH L2 IN	0.950
CENTERLINE LENGTH M IN	1.380
CENTERLINE LENGTH M2 IN	1.380
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
WEIGHT LBS	0.3187
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-08-08-08-SS

$461.13

Attribute: 6606-08-08-08-SS (08FJS-08FJS-08...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	3/4-16
THREAD B1 DRILL IN	0.391
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	3/4-16
THREAD B2 DRILL IN	0.391
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	3/4-16
THREAD 3 DRILL IN	0.391
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.750
C HEX 1 IN	0.875
C HEX 2 IN	0.875
C HEX 3 IN	0.875
OVERALL LENGTH L IN	1.380
OVERALL LENGTH L2 IN	0.950
CENTERLINE LENGTH M IN	1.380
CENTERLINE LENGTH M2 IN	1.380
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.325
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-10-10-10-FG

$73.89

Attribute: 6606-10-10-10-FG (10FJS-10FJS-10...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	7/8-14
THREAD B1 DRILL IN	0.484
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	7/8-14
THREAD B2 DRILL IN	0.484
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	7/8-14
THREAD 3 DRILL IN	0.484
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	0.875
C HEX 1 IN	1.000
C HEX 2 IN	1.000
C HEX 3 IN	1.000
OVERALL LENGTH L IN	1.620
OVERALL LENGTH L2 IN	1.120
CENTERLINE LENGTH M IN	1.620
CENTERLINE LENGTH M2 IN	1.620
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
WEIGHT LBS	0.4937
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-12-12-12-FG

$104.55

Attribute: 6606-12-12-12-FG (12FJS-12FJS-12...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-1/16-12
THREAD B1 DRILL IN	0.609
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-1/16-12
THREAD B2 DRILL IN	0.609
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-1/16-12
THREAD 3 DRILL IN	0.609
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	1.062
C HEX 1 IN	1.250
C HEX 2 IN	1.250
C HEX 3 IN	1.250
OVERALL LENGTH L IN	1.750
OVERALL LENGTH L2 IN	1.180
CENTERLINE LENGTH M IN	1.750
CENTERLINE LENGTH M2 IN	1.750
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
WEIGHT LBS	0.8
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-12-12-12-SS

$707.90

Attribute: 6606-12-12-12-SS (12FJS-12FJS-12...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-1/16-12
THREAD B1 DRILL IN	0.609
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-1/16-12
THREAD B2 DRILL IN	0.609
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-1/16-12
THREAD 3 DRILL IN	0.609
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	1.062
C HEX 1 IN	1.250
C HEX 2 IN	1.250
C HEX 3 IN	1.250
OVERALL LENGTH L IN	1.750
OVERALL LENGTH L2 IN	1.180
CENTERLINE LENGTH M IN	1.750
CENTERLINE LENGTH M2 IN	1.750
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	1.4187
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-16-16-16-FG

$141.12

Attribute: 6606-16-16-16-FG (16FJS-16FJS-16...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-5/16-12
THREAD B1 DRILL IN	0.844
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-5/16-12
THREAD B2 DRILL IN	0.844
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-5/16-12
THREAD 3 DRILL IN	0.844
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	1.312
C HEX 1 IN	1.500
C HEX 2 IN	1.500
C HEX 3 IN	1.500
OVERALL LENGTH L IN	2.000
OVERALL LENGTH L2 IN	1.400
CENTERLINE LENGTH M IN	2.000
CENTERLINE LENGTH M2 IN	2.000
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
WEIGHT LBS	1.1812
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-16-16-16-SS

$1,086.03

Attribute: 6606-16-16-16-SS (16FJS-16FJS-16...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-5/16-12
THREAD B1 DRILL IN	0.844
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-5/16-12
THREAD B2 DRILL IN	0.844
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-5/16-12
THREAD 3 DRILL IN	0.844
THREAD 3 SPECIFICATION	SAE J514
BODY HEX IN	1.312
C HEX 1 IN	1.500
C HEX 2 IN	1.500
C HEX 3 IN	1.500
OVERALL LENGTH L IN	2.000
OVERALL LENGTH L2 IN	1.400
CENTERLINE LENGTH M IN	2.000
CENTERLINE LENGTH M2 IN	2.000
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	1.225
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-20-20-20-FG

$249.33

Attribute: 6606-20-20-20-FG (20FJS-20FJS-20...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-5/8-12
THREAD B1 DRILL IN	1.078
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-5/8-12
THREAD B2 DRILL IN	1.078
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-5/8-12
THREAD 3 DRILL IN	1.078
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-20-20-20-SS

$1,441.08

Attribute: 6606-20-20-20-SS (20FJS-20FJS-20...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-5/8-12
THREAD B1 DRILL IN	1.078
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-5/8-12
THREAD B2 DRILL IN	1.078
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-5/8-12
THREAD 3 DRILL IN	1.078
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-24-24-24-FG

$451.93

Attribute: 6606-24-24-24-FG (24FJS-24FJS-24...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-7/8-12
THREAD B1 DRILL IN	1.312
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-7/8-12
THREAD B2 DRILL IN	1.312
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-7/8-12
THREAD 3 DRILL IN	1.312
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-24-24-24-SS

$1,833.55

Attribute: 6606-24-24-24-SS (24FJS-24FJS-24...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	1-7/8-12
THREAD B1 DRILL IN	1.312
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	1-7/8-12
THREAD B2 DRILL IN	1.312
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	1-7/8-12
THREAD 3 DRILL IN	1.312
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	3.3
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-32-32-32-FG

$900.85

Attribute: 6606-32-32-32-FG (32FJS-32FJS-32...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	2-1/2-12
THREAD B1 DRILL IN	1.781
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	2-1/2-12
THREAD B2 DRILL IN	1.781
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	2-1/2-12
THREAD 3 DRILL IN	1.781
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STEEL FORGING
PLATING	CR3
CALIFORNIA RESIDENTS	PROP-65 WARNING

6606-32-32-32-SS

$4,357.43

Attribute: 6606-32-32-32-SS (32FJS-32FJS-32...)

Stock Status: True

THREAD B1 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B1 SIZE	2-1/2-12
THREAD B1 DRILL IN	1.781
THREAD B1 SPECIFICATION	SAE J514
THREAD B2 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD B2 SIZE	2-1/2-12
THREAD B2 DRILL IN	1.781
THREAD B2 SPECIFICATION	SAE J514
THREAD 3 TYPE	FEMALE JIC SWIVEL 37 DEG FLARE
THREAD 3 SIZE	2-1/2-12
THREAD 3 DRILL IN	1.781
THREAD 3 SPECIFICATION	SAE J514
SHAPE	TEE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTS	PROP-65 WARNING

Connections	JIC
Shape	Tee

ID	10146440
Category	Tube Fittings and Adapters

Description

Description

Variations (18)

6606-04-04-04-FG

6606-04-04-04-SS

6606-05-05-05-FG

6606-06-06-06-FG

6606-06-06-06-SS

6606-08-08-08-FG

6606-08-08-08-SS

6606-10-10-10-FG

6606-12-12-12-FG

6606-12-12-12-SS

6606-16-16-16-FG

6606-16-16-16-SS

6606-20-20-20-FG

6606-20-20-20-SS

6606-24-24-24-FG

6606-24-24-24-SS

6606-32-32-32-FG

6606-32-32-32-SS

General Attributes

PDF Documents
