Tube Fittings and Adapters

5655-FG

Scraped 2026-02-15 08:27:45

Description

Description

MP-FP-FP-FP Cross

Variations (6)

5655-04-04-04-04-FG

$41.54

Attribute: 5655-04-04-04-04-FG (04MP-04FP-0...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/4-18
THREAD B1 DRILL IN0.281
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/4-18
THREAD B2 DRILL IN0.281
THREAD B2 SPECIFICATIONSAE J476
THREAD 3 TYPEFEMALE NPTF
THREAD 3 SIZE1/4-18
THREAD 3 DRILL IN0.281
THREAD 3 SPECIFICATIONSAE J476
THREAD 4 TYPEFEMALE NPTF
THREAD 4 SIZE1/4-18
THREAD 4 DRILL IN0.281
THREAD 4 SPECIFICATIONSAE J476
BODY HEX IN0.750
OVERALL LENGTH L IN1.970
OVERALL LENGTH L2 IN1.760
CENTERLINE LENGTH M IN1.090
CENTERLINE LENGTH M2 IN0.880
CENTERLINE LENGTH M3 IN0.880
CENTERLINE LENGTH M4 IN0.880
SHAPECROSS
BODY MATERIALSTEEL
RAW MATERIAL TYPESTEEL FORGING
PLATINGCR3
WEIGHT LBS0.225
CALIFORNIA RESIDENTSPROP-65 WARNING

5655-06-06-06-06-FG

$52.18

Attribute: 5655-06-06-06-06-FG (06MP-06FP-0...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE3/8-18
THREAD B1 DRILL IN0.406
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE3/8-18
THREAD B2 DRILL IN0.406
THREAD B2 SPECIFICATIONSAE J476
THREAD 3 TYPEFEMALE NPTF
THREAD 3 SIZE3/8-18
THREAD 3 DRILL IN0.406
THREAD 3 SPECIFICATIONSAE J476
THREAD 4 TYPEFEMALE NPTF
THREAD 4 SIZE3/8-18
THREAD 4 DRILL IN0.406
THREAD 4 SPECIFICATIONSAE J476
BODY HEX IN0.875
OVERALL LENGTH L IN2.240
OVERALL LENGTH L2 IN2.040
CENTERLINE LENGTH M IN1.220
CENTERLINE LENGTH M2 IN1.020
CENTERLINE LENGTH M3 IN1.020
CENTERLINE LENGTH M4 IN1.020
SHAPECROSS
BODY MATERIALSTEEL
RAW MATERIAL TYPESTEEL FORGING
PLATINGCR3
WEIGHT LBS0.325
CALIFORNIA RESIDENTSPROP-65 WARNING

5655-08-08-08-08-FG

$114.44

Attribute: 5655-08-08-08-08-FG (08MP-08FP-0...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/2-14
THREAD B1 DRILL IN0.531
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/2-14
THREAD B2 DRILL IN0.531
THREAD B2 SPECIFICATIONSAE J476
THREAD 3 TYPEFEMALE NPTF
THREAD 3 SIZE1/2-14
THREAD 3 DRILL IN0.531
THREAD 3 SPECIFICATIONSAE J476
THREAD 4 TYPEFEMALE NPTF
THREAD 4 SIZE1/2-14
THREAD 4 DRILL IN0.531
THREAD 4 SPECIFICATIONSAE J476
BODY HEX IN1.062
OVERALL LENGTH L IN2.700
OVERALL LENGTH L2 IN2.460
CENTERLINE LENGTH M IN1.470
CENTERLINE LENGTH M2 IN1.230
CENTERLINE LENGTH M3 IN1.230
CENTERLINE LENGTH M4 IN1.230
SHAPECROSS
BODY MATERIALSTEEL
RAW MATERIAL TYPESTEEL FORGING
PLATINGCR3
WEIGHT LBS0.538
CALIFORNIA RESIDENTSPROP-65 WARNING

5655-12-12-12-12-FG

$139.85

Attribute: 5655-12-12-12-12-FG (12MP-12FP-1...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE3/4-14
THREAD B1 DRILL IN0.719
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE3/4-14
THREAD B2 DRILL IN0.719
THREAD B2 SPECIFICATIONSAE J476
THREAD 3 TYPEFEMALE NPTF
THREAD 3 SIZE3/4-14
THREAD 3 DRILL IN0.719
THREAD 3 SPECIFICATIONSAE J476
THREAD 4 TYPEFEMALE NPTF
THREAD 4 SIZE3/4-14
THREAD 4 DRILL IN0.719
THREAD 4 SPECIFICATIONSAE J476
BODY HEX IN1.312
OVERALL LENGTH L IN2.950
OVERALL LENGTH L2 IN2.720
CENTERLINE LENGTH M IN1.590
CENTERLINE LENGTH M2 IN1.360
CENTERLINE LENGTH M3 IN1.360
CENTERLINE LENGTH M4 IN1.360
SHAPECROSS
BODY MATERIALSTEEL
RAW MATERIAL TYPESTEEL FORGING
PLATINGCR3
WEIGHT LBS0.8187
CALIFORNIA RESIDENTSPROP-65 WARNING

5655-16-16-16-16-FG

$239.72

Attribute: 5655-16-16-16-16-FG (16MP-16FP-1...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1-11-1/2
THREAD B1 DRILL IN0.938
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1-11-1/2
THREAD B2 DRILL IN0.938
THREAD B2 SPECIFICATIONSAE J476
THREAD 3 TYPEFEMALE NPTF
THREAD 3 SIZE1-11-1/2
THREAD 3 DRILL IN0.938
THREAD 3 SPECIFICATIONSAE J476
THREAD 4 TYPEFEMALE NPTF
THREAD 4 SIZE1-11-1/2
THREAD 4 DRILL IN0.938
THREAD 4 SPECIFICATIONSAE J476
BODY HEX IN1.625
OVERALL LENGTH L IN3.590
OVERALL LENGTH L2 IN3.240
CENTERLINE LENGTH M IN1.970
CENTERLINE LENGTH M2 IN1.620
CENTERLINE LENGTH M3 IN1.620
CENTERLINE LENGTH M4 IN1.620
SHAPECROSS
BODY MATERIALSTEEL
RAW MATERIAL TYPESTEEL FORGING
PLATINGCR3
WEIGHT LBS1.4375
CALIFORNIA RESIDENTSPROP-65 WARNING

5655-20-16-08-08-FG

$405.81

Attribute: 5655-20-16-08-08-FG (20MP-16FP-0...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1-1/4-11-1/2
THREAD B1 DRILL IN1.250
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1-11-1/2
THREAD B2 DRILL IN0.938
THREAD B2 SPECIFICATIONSAE J476
THREAD 3 TYPEFEMALE NPTF
THREAD 3 SIZE1/2-14
THREAD 3 DRILL IN0.531
THREAD 3 SPECIFICATIONSAE J476
THREAD 4 TYPEFEMALE NPTF
THREAD 4 SIZE1/2-14
THREAD 4 DRILL IN0.531
THREAD 4 SPECIFICATIONSAE J476
BODY HEX IN1.625
OVERALL LENGTH L IN4.000
OVERALL LENGTH L2 IN3.240
CENTERLINE LENGTH M IN2.380
CENTERLINE LENGTH M2 IN1.620
CENTERLINE LENGTH M3 IN1.620
CENTERLINE LENGTH M4 IN1.620
SHAPECROSS
BODY MATERIALSTEEL
RAW MATERIAL TYPESTEEL FORGING
PLATINGCR3
WEIGHT LBS2.4687
CALIFORNIA RESIDENTSPROP-65 WARNING

General Attributes

Connections NPT
Shape Cross
