5406-SHP

5406-SHP-02

$7.98

Attribute: 5406-SHP-02 (02 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/8-27
THREAD B1 DRILL IN	0.220
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.281
OVERALL LENGTH L IN	0.630
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.0187
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-02-SS

$18.80

Attribute: 5406-SHP-02-SS (02 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/8-27
THREAD B1 DRILL IN	0.220
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.281
OVERALL LENGTH L IN	0.630
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.0187
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-04

$3.10

Attribute: 5406-SHP-04 (04 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/4-18
THREAD B1 DRILL IN	0.281
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.375
OVERALL LENGTH L IN	0.750
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.0365
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-04-B

$4.56

Attribute: 5406-SHP-04-B (04 NPTF Square He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/4-18
THREAD B1 DRILL IN	0.281
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.375
OVERALL LENGTH L IN	0.750
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.0387
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-04-SS

$20.93

Attribute: 5406-SHP-04-SS (04 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/4-18
THREAD B1 DRILL IN	0.281
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.375
OVERALL LENGTH L IN	0.750
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.0375
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-06

$2.21

Attribute: 5406-SHP-06 (06 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/8-18
THREAD B1 DRILL IN	0.406
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.437
OVERALL LENGTH L IN	0.780
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.06
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-06-B

$5.75

Attribute: 5406-SHP-06-B (06 NPTF Square He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/8-18
THREAD B1 DRILL IN	0.406
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.437
OVERALL LENGTH L IN	0.780
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.0375
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-06-SS

$30.62

Attribute: 5406-SHP-06-SS (06 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/8-18
THREAD B1 DRILL IN	0.406
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.437
OVERALL LENGTH L IN	0.780
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.0562
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-08

$3.34

Attribute: 5406-SHP-08 (08 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/2-14
THREAD B1 DRILL IN	0.531
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.563
OVERALL LENGTH L IN	1.020
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.12
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-08-B

$17.45

Attribute: 5406-SHP-08-B (08 NPTF Square He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/2-14
THREAD B1 DRILL IN	0.531
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.563
OVERALL LENGTH L IN	1.020
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.125
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-08-SS

$59.01

Attribute: 5406-SHP-08-SS (08 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/2-14
THREAD B1 DRILL IN	0.531
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.563
OVERALL LENGTH L IN	1.020
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.1125
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-12

$8.08

Attribute: 5406-SHP-12 (12 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/4-14
THREAD B1 DRILL IN	0.719
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.625
OVERALL LENGTH L IN	1.100
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.19
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-12-B

$20.06

Attribute: 5406-SHP-12-B (12 NPTF Square He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/4-14
THREAD B1 DRILL IN	0.719
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.625
OVERALL LENGTH L IN	1.100
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-12-SS

$172.73

Attribute: 5406-SHP-12-SS (12 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/4-14
THREAD B1 DRILL IN	0.719
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.625
OVERALL LENGTH L IN	1.100
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.1875
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-16

$28.69

Attribute: 5406-SHP-16 (16 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-11-1/2
THREAD B1 DRILL IN	0.907
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.812
OVERALL LENGTH L IN	1.300
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.35
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-16-SS

$450.35

Attribute: 5406-SHP-16-SS (16 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-11-1/2
THREAD B1 DRILL IN	0.907
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.812
OVERALL LENGTH L IN	1.300
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.3625
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-20

$65.18

Attribute: 5406-SHP-20 (20 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/4-11-1/2
THREAD B1 DRILL IN	1.142
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	0.937
OVERALL LENGTH L IN	1.400
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.5562
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-24

$75.12

Attribute: 5406-SHP-24 (24 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/2-11-1/2
THREAD B1 DRILL IN	1.486
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	1.125
OVERALL LENGTH L IN	1.470
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.8277
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-24-SS

$339.50

Attribute: 5406-SHP-24-SS (24 NPTF Square H...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/2-11-1/2
THREAD B1 DRILL IN	1.486
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	1.125
OVERALL LENGTH L IN	1.470
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.8562
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-SHP-32

$130.00

Attribute: 5406-SHP-32 (32 NPTF Square Head...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	2-11-1/2
THREAD B1 DRILL IN	1.720
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	SQUARE HEAD PIPE PLUG
BODY HEX IN	1.312
OVERALL LENGTH L IN	1.600
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	1.3562
CALIFORNIA RESIDENTS	PROP-65 WARNING

Connections	Other
Shape	Plug

ID	10144927
Category	Tube Fittings and Adapters

Description

Description

Variations (20)

5406-SHP-02

5406-SHP-02-SS

5406-SHP-04

5406-SHP-04-B

5406-SHP-04-SS

5406-SHP-06

5406-SHP-06-B

5406-SHP-06-SS

5406-SHP-08

5406-SHP-08-B

5406-SHP-08-SS

5406-SHP-12

5406-SHP-12-B

5406-SHP-12-SS

5406-SHP-16

5406-SHP-16-SS

5406-SHP-20

5406-SHP-24

5406-SHP-24-SS

5406-SHP-32

General Attributes

PDF Documents
