5406-HP

5406-HP-01

$0.86

Attribute: 5406-HP-01 (01 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/16-27
THREAD B1 DRILL IN	0.117
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.156
OVERALL LENGTH L IN	0.300
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.0044
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-01-SS

$14.42

Attribute: 5406-HP-01-SS (01 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/16-27
THREAD B1 DRILL IN	0.117
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.156
OVERALL LENGTH L IN	0.300
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.0062
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-02

$0.89

Attribute: 5406-HP-02 (02 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/8-27
THREAD B1 DRILL IN	0.220
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.188
OVERALL LENGTH L IN	0.300
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.0071
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-02-B

$4.76

Attribute: 5406-HP-02-B (02 NPTF Hollow Hex...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/8-27
THREAD B1 DRILL IN	0.220
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.188
OVERALL LENGTH L IN	0.300
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.0125
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-02-SS

$14.13

Attribute: 5406-HP-02-SS (02 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/8-27
THREAD B1 DRILL IN	0.220
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.188
OVERALL LENGTH L IN	0.300
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.0125
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-04

$2.01

Attribute: 5406-HP-04 (04 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/4-18
THREAD B1 DRILL IN	0.281
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.250
OVERALL LENGTH L IN	0.460
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.0192
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-04-B

$2.34

Attribute: 5406-HP-04-B (04 NPTF Hollow Hex...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/4-18
THREAD B1 DRILL IN	0.281
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.250
OVERALL LENGTH L IN	0.460
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.0228
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-04-SS

$18.41

Attribute: 5406-HP-04-SS (04 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/4-18
THREAD B1 DRILL IN	0.281
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.250
OVERALL LENGTH L IN	0.460
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.025
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-06

$1.77

Attribute: 5406-HP-06 (06 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/8-18
THREAD B1 DRILL IN	0.406
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.312
OVERALL LENGTH L IN	0.460
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.032
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-06-B

$6.20

Attribute: 5406-HP-06-B (06 NPTF Hollow Hex...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/8-18
THREAD B1 DRILL IN	0.406
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.312
OVERALL LENGTH L IN	0.460
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.0312
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-06-SS

$25.79

Attribute: 5406-HP-06-SS (06 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/8-18
THREAD B1 DRILL IN	0.406
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.312
OVERALL LENGTH L IN	0.460
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.0375
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-08

$2.11

Attribute: 5406-HP-08 (08 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/2-14
THREAD B1 DRILL IN	0.531
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.375
OVERALL LENGTH L IN	0.610
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.068
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-08-B

$9.23

Attribute: 5406-HP-08-B (08 NPTF Hollow Hex...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/2-14
THREAD B1 DRILL IN	0.531
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.375
OVERALL LENGTH L IN	0.610
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.0751
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-08-SS

$37.07

Attribute: 5406-HP-08-SS (08 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1/2-14
THREAD B1 DRILL IN	0.531
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.375
OVERALL LENGTH L IN	0.610
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.068
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-12

$6.25

Attribute: 5406-HP-12 (12 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/4-14
THREAD B1 DRILL IN	0.719
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.562
OVERALL LENGTH L IN	0.550
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.106
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-12-B

$10.06

Attribute: 5406-HP-12-B (12 NPTF Hollow Hex...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/4-14
THREAD B1 DRILL IN	0.719
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.562
OVERALL LENGTH L IN	0.550
SHAPE	STRAIGHT
BODY MATERIAL	BRASS
RAW MATERIAL TYPE	STRAIGHT BRASS
WEIGHT LBS	0.1187
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-12-SS

$55.92

Attribute: 5406-HP-12-SS (12 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	3/4-14
THREAD B1 DRILL IN	0.719
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.562
OVERALL LENGTH L IN	0.550
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.1062
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-16

$8.86

Attribute: 5406-HP-16 (16 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-11-1/2
THREAD B1 DRILL IN	0.907
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.625
OVERALL LENGTH L IN	0.790
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.2108
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-16-SS

$77.73

Attribute: 5406-HP-16-SS (16 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-11-1/2
THREAD B1 DRILL IN	0.907
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.625
OVERALL LENGTH L IN	0.790
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.22
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-20

$42.97

Attribute: 5406-HP-20 (20 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/4-11-1/2
THREAD B1 DRILL IN	1.142
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.750
OVERALL LENGTH L IN	0.770
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.4
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-20-SS

$338.17

Attribute: 5406-HP-20-SS (20 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/4-11-1/2
THREAD B1 DRILL IN	1.142
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	0.750
OVERALL LENGTH L IN	0.770
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.3625
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-24

$53.60

Attribute: 5406-HP-24 (24 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/2-11-1/2
THREAD B1 DRILL IN	1.486
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	1.000
OVERALL LENGTH L IN	0.830
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.47
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-24-SS

$309.97

Attribute: 5406-HP-24-SS (24 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	1-1/2-11-1/2
THREAD B1 DRILL IN	1.486
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	1.000
OVERALL LENGTH L IN	0.830
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.4625
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-32

$83.14

Attribute: 5406-HP-32 (32 NPTF Hollow Hex P...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	2-11-1/2
THREAD B1 DRILL IN	1.720
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	1.000
OVERALL LENGTH L IN	0.900
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.8833
CALIFORNIA RESIDENTS	PROP-65 WARNING

5406-HP-32-SS

$553.47

Attribute: 5406-HP-32-SS (32 NPTF Hollow He...)

Stock Status: True

THREAD B1 TYPE	MALE NPTF
THREAD B1 SIZE	2-11-1/2
THREAD B1 DRILL IN	1.720
THREAD B1 SPECIFICATION	SAE J476
THREAD B2 TYPE	HOLLOW HEX PIPE PLUG
BODY HEX IN	1.000
OVERALL LENGTH L IN	0.900
SHAPE	STRAIGHT
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.9625
CALIFORNIA RESIDENTS	PROP-65 WARNING

Connections	Other
Shape	Plug

ID	10144871
Category	Tube Fittings and Adapters

Description

Description

Variations (25)

5406-HP-01

5406-HP-01-SS

5406-HP-02

5406-HP-02-B

5406-HP-02-SS

5406-HP-04

5406-HP-04-B

5406-HP-04-SS

5406-HP-06

5406-HP-06-B

5406-HP-06-SS

5406-HP-08

5406-HP-08-B

5406-HP-08-SS

5406-HP-12

5406-HP-12-B

5406-HP-12-SS

5406-HP-16

5406-HP-16-SS

5406-HP-20

5406-HP-20-SS

5406-HP-24

5406-HP-24-SS

5406-HP-32

5406-HP-32-SS

General Attributes

PDF Documents
