Tube Fittings and Adapters

3051

Scraped 2026-02-15 08:27:47

Description

Description

MP-FP LOW PROFILE 90 Elbow

Variations (8)

3051-02-02

$15.90

Attribute: 3051-02-02 (02MP-02FP Low Profil...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/8-27
THREAD B1 DRILL IN0.188
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/8-27
THREAD B2 DRILL IN0.188
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN0.500
OVERALL LENGTH L IN1.020
CENTERLINE LENGTH M IN0.750
SHAPE90 DEGREE
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
WEIGHT LBS0.0375
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-02-02-SS

$114.23

Attribute: 3051-02-02-SS (02MP-02FP Low Pro...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/8-27
THREAD B1 DRILL IN0.188
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/8-27
THREAD B2 DRILL IN0.188
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN0.500
OVERALL LENGTH L IN1.020
CENTERLINE LENGTH M IN0.750
SHAPE90 DEGREE
BODY MATERIALSTAINLESS STEEL
RAW MATERIAL TYPESTRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-04-04

$23.38

Attribute: 3051-04-04 (04MP-04FP Low Profil...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/4-18
THREAD B1 DRILL IN0.281
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/4-18
THREAD B2 DRILL IN0.281
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN0.875
OVERALL LENGTH L IN1.562
CENTERLINE LENGTH M IN1.065
SHAPE90 DEGREE
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
WEIGHT LBS0.199
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-04-04-SS

$219.68

Attribute: 3051-04-04-SS (04MP-04FP Low Pro...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/4-18
THREAD B1 DRILL IN0.281
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/4-18
THREAD B2 DRILL IN0.281
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN0.875
OVERALL LENGTH L IN1.562
CENTERLINE LENGTH M IN1.065
SHAPE90 DEGREE
BODY MATERIALSTAINLESS STEEL
RAW MATERIAL TYPESTRAIGHT STAINLESS STEEL
WEIGHT LBS0.2
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-06-06

$24.57

Attribute: 3051-06-06 (06MP-06FP Low Profil...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE3/8-18
THREAD B1 DRILL IN0.406
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE3/8-18
THREAD B2 DRILL IN0.406
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN0.875
OVERALL LENGTH L IN1.562
CENTERLINE LENGTH M IN1.065
SHAPE90 DEGREE
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
WEIGHT LBS0.1867
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-08-08

$40.51

Attribute: 3051-08-08 (08MP-08FP Low Profil...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1/2-14
THREAD B1 DRILL IN0.531
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1/2-14
THREAD B2 DRILL IN0.531
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN1.125
OVERALL LENGTH L IN1.875
CENTERLINE LENGTH M IN1.310
SHAPE90 DEGREE
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
WEIGHT LBS0.384
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-12-12

$127.89

Attribute: 3051-12-12 (12MP-12FP Low Profil...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE3/4-14
THREAD B1 DRILL IN0.719
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE3/4-14
THREAD B2 DRILL IN0.719
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN1.375
OVERALL LENGTH L IN2.250
CENTERLINE LENGTH M IN1.500
SHAPE90 DEGREE
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
WEIGHT LBS0.2
CALIFORNIA RESIDENTSPROP-65 WARNING

3051-16-16

$156.28

Attribute: 3051-16-16 (16MP-16FP Low Profil...)

Stock Status: True

THREAD B1 TYPEMALE NPTF
THREAD B1 SIZE1-11-1/2
THREAD B1 DRILL IN0.938
THREAD B1 SPECIFICATIONSAE J476
THREAD B2 TYPEFEMALE NPTF
THREAD B2 SIZE1-11-1/2
THREAD B2 DRILL IN0.938
THREAD B2 SPECIFICATIONSAE J476
BODY HEX IN1.625
OVERALL LENGTH L IN2.785
CENTERLINE LENGTH M IN1.972
SHAPE90 DEGREE
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
WEIGHT LBS1.0875
CALIFORNIA RESIDENTSPROP-65 WARNING

General Attributes

Connections NPT
Shape Elbow

PDF Documents

Download CAD and Drawings Open PDF
