0500

0500-06-06

$7.98

Attribute: 0500-06-06 (06Bore-06MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 3/8
THREAD B1 DRILL IN	0.379
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	9/16-18
THREAD B2 DRILL IN	0.297
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	0.625
OVERALL LENGTH L IN	1.375
CENTERLINE LENGTH M IN	1.062
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.08
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-08-08

$18.76

Attribute: 0500-08-08 (08Bore-08MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1/2
THREAD B1 DRILL IN	0.506
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	3/4-16
THREAD B2 DRILL IN	0.391
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	0.812
OVERALL LENGTH L IN	1.656
CENTERLINE LENGTH M IN	1.250
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.218
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-10-10

$20.97

Attribute: 0500-10-10 (10Bore-10MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 5/8
THREAD B1 DRILL IN	0.631
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	7/8-14
THREAD B2 DRILL IN	0.484
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	0.937
OVERALL LENGTH L IN	1.938
CENTERLINE LENGTH M IN	1.453
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.25
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-10-10-SS

$224.70

Attribute: 0500-10-10-SS (10Bore-10MJ 90 El...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 5/8
THREAD B1 DRILL IN	0.631
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	7/8-14
THREAD B2 DRILL IN	0.484
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	0.937
OVERALL LENGTH L IN	1.938
CENTERLINE LENGTH M IN	1.453
SHAPE	90 DEGREE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-12-08

$31.80

Attribute: 0500-12-08 (12Bore-08MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 3/4
THREAD B1 DRILL IN	0.756
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	3/4-16
THREAD B2 DRILL IN	0.391
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	0.937
OVERALL LENGTH L IN	1.780
CENTERLINE LENGTH M IN	1.310
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.2147
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-12-12

$18.90

Attribute: 0500-12-12 (12Bore-12MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 3/4
THREAD B1 DRILL IN	0.756
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-1/16-12
THREAD B2 DRILL IN	0.609
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.125
OVERALL LENGTH L IN	2.219
CENTERLINE LENGTH M IN	1.660
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.416
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-12-12-SS

$376.67

Attribute: 0500-12-12-SS (12Bore-12MJ 90 El...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 3/4
THREAD B1 DRILL IN	0.756
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-1/16-12
THREAD B2 DRILL IN	0.609
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.125
OVERALL LENGTH L IN	2.219
CENTERLINE LENGTH M IN	1.660
SHAPE	90 DEGREE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.45
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-14-14

$248.19

Attribute: 0500-14-14 (14Bore-14MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 7/8
THREAD B1 DRILL IN	0.882
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-3/16-12
THREAD B2 DRILL IN	0.719
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.250
CENTERLINE LENGTH M IN	1.734
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.52
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-16-16

$29.14

Attribute: 0500-16-16 (16Bore-16MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1
THREAD B1 DRILL IN	1.007
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-5/16-12
THREAD B2 DRILL IN	0.844
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.375
OVERALL LENGTH L IN	2.500
CENTERLINE LENGTH M IN	1.812
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.6533
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-16-16-SS

$596.21

Attribute: 0500-16-16-SS (16Bore-16MJ 90 El...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1
THREAD B1 DRILL IN	1.007
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1
THREAD B2 DRILL IN	1.812
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.375
OVERALL LENGTH L IN	2.500
CENTERLINE LENGTH M IN	1.812
SHAPE	90 DEGREE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
WEIGHT LBS	0.725
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-20-16-SS

$665.36

Attribute: 0500-20-16-SS (20Bore-16MJ 90 El...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1 1/4
THREAD B1 DRILL IN	1.258
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-5/16-12
THREAD B2 DRILL IN	0.844
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.750
CENTERLINE LENGTH M IN	2.062
SHAPE	90 DEGREE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-20-20

$72.66

Attribute: 0500-20-20 (20Bore-20MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1 1/4
THREAD B1 DRILL IN	1.256
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-5/8-12
THREAD B2 DRILL IN	1.078
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.750
OVERALL LENGTH L IN	2.938
CENTERLINE LENGTH M IN	2.062
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	1.3
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-20-20-SS

$670.30

Attribute: 0500-20-20-SS (20Bore-20MJ 90 El...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1 1/4
THREAD B1 DRILL IN	1.256
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-5/8-12
THREAD B2 DRILL IN	1.078
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.750
OVERALL LENGTH L IN	2.938
CENTERLINE LENGTH M IN	2.062
SHAPE	90 DEGREE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-24-24

$431.85

Attribute: 0500-24-24 (24Bore-24MJ 90 Elbow)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1 1/2
THREAD B1 DRILL IN	1.508
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-7/8-12
THREAD B2 DRILL IN	1.312
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	2.000
CENTERLINE LENGTH M IN	2.328
SHAPE	90 DEGREE
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	1.79
CALIFORNIA RESIDENTS	PROP-65 WARNING

0500-24-24-SS

$837.89

Attribute: 0500-24-24-SS (24Bore-24MJ 90 El...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 1 1/2
THREAD B1 DRILL IN	1.508
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1-7/8-12
THREAD B2 DRILL IN	1.312
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	2.000
CENTERLINE LENGTH M IN	2.328
SHAPE	90 DEGREE
BODY MATERIAL	STAINLESS STEEL
RAW MATERIAL TYPE	STRAIGHT STAINLESS STEEL
CALIFORNIA RESIDENTS	PROP-65 WARNING

Connections	JIC, Bore
Shape	Elbow

ID	10142290
Category	Tube Fittings and Adapters

Description

Description

Variations (15)

0500-06-06

0500-08-08

0500-10-10

0500-10-10-SS

0500-12-08

0500-12-12

0500-12-12-SS

0500-14-14

0500-16-16

0500-16-16-SS

0500-20-16-SS

0500-20-20

0500-20-20-SS

0500-24-24

0500-24-24-SS
