0406

Attribute: 0406-06-06 (06Bore-06MJ Bulkhead...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 3/8
THREAD B1 DRILL IN	0.379
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	9/16-18
THREAD B2 DRILL IN	0.297
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	0.813
OVERALL LENGTH L IN	1.624
OVERALL LENGTH L2 IN	0.344
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
WEIGHT LBS	0.0937
CALIFORNIA RESIDENTS	PROP-65 WARNING

Attribute: 0406-12-12 (12Bore-12MJ Bulkhead...)

Stock Status: True

THREAD B1 TYPE	BORE
THREAD B1 SIZE	TUBE OD 3/4
THREAD B1 DRILL IN	0.757
THREAD B2 TYPE	MALE JIC SAE 37 DEGREE FLARE
THREAD B2 SIZE	1 1/16-12
THREAD B2 DRILL IN	0.609
THREAD B2 SPECIFICATION	SAE J514
BODY HEX IN	1.375
OVERALL LENGTH L IN	2.300
OVERALL LENGTH L2 IN	0.500
SHAPE	STRAIGHT
BODY MATERIAL	STEEL
RAW MATERIAL TYPE	STRAIGHT STEEL
PLATING	CR3
CALIFORNIA RESIDENTS	PROP-65 WARNING
