NH-600R

Attribute: NH-600R-SS-L-1/2-15 (08INS-08INS...)

Stock Status: True

SERIES	H-600R
MAX WORKING PRESSURE	6000PSI
END CONNECTION	LET-LET INS
BODY TYPE / PATTERN	TEE / STRAIGHT FLOW
MATERIAL	STAINLESS STEEL
INLET CONNECTION (1)	1/2″ LET-LOK INS
OUTLET CONNECTION (2)	1/2″ LET-LOK INS
FILTER LEVEL	15 MICRON
BYPASS/PURGE PORT OPTION	N
SPARE KIT OPTION	N
OXYGEN CLEAN OPTION	N
ORIFICE (MM)	6.35
L OVERALL LENGTH (MM)	77.3
L1 LENGTH (MM)	33.4
M (MM)	28.8
D (MM)	11.6
H (MM)	56.0
N FILTER HEX (MM)	28.6

Attribute: NH-600R-SS-L-3/8-7 (06INS-06INS-...)

Stock Status: True

SERIES	H-600R
MAX WORKING PRESSURE	6000PSI
END CONNECTION	LET-LOK INS
BODY TYPE / PATTERN	TEE / STRAIGHT FLOW
MATERIAL	STAINLESS STEEL
INLET CONNECTION (1)	3/8″ LET-LOK INS
OUTLET CONNECTION (2)	3/8″ LET-LOK INS
FILTER LEVEL	7 MICRON
BYPASS/PURGE PORT OPTION	N
SPARE KIT OPTION	N
OXYGEN CLEAN OPTION	N
ORIFICE (MM)	5.41
L OVERALL LENGTH (MM)	72.2
L1 LENGTH (MM)	33.6
M (MM)	28.8
D (MM)	11.6
H (MM)	56.0
N FILTER HEX (MM)	28.6
