Description
INS-INS-INLINE FILTER STRAIGHT
Description
Variations (6)
NH-600-SS-L-1/2-0.5
$538.25Attribute: NH-600-SS-L-1/2-0.5 (08INS-08INS...)
Stock Status: True
| SERIES | H-600 |
|---|---|
| MAX WORKING PRESSURE | 3000PSI |
| END CONNECTION | LET-LOK INS |
| BODY TYPE / PATTERN | IN-LINE FILTER |
| MATERIAL | STAINLESS STEEL |
| INLET CONNECTION (1) | 1/2″ LET-LOK INS |
| OUTLET CONNECTION (2) | 1/2″ LET-LOK INS |
| FILTER LEVEL | 0.5 MICRON |
| BYPASS/PURGE PORT OPTION | N |
| SPARE KIT OPTION | N |
| OXYGEN CLEAN OPTION | N |
| ORIFICE (MM) | 10.3 |
| L OVERALL LENGTH (MM) | 88.5 |
| K HEX (MM) | 25.4 |
NH-600-SS-L-1/4-0.5
$259.17Attribute: NH-600-SS-L-1/4-0.5 (04INS-04INS...)
Stock Status: True
| SERIES | H-600 |
|---|---|
| MAX WORKING PRESSURE | 3000PSI |
| END CONNECTION | LET-LOK INS |
| BODY TYPE / PATTERN | IN-LINE FILTER |
| MATERIAL | STAINLESS STEEL |
| INLET CONNECTION (1) | 1/4″ LET-LOK INS |
| OUTLET CONNECTION (2) | 1/4″ LET-LOK INS |
| FILTER LEVEL | 0.5 MICRON |
| BYPASS/PURGE PORT OPTION | N |
| SPARE KIT OPTION | N |
| OXYGEN CLEAN OPTION | N |
| ORIFICE (MM) | 4.75 |
| L OVERALL LENGTH (MM) | 70.0 |
| K HEX (MM) | 19.05 |
NH-600-SS-L-1/4-15
$277.30Attribute: NH-600-SS-L-1/4-15 (04INS-04INS-...)
Stock Status: True
| SERIES | H-600 |
|---|---|
| MAX WORKING PRESSURE | 3000PSI |
| END CONNECTION | LET-LOK INS |
| BODY TYPE / PATTERN | IN-LINE FILTER |
| MATERIAL | STAINLESS STEEL |
| INLET CONNECTION (1) | 1/4″ LET-LOK INS |
| OUTLET CONNECTION (2) | 1/4″ LET-LOK INS |
| FILTER LEVEL | 15 MICRON |
| BYPASS/PURGE PORT OPTION | N |
| SPARE KIT OPTION | N |
| OXYGEN CLEAN OPTION | N |
| ORIFICE (MM) | 4.75 |
| L OVERALL LENGTH (MM) | 70.0 |
| K HEX (MM) | 19.05 |
NH-600-SS-L-10MM-440
$559.02Attribute: NH-600-SS-L-10MM-440 (10MMINS-10...)
Stock Status: True
| SERIES | H-600 |
|---|---|
| MAX WORKING PRESSURE | 3000PSI |
| END CONNECTION | LET-LOK INS |
| BODY TYPE / PATTERN | IN-LINE FILTER |
| MATERIAL | STAINLESS STEEL |
| INLET CONNECTION (1) | 10MM LET-LOK INS |
| OUTLET CONNECTION (2) | 10MM LET-LOK INS |
| FILTER LEVEL | 440 MIRCRON |
| BYPASS/PURGE PORT OPTION | N |
| SPARE KIT OPTION | N |
| OXYGEN CLEAN OPTION | N |
NH-600-SS-L-3/8-15
$415.97Attribute: NH-600-SS-L-3/8-15 (06INS-06INS-...)
Stock Status: True
| SERIES | H-600 |
|---|---|
| MAX WORKING PRESSURE | 3000PSI |
| END CONNECTION | LET-LOK INS |
| BODY TYPE / PATTERN | IN-LINE FILTER |
| MATERIAL | STAINLESS STEEL |
| INLET CONNECTION (1) | 3/8″ LET-LOK INS |
| OUTLET CONNECTION (2) | 3/8″ LET-LOK INS |
| FILTER LEVEL | 15 MICRON |
| BYPASS/PURGE PORT OPTION | N |
| SPARE KIT OPTION | N |
| OXYGEN CLEAN OPTION | N |
| ORIFICE (MM) | 7.14 |
| L OVERALL LENGTH (MM) | 81.4 |
| K HEX (MM) | 25.4 |
NH-600-SS-L-6MM-2-OC
$306.83Attribute: NH-600-SS-L-6MM-2-OC (06MMINS-06...)
Stock Status: True
| SERIES | H-600 |
|---|---|
| MAX WORKING PRESSURE | 3000PSI |
| END CONNECTION | LET-LOK INS |
| BODY TYPE / PATTERN | IN-LINE FILTER |
| MATERIAL | STAINLESS STEEL |
| INLET CONNECTION (1) | 6MM LET-LOK INS |
| OUTLET CONNECTION (2) | 6MM LET-LOK INS |
| FILTER LEVEL | 2 MICRON |
| BYPASS/PURGE PORT OPTION | N |
| SPARE KIT OPTION | N |
| OXYGEN CLEAN OPTION | OXYGEN CLEAN |
| ORIFICE (MM) | 4.75 |
| L OVERALL LENGTH (MM) | 74.9 |
| K HEX (MM) | 19.05 |
General Attributes
| Connections | Instrumentation |
|---|---|
| Shape | Straight |
