Description
Heavy Series Single Weld Plate Metric
Description
Variations (4)
AWP-H3-M-PCS
$12.67Attribute: AWP-H3-M-PCS (Hvy Sgl Weld Plate...)
Stock Status: True
| GROUP | 3 |
|---|---|
| L1 | 74 |
| L2 | 33 |
| B | 30 |
| S | 8 |
| H | 8 |
| D | M10 |
| THREAD | CARBON STEEL |
| MATERIAL | PHOS STEEL |
AWP-H4-M-PCS
$14.55Attribute: AWP-H4-M-PCS (Hvy Sgl Weld Plate...)
Stock Status: True
| GROUP | 4 |
|---|---|
| L1 | 86 |
| L2 | 45 |
| B | 30 |
| S | 8 |
| H | 8 |
| D | M10 |
| THREAD | CARBON STEEL |
| MATERIAL | PHOS STEEL |
AWP-H5-M-PCS
$15.80Attribute: AWP-H5-M-PCS (Hvy Sgl Weld Plate...)
Stock Status: True
| GROUP | 5 |
|---|---|
| L1 | 100 |
| L2 | 60 |
| B | 30 |
| S | 8 |
| H | 8 |
| D | M10 |
| THREAD | CARBON STEEL |
| MATERIAL | PHOS STEEL |
AWP-H6-M-PCS
$20.62Attribute: AWP-H6-M-PCS (Hvy Sgl Weld Plate...)
Stock Status: True
| GROUP | 6 |
|---|---|
| L1 | 140 |
| L2 | 90 |
| B | 45 |
| S | 10 |
| H | 8 |
| D | M12 |
| THREAD | CARBON STEEL |
| MATERIAL | PHOS STEEL |
General Attributes
| Connections | Other |
|---|---|
| Shape | Other |
